Hyundai Genesis Coupe 2016 Fuse Box Info
Passenger compartment fuse box location:
The fuse box is located on the left hand side of the instrument panel facing the driver’s side door.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay Name | Rating | Functions |
| AUDIO | 15A | Audio, A/V & Navigation Head Unit, Multi Gauge, Multi Monitor Front Monitor, MTS Module |
| DRV P/SEAT | 30A | Driver Seat Manual Switch, Driver Lumbar Support Switch |
| HAZARD | 15A | BCM, Flasher Sound Relay |
| PDM1 | 25A | PDM |
| ROOM LP | 10A | Driver/Passenger Door Lamp, Trunk Room Lamp Driver/Passenger Door Scuff Lamp, Vanity Lamp LH/RH Map Lamp |
| C/LIGHTER | 15A | Front Power Outlet |
| MEMORY1 | 10A | BCM, Data Link Connector, Auto Light & Photo Sensor Ignition Key ILL. & Door Warning Switch, Electro Chromic Mirror Instrument Cluster (IND. MICOM), A/C Control Module Tire Pressure Monitoring Module |
| MEMORY2 | 7.5A | RF Receiver |
| ABS | 7.5A | E/R Junction Box LH (Multipurpose Check Connector) ESC Module, ESC & PAS Switch, Steering Angle Sensor |
| A/BAG IND | 7.5A | Instrument Cluster (Air Bag IND.) |
| A/BAG | 15A | SRS Control Module, A/C Control Module, PODS Module |
| B/UP LP | 15A | Back-Up Lamp Switch, TCM, Transmission Range Switch |
| MODULE3 | 10A | ECM, PDM, Smart Key Control Module, Injector Drive Box (G6DJ) |
| MODULE1 | 7.5A | AMP, Audio, A/V & Navigation Head Unit, Multi Monitor, MTS Module Front Monitor, Map Lamp, Power Outside Mirror Switch |
| POWER OUTLET | 15A | Console Power Outlet |
| MODULE6 | 10A | BCM, PDM, Smart Key Control Module |
| MODULE2 | 7.5A | IPS Control Module, Instrument Cluster (IND, MICOM), BCM, ATM Shift Lever IND., Multifunction Switch (Remote Control), Multi Gauge, Cruise Clutch Pedal Position Switch, A/C Control Module, Auto Head Lamp Leveling Device Unit, Stop Lamp Switch, Driver/Passenger Seat Warmer Module, Electro Chromic Mirror, MTS Module, Tire Pressure Monitoring Module, Head Lamp Leveling Device Actuator LH/RH, Front Parking Assist Sensor LH/RH Rear Parking Assist Sensor Side LH/RH Rear Parking Assist Sensor Center LH/RH |
| MODULE5 | 7.5A | Sport Mode Switch (A/T), Key Solenoid |
| STOP LP | 15A | Stop Signal Relay |
| MODULE7 | 7.5A | Blower Relay, Sunroof Control Module, A/C Control Module, Cluster Ionizer (Auto A/C) |
| MODULE4 | 7.5A | BCM, PDM, IPS Control Module, Vacuum Switch E/R Junction Box LH (Vacuum Pump Relay) |
| WIPER FRT | 25A | MultiFunction Switch (Wiper), Front Wiper Motor E/R Junction Box LH (Wiper FRT Relay) |
| START | 10A | E/R Junction Box LH (Start Relay), Ignition Lock Switch, PDM Transmission Range Switch, ECM (G6DJ), B/Alarm Relay |
| BLOWER | 7.5A | A/C Control Module |
| HTD MIRR | 7.5A | A/C Control Module, Driver/Passenger Power Outside Mirror |
| TRUNK | 10A | Trunk Lid & Fuel Filler Door Switch, ICM Relay Box (Trunk Lid Relay) |
| PDM2 | 10A | PDM, Smart Key Control Module, Start Stop Button Switch, FOB Holder |
| SAFETY POWER WINDOW RH | 25A | Passenger Safety Power Window Module |
| FOG LP RR | 10A | (Not Used) |
| S/HEATER | 15A | Driver/Passenger Seat Warmer Module |
| AMP | 25A | AMP (JBL) |
| SAFETY POWER WINDOW LH | 25A | Driver Safety Power Window Module |
Engine compartment fuse box (Main fuse box):
| Fuse/Relay Name | Rating | Functions |
| C/FAN | 60A | Cooling Fan (High) Relay, Cooling Fan (Low) Relay |
| B+1 | 60A | Smart Junction Box ((Fuse : S/HEATER, AMP, SAFETY POWER WINDOW LH/RH), IPS 2, IPS Control Module) |
| BLOWER | 40A | Smart Junction Box (Blower Relay) |
| ABS2 | 40A | Multipurpose Check Connector, ESC Module |
| ABS1 | 40A | Multipurpose Check Connector, ESC Module |
| ALT | 150A | Alternator, Multi Fuse (ABS1, ABS2, BLOWER, B+1, C/FAN), Fuse (S/ROOF FRT, DEICER, VACUUM PUMP) |
| RR HTD | 40A | RR HTD Relay |
| B+2 | 60A | Smart Junction Box ((Fuse : HAZARD, PDM1, MODULE5, STOP LP, TRUNK, PDM2), IPS 1, ARISU 2, IPS Control Module) |
| B+3 | 60A | Smart Junction Box ((Fuse : AUDIO, DRV P/SEAT, ROOM LP, MEMORY1, MEMORY2), ARISU 1, IPS Control Module, Leak Current Autocut Device Switch, Leak Current Autocut Device Relay) |
| IG2 | 30A | Start Relay, IG2 Relay, Ignition Switch |
| IG1 | 40A | IG1 Relay, ACC Relay, Ignition Switch |
| S/ROOF FRT | 20A | Sunroof Control Module |
| DEICER | 15A | Deicer Relay |
| VACUUM PUMP | 15A | Vacuum Pump Relay (G4KF A/T) |
| DR LOCK | 10A | Smart Junction Box (Door Lock Relay, Door Unlock Relay), ICM Relay Box (Two Turn Unlock Relay) |
| BRAKE SW | 10A | Stop Lamp Switch |
| HORN | 15A | Horn Relay |
| DEDICATED DRL | 10A | Dedicated DRL Relay |
| B/UP LP | 10A |
M/T - Back-Up Lamp Switch A/T - Rear Combination Lamp LH/RH, Electro Chromic Mirror, A/V & Navigation Head Unit |
Engine compartment fuse box (Sub fuse box):
| Fuse/Relay Name | Rating | Functions |
| B+ | 50A | Fuse (EMS 30A, ECU1 10A, F/PUMP 20A) |
| EMS | 30A | Engine Control Relay |
| F/PUMP | 20A | F/Pump Relay |
| ECU 1 |
10A G4KF 10A G6DJ |
ECM, TCM ECM, TCM, Injector Drive Box |
| INJECTOR |
15A G4KF 15A G6DJ |
F/Pump Relay, Injector #1/#2/#3/#4 F/Pump Relay, Fuel Pump Relay (Low), ECM |
| IGN COIL |
20A G4KF 20A G6DJ |
Ignition Coil #1/#2/#3/#4, Condenser Ignition Coil #1/#2/#3/#4/#5/#6, Condenser #1/#2 |
| ECU 2 |
20A G4KF 20A G6DJ |
ECM Injector Drive Box |
| SENSOR 1 |
10A G4KF 10A G6DJ |
Cooling Fan (High)/(Low) Relay, Oxygen Sensor (Up)/(Down) Cooling Fan (High)/(Low) Relay, ECM, Oxygen Sensor #1/#2/#3/#4 |
| SENSOR 2 |
15A G4KF 15A G6DJ |
Camshaft Position Sensor #1/#2, RCV Control Solenoid Valve, Immobilizer Module, Canister Close Valve, Purge Control Solenoid Valve, Crankshaft Position Sensor, Oil Control Valve #1/#2 ECM, Oil Control Valve #1/#2/#3/#4, Purge Control Solenoid Valve, Immobilizer Module, Canister Close Valve |
