Hyundai Veloster 2015 Fuse Box Info
Passenger compartment fuse box location:
The fuse box is located at the left side of the steering column at the bottom of the instrument panel.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay Name | Rating | Functions |
| C/LIGHTER | 15A | Cigarette Lighter |
| DRL | 10A | Not Used |
| HTD STRG | 15A | Smart Key Control Module, A/C Inverter Module, Steering wheel heated |
| MDPS | 10A | EPS Control Module |
| A/BAG IND | 10A | Instrument Cluster (Air Bag IND.) |
| POWER OUTLET | 15A | Power Outlet |
| WIPER RR | 15A | Engine Room Fuse & Relay Box (Rear Wiper Relay), Rear Wiper Motor, Multifunction Switch |
| IG 2 | 10A | Engine Room Fuse & Relay Box (Front Wiper Relay, Blower Relay), Crash Pad Switch, Panaroma Sunroof Motor, A/C Control Module, IPS Control Module |
| WIPER FRT | 25A | Multifunction Switch, Front Wiper Motor, Engine Room Fuse & Relay Box (Front Wiper Relay) |
| CLUSTER | 10A | Instrument Cluster, Tire Pressure Monitoring Module, Sport Mode Switch, Shift Lever Indicator, MTS Module |
| AUDIO | 10A | Power Outside Mirror Switch, AMP, A/V & Navigation Head Unit, MTS Module, Smart Key Control Module, IPS Control Module |
| MULTIMEDIA | 15A | A/V & Navigation Head Unit, MTS Module |
| A/BAG | 15A | Passenger Occupant Detection Sensor, SRS Control Module, Telltale |
| IG 1 | 10A | Rear Parking Assist Sensor LH/RH, Rear Parking Assist Sensor Center LH/RH, Rear Parking Assist Buzzer, IPS Control Module, Driver/Passenger Seat Warmer, Driver/Passenger Seat Warmer Switch, MTS Module, A/C Control Module |
| 1 SMART KEY | 15A | Smart Key Control Module |
| MEMORY | 10A | Data Link Connector, Instrument Cluster, A/C Control Module |
| A/CON | 10A | ECM |
| ABS | 10A | ESC Module, ESC Off Switch, E/R Fuse & Relay Box (HAC Relay, Multipurpose Check Connector) |
| DR LOCK | 20A | Door Lock Relay, Door Unlock Relay, Flasher Sound Relay, Tail Gate Latch Relay, Two Turn Unlock Relay, IPS Control Module |
| FOLD'G MIRR/ FOG LP RR | 15A | Not Used |
| STOP LAMP | 15A | Stop Lamp Switch, Stop Signal Relay, Smart Key Control Module |
| ECU | 10A | Immobilizer Module, Smart Key Control Module, ECM, Stop Lamp Switch |
| AMP | 25A | AMP |
| INVERTER | 25A | A/C Inverter Module |
| INTERIOR LAMP | 10A | Luggage Room Lamp, Map Lamp, Room Lamp, Vanity Lamp LH/RH, Overhead Console Lamp |
| 2 SMART KEY | 10A | Smart Key Control Module, Immobilizer Module, Start Stop Button Switch |
| TCU (VACUUM PUMP) |
15A T-GDI 15A GDI |
Engine Room Fuse & relay box (Vacuum Pump Relay) TCM |
| TAIL LP LH | 10A | Rear Combination Lamp LH, License Lamp LH/RH, Shift Lever Indicator, Instrument Cluster, Multifunction Switch, Passenger Power Window Switch, Power Window Main Switch, AUX & USB Jack, Inside Miiror A/C Control Module, ESC Off Switch, A/V & Navigation Head Unit, Crash Pad Switch, Driver/Passenger Seat Warmer Switch, Head Lamp LH |
| S/HEATER | 20A | Driver/Passenger Seat Warmer |
| P/WDW LH | 25A | Power Window Main Switch |
| START | 10A | Burglar Alarm Relay, Transaxle Range Switch, Smart Key Control Module, ECM, TCM, Engine Room Fuse & Relay Box (Start Relay) |
| 1 B/UP LP | 15A | Back-Up Lamp Switch, Transaxle Range Switch |
| TAIL LAMP RH | 10A | Head Lamp RH, Rear Combination Lamp RH |
| SAFETY POWER WINDOW | 25A | Driver Safety Power Window Module |
| P/WDW RH | 25A | Power Window Main Switch, Passenger Power Window Switch, Rear Power Window Switch RH |
| 2 B/UP LAMP | 10A | A/V & Navigation Head Unit, Transaxle Range Switch, MTS Module, TCM, Back-Up Lamp Switch, Rear Combination Lamp LH/RH, IPS Control Module |
| SPARE | 15A | - |
| HTD MIRR | 10A | ECM, A/C Control Module, Dirver/Passenger Power Outside Mirror |
| P/SEAT DRV | 25A | Lumber Support |
Engine compartment fuse box:
| Fuse/Relay Name | Rating | Functions |
| MDPS | 80A | EPS Control Module |
| BLOWER | 40A | Engine Room Fuse & Relay Box (Blower Relay) |
| 1 DCT | 40A GDI | TCM |
| RR HTD | 40A | Engine Room Fuse & Relay Box (Rear Defogger Relay) |
| ALT |
125A GDI 150A T-GDI |
Engine Room Fuse & Relay Box (Multi Fuse - EcoShift dual clutch transmission 1, MDPS, RR HTD, BLOWER), Alternator |
| 2 ABS | 30A | Multipurpose Check Connector, ESC Module |
| 2 B+ | 50A | Smart Junction Box (Power Window Relay, IPS Control Module (ARISU LT), Fuse - SAFETY POWER WINDOW, AMP) |
| 1 B+ | 50A | Leak Current Autocut Device (Room Lamp Relay, Leak Current Autocut Switch, Fuse - INTERIOR LAMP, MULTIMEDIA, MEMORY ), Fuse - S/HEATER |
| C/FAN |
40A GDI 60A T-GDI |
Engine Room Fuse & Relay Box (Cooling Fan (High) Relay, Cooling Fan (Low) Relay) Engine Room Fuse & Relay Box (Cooling Fan (High) Relay) |
| A/CON | 10A | Engine Room Fuse & Relay Box (A/CON Relay) |
| FOG LAMP FRT | 10A | Engine Room Fuse & Relay Box (Fog Lamp Relay) |
| HORN | 15A | Engine Room Fuse & Relay Box (Burglar Alarm Horn Relay, Horn Relay) |
| SUNROOF | 20A | Panorama Sunroof Motor |
| VACUUM PUMP | 20A T-GDI | Engine Room Fuse & Relay Box (Vacuum Pump Relay) |
| AMS | 10A | Battery Sensor |
| IG 2 | 40A | Ignition Switch, PDM Relay Box (IG 2 Relay), Engine Room Fuse & Relay Box (Start Relay) |
| IG 1 | 40A | Ignition Switch, PDM Relay Box (IG 1 Relay, ACC Relay) |
| 1 SENSOR | 20A | ECM |
| 2 SENSOR |
10A GDI 10A T-GDI |
Oxygen Sensor (Up)/(Down), Canister Close Valve, Variable Intake Solenoid Valve, Purge Control Solenoid Valve, Engine Room Fuse & Relay Box (Cooling Fan (High/Low) Relay) Oxygen Sensor (Up)/(Down), Canister Close Valve, Recirulation valve, Waste gate valve, Purge Control Solenoid Valve, Engine Room Fuse & Relay Box (Cooling Fan (High) Relay) |
| 3 SENSOR | 15A | Engine Room Fuse & Relay Box (Fuel Pump Relay), Engine Room Fuse & Relay Box (A/CON Relay), Oil Control Valve #1 (Intake)/#2 (Exhaust), ECM |
| 2 ECU | 15A | ECM |
| 3 DCT | 15A GDI | TCM |
| F/PUMP |
15A GDI 20A T-GDI |
Engine Room Fuse & Relay Box (Fuel Pump Relay) |
| 1 ABS | 40A | ESC Module |
| 1 ECU | 30A | Engine Room Fuse & Relay Box (Engine Conrol Relay, Fuse - ECU 2) |
| 2 DCT | 40A GDI | TCM |
| 3 B+ | 50A | Smart Junction Box (Tail Lamp Relay, IPS Control Module (ARISU RT), Fuse - STOP LP, SMART KEY 1/2, INVERTER 2, DR LOCK ) |
| 3 ECU | 10A | Sport Mode Switch, Key Solenoid |
| 4 ECU | 15A | Condenser, Ignition coil #1/#2/#3/#4 |
