Fiat Bravo 2007 Fuse Box Info
Passenger compartment fuse box location:
The fuse box is located on the left side of the dashboard.
Engine compartment fuse box location:
The fuse box is located next to the battery.
Luggage compartment fuse box location:
The fuse box is located on the left side of the boot.
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| F12 | 7.5A | Right dipped beam (quartz-iodine headlights) |
| F12 | 15A | Right dipped beam (Bi-Xenon headlights) |
| F13 | 7.5A | Left dipped beam (quartz-iodine headlights) |
| F13 | 15A | Left dipped beam (Bi-Xenon headlights) |
| F13 | 15A | Headlamp alignment correction system (versions with gas discharge headlights) |
| F13 | 7.5A | Headlight alignment correction system (versions with halogen headlights) |
| F31 | 5A | Remote switch coils on fuse box in engine compartment (CVM)/ Body Computer control unit (NBC) |
| F32 | 15A | Hi-Fi system subwoofer |
| F33 | 20A | Rear left power window |
| F34 | 20A | Rear right power window |
| F35 | 5A | Brake pedal control (normally closed contact NC)/water in diesel fuel sensor/flow meter |
| F35 | 7.5A | Reversing light |
| F36 | 20A | Door opening system control unit (CGP) (door opening/closing, safe lock, tailgate release) |
| F37 | 7.5A | Third stop light |
| F37 | 7.5A | Brake pedal control (normally closed contact NA)/Instrument panel (NQS)/gas-discharge lamp control units on front headlights |
| F39 | 10A | Sound system/Sound system presetting/Connect Nav +/Blu&Me System/Alarm siren (CSA)/Alarm system on ceiling light/Internal cooling unit system/Tyre pressure monitoring control unit (CPP)/Diagnostic socket connector/Rear ceiling lights |
| F40 | 30A | Heated rear window |
| F41 | 7.5A | Electric door mirror defrosters/Defrosters on front nozzles |
| F42 | 5A | Braking system control unit (NFR)/Yaw sensor (YRS) |
| F43 | 30A | Windscreen wiper/Windscreen/rear window washer bidirectional motor pump system on steering column stalk |
| F44 | 15A | Current outlet/Cigar lighter |
| F45 | - | Free |
| F46 | 20A | Power sunroof motor |
| F47 | 20A | Front power window (left side) |
| F48 | 20A | Front power window (right side) |
| F49 | 5A | Emergency control panel (illumination)/Central right and left branch control panel (illumination, ASR switch)/ Controls on steering wheel (illumination)/Control panel on front ceiling light (illumination)/Volumetric protection alarm system control unit (deactivation)/Power sunroof (control unit, control illumination)/rain sensor/daylight sensor on driving mirror/Front seat warming activation controls |
| F50 | 7.5A | Air bag control unit (NAB) |
| F51 | 5A | Internal cooling unit system/Sound system presetting/ Connect Nav +/Blu&Me system control unit/Parking sensor control unit (NSP)/Air quality sensor (AQS)/Automatic air-conditioner/Electric door mirrors (moving, folding)/ Tyre pressure monitoring control unit (CPP) |
| F52 | 15A | Rear window wiper |
| F53 | 7.5A | Instrument panel (NQS) |
| F53 | 7.5A | Rear fog light (driver’s side) |
Engine compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| F09 | 7.5A | Front fog light/Cornering light, RH |
| F10 | 10A | Single-tone horn |
| F11 | 15A | Engine diagnosis system secondary loads (lambda sensor, canister solenoid valve, PDA system solenoid valve, EGR solenoid valve, throttle solenoid valve, VGT solenoid valve, glow plug warming control unit) |
| F14 | 7.5A | Right main beam headlight |
| F15 | 10A | Left main beam headlight |
| F16 | 7.5A | Engine control unit (NCM) |
| F17 | 10A | Engine control unit (NCM) |
| F18 | 10A | Engine control unit (NCM) |
| F19 | 7.5A | Conditioner compressor |
| F20 | 20A | Headlight washer motor pump |
| F21 | 15A | Fuel motor pump on tank |
| F22 | 15A | Engine diagnosis system primary loads (injectors, ignition coils) |
| F22 | 20A | Engine diagnosis system primary loads (injectors, ignition coils, engine control unit for diesel versions) |
| F23 | 30A | Braking system control unit (NFR) (electronic control unit, solenoid valves) |
| F24 | 7.5A | Electric steering control unit (NGE) |
| F30 | 7.5A | Front fog light/Cornering light, LH |
Luggage compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| F56 | 30A | Left front seat heating/movement |
| F60 | 30A | Right front seat heating/movement |
| F67 | 10A | Left front seat heating/movement |
| F68 | 10A | Right front seat heating/movement |
