Citroën C4 Picasso 2014 Fuse Box Info
Passenger compartment fuse box location:
The fuse box is located at the left side of the steering column at the bottom of the instrument panel.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Type 1 - Passenger compartment fuse box (Fuse box 1):
| Fuse/Relay N° | Rating | Functions |
| 8 | 5A | Steering mounted controls |
| 18 | 20A | Touch screen tablet, audio and navigation system, CD player, USB ports and auxiliary sockets |
| 16 | 15A | Front 12V socket |
| 15 | 15A | Boot 12V socket |
| 28 | 5A | START/STOP button |
| 30 | 15A | Rear wiper |
| 27 | 15A | Front screenwash pump, rear screenwash pump |
| 26 | 15A | Horn |
| 20 | 5A | Airbags |
| 21 | 5A | Instrument panel |
| 19 | 5A | Rain and sunshine sensor |
| 12 | 5A | Keyless starting unit |
| 2 | 5A | Manual headlamp adjustment control |
Type 1 - Passenger compartment fuse box (Fuse box 2):
| Fuse/Relay N° | Rating | Functions |
| 9 | 15A | Rear 12V socket |
Type 2 - Passenger compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 3 | 3A | START/STOP button |
| 6A | 15A | Touch screen tablet, audio and navigation system, CD player, USB ports and auxiliary sockets |
| 8 | 5A | Alarm |
| 9 | 3A | Steering mounted controls |
| 19 | 5A | Instrument panel |
| 24 | 3A | Rain and sunshine sensor |
| 25 | 5A | Airbags |
| 33 | 3A | Memorisation of driving position |
| 34 | 5A | Electric power steering |
| 13 | 10A | Front 12V socket |
| 14 | 10A | Boot 12V socket |
| 16 | 3A | Map reading lamps in row 1 courtesy lamps |
| 27 | 5A | Electronic gearbox gear selector |
| 30 | 20A | Rear wiper |
| 38 | 3A | Manual headlamp adjustment control |
Type 1 - Engine compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 18 | 10A | Right hand main beam |
| 19 | 10A | Left hand main beam. |
Type 2 - Engine compartment fuse box (Fuse box 1):
| Fuse/Relay N° | Rating | Functions |
| 9 | 30A | Motorised tailgate |
| 18 | 25A | Hi-Fi amplifier |
| 21 | 3A | Hands-free starting reader unit |
Type 2 - Engine compartment fuse box (Fuse box 2):
| Fuse/Relay N° | Rating | Functions |
| 19 | 30A | Front wiper slow / fast speed |
| 20 | 15A | Front and rear screenwash pump |
| 21 | 20A | Headlamp wash pump |
