Chevrolet Silverado EV 2024 Fuse Box Info
Passenger compartment fuse box location:
The left instrument panel fuse box is located on the driver side of the instrument panel, between the steering wheel and the door. The right instrument panel fuse box is located behind the glove box.
Underhood compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box (Left):
| Fuse/Relay N° | Functions |
| 01 | DRIVER_PWR_ST |
| 02 | VKS_TTPM |
| 03 | VECM |
| 04 | BCM 1 – Body Control Module 1 |
| 05 | ELM 5 – Exterior Lighting Module 5 |
| 06 | PASSENGER DSP |
| 07 | SPARE |
| 08 | TCP – Telematics Control Platform |
| 09 | 4W_Co_Driver PWR LUMBAR SPARE |
| 10 | WCM_VKM – Wireless Charger Module TVR_APA_PFA |
| 11 | 2ND HTD SEAT – 2nd Row Heated Seat 2ND HTD SEAT – 2nd Row Heated Seat 1 |
| 12 | SPARE |
| 13 | TPIM TPIM 2 |
| 14 | SPARE |
| 15 | SPARE |
| 16 | Tonneau Accessory |
| 17 | SDM_AOS SRR |
| 18 | SPARE |
| 19 | SPARE |
| 20 | OBCM 2 MSM |
| 21 | HSM ROW HSM ROW 1 |
| 22 | SPARE |
| 23 | MJR END HIGH |
| 24 | TPIM 1 & VBAT 1 – Traction Power Inverter Module 1 |
| 25 | SPARE |
| 26 | TPIM 2 & VBAT 1 – Traction Power Inverter Module 1 |
| 27 | DSP |
| 28 | ELM 7 – Exterior Lighting Module 7 |
| 29 | SPARE |
| 30 | MJR END LOW |
| 31 | ELM 2 – Exterior Lighting Module 2 |
| 32 | RFR/PLCM |
| 33 | MIDGATE CONTROL LOW |
| 34 | ACP_VPM |
| 35 | AMP – Amplifier |
| 36 | CO-DRVR_PWR_ST |
| 37 | SPARE |
| 38 | ELM 6 – Exterior Lighting Module 6 |
| 39 | RT WNDW – Right Hand Power Window |
| 40 | LT WNDW – Left Hand Power Window |
| CB01 | - |
| CB02 | - |
Passenger compartment fuse box (Right):
| Fuse/Relay N° | Functions |
| 01 | FRT BLWR MTR – Front Blower Motor |
| 02 | CPM |
| 03 | SPARE |
| 04 | SPARE |
| 05 | BCM 2 – Body Control Module 2 |
| 06 | BCM 4 – Body Control Module 4 |
| 07 | COIL CLOCK SPRING |
| 08 | TBCS/EPB – Trailer Brake Control Switch/Electric Park Brake |
| 09 | ESM SPARE |
| 10 | Displays SPARE |
| 11 | CGM – Central Gateway Module SPARE |
| 12 | SPARE |
| 13 | SPARE DLC – Data Link Connection |
| 14 | BODY MISC BODY MISC 1 |
| 15 | MISC_IP 1 |
| 16 | SPARE |
| 17 | SPARE |
| 18 | BDY 1 HDLNR |
| 19 | VICM TPIM IGN – Vehicle Integration Control Module/Traction Power Inverter Module/Ignition |
| 20 | OHC HUD |
| 21 | VCU VCU 2 |
| 22 | SPARE |
| 23 | SPARE |
| 24 | FCM_RLH_UGDO |
| 25 | USB_ROW 2 |
| 26 | SPARE |
| 27 | USB |
| 28 | SPARE |
| 29 | FRT_HVAC_DIS |
| 30 | SPARE |
| 31 | BCM 3 – Body Control Module 3 |
| 32 | HSWM – Heating Steering Wheel Module |
| 33 | SPARE |
| 34 | SPARE |
| 35 | SPARE |
| 36 | SPARE |
| 37 | SPARE |
| 38 | SPARE |
| 39 | SPARE |
| 40 | SPARE |
| CB01 | APO – Auxiliary Power Outlet Center Console |
| CB02 | SPARE |
Underhood compartment fuse box:
| Fuse/Relay N° | Functions |
| 01 | - |
| 02 | - |
| 03 | - |
| 04 | - |
| 05 | - |
| 06 | ACEC – Air Conditioning Electric Compressor |
| 07 | ESSCP – Energy Storage System Coolant Pump |
| 08 | - |
| 09 | PECP – Power Electric Cooling Pump |
| 10 | - |
| 11 | - |
| 12 | - |
| 13 | TRLR_HD – Trailer Headlamps |
| 14 | - |
| 15 | VLM – Vehicle Leveling Module Spare |
| 16 | - |
| 17 | ELM 1 – Exterior lighting Module 1 |
| 18 | SADS – Semi Active Damping System TAIL LMP LT – Left Tail Lamp |
| 19 | IECL 2 – Left Internal Electrical Center 2 |
| 20 | - |
| 21 | - |
| 22 | IRM_ACM – Integrated Refrigerant Module and Air Conditioning Module |
| 23 | TAIL LMP RT – Right Tail Lamp VICMS – Vehicle Integrated Control Module |
| 24 | - |
| 25 | - |
| 26 | - |
| 27 | PKLPS_TRLR – Trailer Parklamps |
| 28 | - |
| 29 | Spare |
| 30 | PUMP_ONE |
| 31 | - |
| 32 | - |
| 33 | Spare TRLR REV LMPS – Reverse Trailer Lamps |
| 34 | TIM1 – Trailer Interface Module 1 |
| 35 | Spare |
| 36 | TPIM1_BAT2 |
| 37 | - |
| 38 | TRLR_STP_TRN_LT – Trailer Stop |
| 39 | TRLR_STP_TRN_RT |
| 40 | VLM_M |
| 41 | - |
| 42 | - |
| 43 | - |
| 44 | Spare |
| 45 | Spare |
| 46 | Spare |
| 47 | Spare |
| 48 | Spare |
| 49 | TBPM – Trailer Brake Power Module |
| 50 | Spare |
| 51 | MIDGATE MOTOR RIGHT |
| 52 | - |
| 53 | Spare |
| 54 | PFCM |
| 55 | REAR DEFOG |
| 56 | - |
| 57 | MINOR ENDGATE HIGH |
| 58 | FRNT WIPER |
| 59 | TIM2 |
| 60 | PKLPS_ID |
| 61 | Spare |
| 62 | ELM 3 |
| 63 | GLASS BREAK |
| 64 | - |
| 65 | ELM 4 |
| 66 | - |
| 67 | EMB/GRILL LIGHT |
| 68 | HDLP_LT |
| 69 | MIDGATE LEFT MOTOR |
| 70 | EBCM 1 |
| 71 | DC/AC INV |
| 72 | Spare |
| 73 | - |
| 74 | - |
| 75 | Spare |
| 76 | HDLP_RT |
| 77 | - |
| 78 | MIDGATE CROSS BAR MOTOR 2 MIDGATE CROSS BAR MOTOR 1 |
| 79 | PCV_PEEV_ALD FR RADAR/VIRTUAL KEY |
| 80 | IECR 2 |
| 81 | IECL 1 |
| 82 | - |
| 83 | - |
| 84 | V2LIM |
| 85 | Spare HVS (HIGH VOLTAGE SERVICE DISCONNECT) |
| 86 | HORN |
| 87 | FRT WSHR PMP |
| 88 | - |
| 89 | - |
| 90 | - |
| 91 | - |
