Chevrolet Malibu 2022 Fuse Box

Chevrolet Malibu 2022 Fuse Box Info



Passenger compartment fuse box location:

The instrument panel fuse box is on the driver side of the instrument panel.



Engine compartment fuse box location:



Fuse Box Diagram | Layout



Passenger compartment fuse box:

Fuse/Relay N° Functions
Fuses
1 Left power windows
2 Right power windows
3 -
4 Heating, ventilation, and air conditioning blower
5 Body control module 2 (without Stop/Start option)
6 Left rear heated seat
7 Right rear heated seat
8 Body control module 3
9 -
10 Body control module 2 (with Stop/Start option)
11 -
12 -
13 -
14 -
15 Transmission control module (with Stop/ Start option)
16 Amplifier
17 Seat power lumbar
18 -
19 -
20 Body control module 1 (without Stop/Start option)
21 Body control module 4
22 -
23 Electric steering column lock
24 Sensing and diagnostic module/Automatic occupant sensing (Airbag)
25 Data link connector
26 -
27 AC DC inverter
28 -
29 Body control module 8
30 Overhead console
31 Steering wheel controls
32 -
33 Heating, ventilation, and air conditioning
34 Central gateway module
35 -
36 Wireless charger/USB charger
37 -
38 OnStar
39 Display
40 Obstacle detection
41 Body control module 1 (with Stop/Start option)
42 Radio
43 -
44 Console accessory power outlet – rear
Relays
K1 -
K2 Interruptible retained accessory power
K3 -
K4 -
K5 -



Engine compartment fuse box:

Fuse/Relay N° Functions
Fuses
1 -
2 -
3 Antilock brake system pump/Electric brake booster
5 -
6 Rear closure
7 -
8 Memory seat module
9 -
10 -
11 DC DC converter 1
12 Rear window defogger
13 Heated mirrors
14 -
15 Passive entry/Passive start
16 Front wiper
17 Passenger power seat
18 Antilock brake system valve
19 Driver power seat
21 Sunroof
22 Parking lamp
23 Automatic headlamp leveling/Adaptive forward lighting
24 -
26 Transmission control module/Ignition
27 Instrument panel/ Body/Ignition
28 -
29 Rear vision camera/ Ventilated seats
30 Malfunction indicator lamp/Ignition
32 Canister vent solenoid/Evap leak check module
33 Front heated seat
34 -
35 Body control module 6/Body control module 7
36 Fuel module
38 -
39 -
40 Steering column lock
41 -
43 Heated steering wheel
44 Headlamp leveling
45 -
46 Engine control module/Ignition
47 -
48 -
49 DC DC converter 2
50 -
51 -
52 -
53 -
54 -
55 -
56 Starter motor
57 -
58 -
59 High-beam headlamps Left/Right
60 Cooling fan
61 -
62 -
63 -
65 Air conditioning
67 -
68 -
69 -
70 -
72 Starter pinion
74 -
75 Engine control module main
76 Engine control module sense
78 Horn
79 Washer pump
81 Transmission control module/Engine control module
82 -
83 Ignition coil
84 Powertrain on engine
85 Shunt
86 Shunt
87 -
88 Aeroshutter
89 -
91 -
92 -
93 Active headlamp leveling
95 -
96 -
97 -
99 Coolant pump
Relays
4 -
20 Rear window defogger
25 Front wiper control
31 Run/Crank
37 Front wiper speed
42 -
64 Starter motor
66 Powertrain
71 -
73 Air conditioning
80 Starter pinion
90 -
94 -
98 -
