Chevrolet Malibu 2000 Fuse Box Info
Passenger compartment fuse box location:
The left instrument panel fuse box is located on the driver side edge of the instrument panel.
The right instrument panel fuse box is located on the passenger side edge of the instrument panel.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box (Left):
| Fuse/Relay | Functions |
| A | Radio |
| B | Wipers |
| C | Trunk Release and Remote Lock Control |
| D | Turn Signals |
| E | Power Mirrors |
| F | Air Bag |
| G | Body Function Control Module |
| H | Powertrain Control Module |
| J | Door Locks |
| K | Body Function Control Module, Cluster |
| STOP LPS | Stoplamps |
| HAZARD LPS | Hazard Lamps |
| IPC/HVAC BATT | Cluster, Climate Control |
| MICRO RELAY TRUNK REL | Remote Trunk Release |
| CIRCUIT BRKR PWR SEATS | Power Seats |
| MICRO RELAY DR UNLOCK | Door Locks |
| MICRO RELAY DR LOCK | Door Locks |
| MICRO RELAY DRIVERS DR UNLOCK | Not Used |
Passenger compartment fuse box (Right):
| Fuse/Relay | Functions |
| A | Instrument Panel Lights, Dimmer |
| B | Cruise Control Switches |
| C | Climate Control System |
| D | Cruise Control |
| E | Fog Lamps |
| F | Interior Lamps, Body Function Control Module |
| G | Radio |
| H | Sunroof |
| CIRCUIT BRKR PWR WNDWS | Power Windows |
| MICRO RELAY FOG LPS | Fog Lamps |
Engine compartment fuse box:
| Fuse/Relay N° | Functions |
| Maxi Fuses | |
| 1 | Ignition Switch |
| 2 | Right Electrical Center-Fog Lamps, Radio, Body Function Control Module, Interior Lamps |
| 3 | Left Electrical Center-Stoplamps, Hazard Lamps, Body Function Control Module, Cluster, Climate Control System |
| 4 | Anti-Lock Brakes |
| 5 | Ignition Switch |
| 6 | A.I.R. |
| 7 | Left Electrical Center-Power Seats, Power Mirrors, Door Locks, Trunk Release and Remote Lock Control |
| 8 | Cooling Fan #1 |
| Mini Relays | |
| 9 | Rear Defog |
| 10 | A.I.R. |
| 11 | Not Used |
| 12 | Cooling Fan #1 |
| 13 | HVAC Blower (Climate Control) |
| 14 | Cooling Fan #2 |
| 15 | Cooling Fans |
| Micro Relays | |
| 16 | Air Conditioning Compressor |
| 17 | Not Used |
| 18 | Fuel Pump |
| 19 | Automatic Light Control |
| 20 | Automatic Light Control |
| 21 | Horn |
| 22 | Daytime Running Lamps |
| Mini Fuses | |
| 23-32 | Spare Fuse Holder |
| 33 | Rear Defog |
| 34 | Accessory Power Outlets, Cigar Lighter |
| 35 | Generator |
| 36 | Not Used |
| 37 | Air Conditioning Compressor, Body Function Control Module |
| 38 | Automatic Transaxle |
| 39 | Powertrain Control Module, Ignition |
| 40 | Anti-Lock Brakes |
| 41 | Ignition System |
| 42 | Back-Up Lamps, Brake Transaxle Shift Interlock Control |
| 43 | Horn |
| 44 | Powertrain Control Module |
| 45 | Parking Lamps |
| 46 | Climate Control System |
| 47 | Canister Purge Valve, Powertrain Control Module, Exhaust Gas Recirculation, Heated O2 Sensor |
| 48 | Fuel Pump Injectors |
| 49 | Not Used |
| 50 | Right Headlamp |
| 51 | Left Headlamp |
| 52 | Cooling Fan |
| 53 | HVAC Blower (Climate Control ) |
| 54 | Not Used |
| 55 | Cooling Fan #2 Ground |
| 56 | Fuse Puller |
| 57 | Not Used |
