Buick Roadmaster 1995 Fuse Box Info
Passenger compartment fuse box location:
The fuse box in the passenger compartment is located on the driver's side, between the door and the instrument panel.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° | Functions |
| 7 | Not Used |
| 8 | Rear Window Wiper |
| 9 | Radio |
| 10 | Windshield Wiper/Washer Switch |
| 11 | Rear Defog Relay, Inflatable Restraint Diagnostic Energy Reserve (with Sensor) Module, Headlamp Switch, I/P Cluster, Rear Defog Switch |
| 12 | Turn Signal Lamp Flasher, Backup Lamp/Transmission Position Sensor (PNP) Switch, Shift Interlock (BTSI) |
| 13 | Inside Rearview Mirror, Warning Alarm, Cruise Control Release Switch, Headlamp Auto Control Module, Daytime Running Lamp Control Module, Remote Control Door Lock Receiver, Automatic Level Control Sensor |
| 14 | Theft Deterrent Module |
| 15 | Inflatable Restrain Diagnostic Energy Reserve (with Sensor) Module |
| 16 | Cruise Control Module, Cruise Control Switch, Cruise Control Release Switch |
| 17 | Heater A/C Control, Low Blower Module Relay |
| 18 | Power Steering Control Module, Heated Seats Control |
| 20 | Electric Actuator, Vacuum Electric Solenoid, Heater A/C Control, Instrument Cluster, Daytime Running Lamps |
| 21 | Not Used |
| 22 | Not Used |
| 24 | Inflatable Restrain Diagnostic Energy Reserve (with Sensor) Module, Theft Deterrent Relay |
| 26 | Not Used |
| 27 | Auto Level Control Sensor, Rear Compartment Courtesy Lamp, Mercury Switch |
| 28 | Cigar Lighter |
| 29 | Remote Control Door Lock Receiver, Liftgate Wiper Latch Switch, Rear Glass Release Switch, Rear Compartment Lid Release Switch, Rear Glass Release Relay, Rear Compartment Release Relay |
| 30 | Radio |
| 31 | Headlamp Switch, Headlamp Auto Control Module, Daytime Running Lamps Control Module |
| 32 | Horn Relay |
| 33 | Warning Alarrn, I/P Compartment Lamp Switch, I/P Compartment Lamp, I/P Cluster, Heater and A/C Control |
| 34 | Theft Deterrent Module |
| 35 | Courtesy Lamp Relay, Front Door Lock Switches, Front Door Courtesy Lamps, Rear Door Courtesy Lamps, Outside Remote Control Rearview Mirror Switch, Inside Rearview Mirror, Sunshade Illuminated Mirrors, IP Door Lamps, Roof Rail Courtesy Lamp |
| 36 | Rear Window Wiper Motor, Rear Compartment Lid Pulldown Actuator |
| 37 | Stoplamp Switch, Hazard Lamp Flasher |
| 38 | Blower Motor Control Module |
| 39 | Power Door Lock Relay |
| 40 | Heated Seat Controls |
| 41 | Turn Signal Switch, Sidemarker Lamps, Turn/Parking Lamps |
| 42 | Heater and A/C Control , Headlamp Switch, Instrument Cluster, Radio |
| 43 | Opera Lamps, License Lamp, Marker Lamps, Inboard Tailamps, Outboard Tail/Turn Stoplamps, Inboard Tail/Turn Stoplamps |
| 44 | Heated Power Mirrors |
| 45 | Not Used |
| Circuit Breakers | |
| 1 | Power Antenna Relay, Power Seats |
| 2 | Master Power Window Switch, Power Window Lockout Switch, Power Window Control Module |
| 3 | Driver’s and Passanger’s Power Seat Switches, LH and RH Recline Switches, LH and RH Lumbar Switches |
| 4 | Rear Window Defog Switch, Rear Window Defog Relay |
Engine compartment fuse box:
| Fuse/Relay N° | Functions |
| 1 | Auto Level Control Air Compressor |
| 2 | Fuel Pump Relay, Fuel Pump Switch and Engine Oil Pressure Sensor, PCM |
| 3 | Secondary Air Pump Relay, Underhood Lamp |
| 4 | Mass Air Flow Sensor, Secondary Air Pump Relay, EGR Solenoid, Evaporative Emission Solenoid, Oxygen Sensors, Automatic Transmission |
| 5 | PCM, Ignition Coil, Electronic Brake Control Module |
| 6 | Fuel Injector Cylinders One, Four, Six, Seven |
| 7 | Primary Cooling Fan, A/C Compressor Relay |
| 8 | Generator, Secondary Cooling Fan |
| 9 | Fuel Injector Cylinders Two, Three, Five, Eight |
| A | Primary Cooling Fan Relay |
| B | Secondary Cooling Fan Relay |
| C | Air Pump Relay |
| E | Fuel Pump Relay |
| F | Air Conditioning Compressor Relay |
