Audi A3 2011 Fuse Box

Audi A3 2011 Fuse Box Info


Passenger compartment fuse box location:

The instrument panel fuse box is located on the end of the instrument panel on the driver’s side of the vehicle.


Engine compartment fuse box location:



Fuse Box Diagram | Layout


Passenger compartment fuse box:

Fuse/Relay N° Rating Functions
1 10A Manual headlight beam adjustment, automatic headlight beam adjustment, AFS control module, engine components, light switch (switch lighting/illumination), diagnosis socket
2 10A Automatic transmission, control module for CAN data transfer (gateway), electro-mechanical steering, shift gate automatic transmission engine relay, fuel tank control unit, engine control unit, brakes control (ABS), Electronic Stabilization Program (ESP), Anti-Slip Regulation (ASR)
3 5A Airbag
4 5A Air-conditioning (pressure sensor, air quality sensor), button for Electronic Stabilization Program (ESP), Anti-Slip Regulation (ASRI), tire pressure monitor dysplay, oil level sensor, back-up light switch, front seat heating, parking aid, seat-occupancy recognition (on USA vehicles), garage door opener, automatic mirror dimming, headlight assistant, heated windshield washer nozzles, air conditioning (control module)
5 5A AFS headlights (left side)
6 5A AFS headlights (right side)
7 - Not used
8 - Not used
9 15A Navigation system, radio system
10 7.5A Digital radio, cell phone, TV equipment
11 10A Automatic mirror dimming, headlight assistant
12 10A Central locking (front doors)
13 10A Central locking (rear doors)
14 10A Electronic Stabilization Program (ESP) (control module), shift gate automatic transmission
15 10A Interior lights, reading lights
16 10A Diagnostic connector, rain sensor, air conditioning (control module), tire pressure monitor display (control module)
17 5A Anti-theft alarm warning system
18 5A Diagnose Starter
19 10A All Wheel Drive
20 - Not used
21 - Not used
22 40A Blower fan
23 30A Driver's side power window, front
24 20A Power outlet front
25 30A Rear window defogger
26 20A Power outlet in luggage compartment
27 15A Fuel tank control module, fuel pump
28 30A Power window, rear
29 - Not used
30 - Not used
31 - Not used
32 - Not used
33 20A Sliding/pop-up roof
34 - Not used
35 - Not used
36 10A Lumbar support
37 20A Heated seats, front
38 30A Passenger side power window, front
39 5A Special function interface
40 40A Starter
41 15A Rear window wiper
42 - Not used
43 20A Body control module
44 - Not used
45 - Not used
46 - Not used
47 5A Cell phone package (VDA interface)
48 - Not used
49 - Not used


Engine compartment fuse box:

Fuse/Relay N° Rating Functions
1 40A Terminal 30
2 20A Engine components
3 5A Battery voltage
4 20/30A ESP valve, Anti-lock brake system (ABS) valves
5 15A Transmission control module
6 5A Steeling wheel electronics
7 - Not used
8 - Not used
9 - Not used
10 5/10A Engine control module, main relay
11 - Not used
12 5A Control module for CAN data transfer (gateway)
13 15/25A Engine control module
14 20A Ignition coils, engine components (diesel engine)
15 5/10A Preheating control module/engine component, tank diagnosis, oxygen sensor
16 30A Body control module (right)
17 15A Horn
18 30A Audio amplifier
19 30A Front windshield wiper system
20 10/20A Water pump, volume regulator valve
21 10A Oxygen sensor, vacuum pump
22 5A Clutch pedal switch, brake light switch
23 5/10/15A Engine components, water pump
24 10A Engine components, water pump
25 30/40A Pump (ESP/ABS), ABS valve
26 30A Body control module (left)
27 40A Secondary air pump, preheating control module
28 - Not used
29 50A Fuse assignment in the left-side instrument panel (special equipment)
30 50A Power supply relay terminal 15
