Audi A3 2020 Fuse Box

Audi A3 2020 Fuse Box Info



Passenger compartment fuse box location:

The instrument panel fuse box is located behind a cover near the steering column.



Engine compartment fuse box location:





Fuse Box Diagram | Layout



Passenger compartment fuse box:

Fuse/Relay N° Functions
1 Engine components, AdBlue
2 Seat adjustment
4 Infotainment control panel, Infotainment components
5 Gateway
6 Selector lever (automatic transmission), steering lock
7 Air conditioning/heating controls, auxiliary heating, rear window defogger relay, tire pressure monitor
8 Electromechanical parking brake switch, light switch, rain/light sensor, anti-theft alarm system, diagnostic connector, roof module, emergency cali system, headlight range control
9 Steering column switch module
10 Infotainment system display
11 Left vehicle electrical system control module, airbag
12 Infotainment components
13 Driver's side safety belt tensioner, airbag
14 Heating and A/C system blower control
15 Electronic steering column lock, convenience access control module
16 TV tuner, telephone antenna
17 Instrument cluster
18 Rearview camera
19 Vehicle positioning
20 Engine components, AdBlue, charging system
21 Steering column, steering wheel heating switch module
24 Right vehicle electrical system control module
25 Driver's side front/rear power windows
26 Seat heating
27 Vehicle electrical system control module
28 Power top control module
29 Vehicle electrical system control module, interior lighting
30 Diagnostic connector
32 Front camera, parking system, ACC sensor, lane change assist
33 Airbag
34 Hold assist button, interior sound, back-up light switch, temperature sensor, neck heating relay coil and socket relay, power top operation button
35 Air quality sensor, automatic dimming rearview mirror, diagnostic connector, center console power supply
36 Right headlight (LED, Matrix LED)
37 Left headlight (LED, Matrix LED)
38 High-voltage battery
39 Passenger's side front/rear power windows
40 Cigarette lighter, sockets
41 Passenger's side safety belt tensioner
42 Central locking area
44 All wheel drive
45 Driver's side seat adjustment
47 Rear window wiper
48 Outer sound actuator
49 Clutch sensor, engine start, high-voltage battery, power electronics
52 Level control system control module
53 Rear window defogger



Engine compartment fuse box:

Fuse/Relay N° Functions
3 Engine control module
4 Engine components, engine cooling, auxiliary heater, exhaust treatment
5 Engine components, fuel tank system (diesel), CNC cut-off valve
6 Brake light switch
7 Engine components, water pumps, tank system (gasoline engine), electrification
8 Heat oxygen sensor
9 Engine components, exhaust door, glow time control module
10 Fuel control module, fuel pump
13 Transmission fluid pump
15 Horn
16 Power and control electronics, engine components, ignition coil, options module
17 Electronic Stabilization Control (ESC), engine control module
18 Terminal 30 (voltage reference), battery monitoring
19 Windshield wipers
20 Anti-theft alarm system
21 Automatic transmission
22 Terminal 50 diagnosis, engine control module
23 Engine start
31 Vacuum pump, water pump, high pressure pump, fuel injectors
33 Brake pressure reservoir, recuperation
34 Brake booster
35 Climate control system
36 Left front headlamp
37 Parking heater
38 Right front headlamp
