Acura Integra 2001 Fuse Box

Acura Hits: 493

Acura Integra 2001 Fuse Box Info

Passenger compartment fuse box location:

The fuse box is located underneath the dashboard on the driver's side, behind the cover.

Engine compartment fuse box location:

Fuse Box Diagram | Layout

Passenger compartment fuse box:

Fuse/Relay N°	Rating	Functions
1	7.5A	Inter Lock Unit
2	10A	Licence Plate Light, Taillight
3	7.5A	Starter Signal
4	7.5A	Instrument Panel Light
5	-	Not Used
6	10A	Radio
7	10A	Cigarette Lighter
8	20A	Front Wiper, Front Washer
9	7.5A	Meter
10	7.5A	Power Window Relay, Moonroof Relay
11	10A	SRS
12	-	Spare
13	10A	Left Headlight Low Beam
14	10A	Right Headlight Low Beam
15	-	Not Used
16	7.5A	Back-up Light
17	-	Not Used
18	7.5A	Heater A/C Relay
19	7.5A	Rear Defroster Relay
20	7.5A	Alternator, Speed Sensor
21	7.5A	Cruise Control
22	15A	Fuel Pump, SRS Unit
23	10A	Turn Signal Light
24	-	Spare
25	-	Spare
26	-	Spare
27	20A	Front Left Power Window
28	20A	Front Right Power Window
29	15A	Ignition Coil
30	20A	Rear Right Power Window
31	20A	Rear Left Power Window
32	-	Not Used
33	10A	Left Headlight High Beam
34	10A	Right Headlight High Beam
35	-	Not Used
36	-	Not Used
37	20A	Power Door Lock
38	-	Spare

Engine compartment fuse box:

Fuse/Relay N°	Rating	Functions
1	100A	Battery
2	40A	Ignition 1
3	-	Not Used
4	40A	Power Window
5	30A	Headlight
6	30A	Door Lock, Moonroof
7	40A	Rear Defroster
8	40A	Option
9	40A	Heater Motor
10	7.5A	Interior Light
11	15A	FI E/M (ECM)
12	7.5A	Back Up, Radio
13	15A	Small Light
14	20A	Magnetic Clutch (A/C), Condenser Fan (A/C)
15	20A	Cooling Fan
16	20A	Horn, Stop Light
17	10A	Hazard

Engine compartment fuse box (ABS fuse box):
