Acura ILX 2022 Fuse Box Info
Passenger compartment fuse box location:
The interior fuse box is located under the dashboard.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | - | - |
| 2 | 15A | ACG |
| 3 | 10A | SRS |
| 4 | 15A | Fuel Pump |
| 5 | 7.5A | Meter |
| 6 | 7.5A | Power Window |
| 7 | 15A | VB SOL |
| 8 | 15A | Right Door Lock Motor (Unlock) |
| 9 | 15A | Left Door Lock Motor (Unlock) |
| 10 | (15A) | Audio* |
| 11 | 20A | Moonroof |
| 12 | (20A) | Driver’s Power Seat Sliding |
| 13 | (20A) | Driver’s Power Seat Reclining |
| 14 | (20A) | Seat Heaters |
| 15 | 10A | Driver’s Door Lock Motor (Unlock) |
| 16 | (20A) | Passenger’s Power Seat Sliding* |
| 17 | (20A) | Passenger’s Power Seat Reclining* |
| 18 | 10A | Driver’s Power Lumbar |
| 19 | 7.5A | Accessory |
| 20 | 7.5A | ACC Key Lock |
| 21 | 7.5A | Daytime Running Lights |
| 22 | 7.5A | HAC |
| 23 | - | - |
| 24 | 7.5A | ABS/VSA |
| 25 | 7.5A | ACC |
| 26 | - | - |
| 27 | 20A | Accessory Power Socket |
| 28 | - | - |
| 29 | 7.5A | ODS |
| 30 | 10A | Driver’s Door Lock Motor (Lock) |
| 31 | 10A | SMART |
| 32 | 15A | Right Door Lock Motor (Lock) |
| 33 | 15A | Left Door Lock Motor (Lock) |
| 34 | 7.5A | Small Lights |
| 35 | 7.5A | Illumination |
| 36 | - | - |
| 37 |
(30A)*1 (20A)* |
Premium Audio* |
| 38 | 10A | Left Headlight High Beam |
| 39 | 10A | Right Headlight High Beam |
| 40 | - | - |
| 41 | 20A | Door Lock |
| 42 | 20A | Driver’s Power Window |
| 43 | 20A | Rear Passenger’s Side Power Window |
| 44 | 20A | Front Passenger’s Side Power Window |
| 45 | 20A | Rear Driver’s Side Power Window |
| 46 | - | - |
* Not available on all models
*1: Model with Navigation system
Engine compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 |
70A - 30A 40A 30A 120A |
EPS - ABS/VSA FSR ABS/VSA Motor WIPER Main Fuse |
| 2 |
50A 60A 60A 30A 30A 30A 30A 40A 30A 20A 20A |
IG Main Fuse Box Main Fuse Box Main 2 Headlight Main ST/MG SW Rear Defogger IG Main1 Blower IG Main2 Sub Fan Motor Main Fan Motor |
| 3 | - | - |
| 4 | - | - |
| 5 | 7.5A | Starter DIAG |
| 6 | - | - |
| 7 | - | - |
| 8 | - | - |
| 9 | - | - |
| 10 | - | - |
| 11 | 7.5A | Oil Level |
| 12 | (20A) | Fog Lights* |
| 13 | 20A | Injector |
| 14 | 10A | Hazard |
| 15 | 15A | FI Sub |
| 16 | 15A | IG Coil |
| 17 | 7.5A | Daytime Running Lights |
| 18 | 10A | Stop & Horn |
| 19 | - | - |
| 20 | 10A | Right Headlight Low Beam |
| 21 | 15A | IGP |
| 22 | 15A | DBW |
| 23 | 10A | Left Headlight Low Beam |
| 24 | - | - |
| 25 | 7.5A | MG Clutch |
| 26 | 15A | Washer |
| 27 | 20A | Small |
| 28 | 7.5A | Interior Lights |
| 29 | 10A | Backup |
* Not available on all models
