Acura ILX 2015 Fuse Box Info
Passenger compartment fuse box location:
The interior fuse box is located under the dashboard.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | - | - |
| 2 | 15A | ACG |
| 3 | 10A | SRS |
| 4 | 15A | Fuel Pump |
| 5 | 7.5A | Meter |
| 6 | 7.5A | Power Window |
| 7 | 15A | VB SOL* |
| 8 | 15A | Door Lock Motor 2 (Unlock) |
| 9 | 15A | Door Lock Motor 1 (Unlock) |
| 10 | - | - |
| 11 | 20A | Moonroof* |
| 12 | (15A) | Driver’s Power Seat Sliding* |
| 13 | (20A) | Driver’s Power Seat Reclining* |
| 14 | (15A) | Seat Heaters* |
| 15 | 10A | Driver’s Door Lock Motor (Unlock) |
| 16 | - | - |
| 17 | - | - |
| 18 | - | - |
| 19 | 7.5A | ACC |
| 20 | 7.5A | ACC Key Lock |
| 21 | 7.5A | Daytime Running Lights |
| 22 | 7.5A | HAC |
| 23 | - | - |
| 24 | 7.5A | ABS/VSA |
| 25 | 7.5A | ACC |
| 26 | - | - |
| 27 | 20A | Accessory Power Socket |
| 28 | - | - |
| 29 | 7.5A | ODS |
| 30 | 10A | Driver’s Door Lock Motor (Lock) |
| 31 | 10A | SMART |
| 32 | 15A | Door Lock Motor 2 (Lock) |
| 33 | 15A | Door Lock Motor 1 (Lock) |
| 34 | 7.5A | Small Lights |
| 35 | 7.5A | Illumination |
| 36 | - | - |
| 37 | (20A) | Premium Audio* |
| 38 | 10A | Left Headlight High Beam |
| 39 | 10A | Right Headlight High Beam |
| 40 | (7.5A) | TPMS* |
| 41 | 20A | Door Lock |
| 42 | 20A | Driver’s Power Window |
| 43 | (20A) | Rear Passenger’s Side Power Window |
| 44 | 20A | Front Passenger’s Side Power Window |
| 45 | 20A | Rear Driver’s Side Power Window |
| 46 | - | - |
* Not available on all models
Engine compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 |
70A - 30A 30A 30A 100A |
EPS - ABS/VSA Motor ABS/VSA FSR WIPER Main Fuse |
| 2 |
50A 60A 60A 30A 30A 30A - 40A - 20A 20A |
IG Main Fuse Box Main Fuse Box Main 2 Headlight Main ST/MG SW Rear Defogger - Blower - Sub Fan Motor Main Fan Motor |
| 3 | - | - |
| 4 | - | - |
| 5 | 7.5A | Starter DIAG, ST MG |
| 6 | - | - |
| 7 | - | - |
| 8 | - | - |
| 9 | - | - |
| 10 | - | - |
| 11 | 7.5A | Oil Level |
| 12 | (20A) | Fog Lights* |
| 13 | - | - |
| 14 | 10A | Hazard |
| 15 | 15A | FI Sub |
| 16 | 15A | IG Coil |
| 17 | 15A | Stop |
| 18 | 10A | Horn |
| 19 | - | - |
| 20 |
10A 15A |
Right Headlight Low Beam*1 Right Headlight Low Beam (HID)*2 |
| 21 | 15A | IGP |
| 22 | 15A | DBW |
| 23 |
10A 15A |
Left Headlight Low Beam*1 Left Headlight Low Beam (HID)*2 |
| 24 | - | - |
| 25 | 7.5A | MG Clutch |
| 26 | 15A | WASHER |
| 27 | 20A | SMALL |
| 28 | 7.5A | Interior Lights |
| 29 | 10A | Backup |
* Not available on all models
*1: Models with halogen bulb low beam headlights
*2: Models with discharge headlights
