Acura ZDX 2012 Fuse Box Info
Passenger compartment fuse box location:
The interior fuse box A is located under the dashboard on the driver’s side. The interior fuse box B is located on the lower passenger’s side panel.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box A (Driver’s side):
| Fuse/Relay N° | Rating | Functions |
| 1 | 7.5A | Front Seat Heaters and Seat Ventilation/Blind Spot Information* |
| 2 | 7.5A | SH-AWD/Headlight Adjuster |
| 3 | 20A | Washer |
| 4 | 7.5A | Wiper |
| 5 | 7.5A | OPDS |
| 6 | 7.5A | VSA |
| 7 | - | Not Used |
| 8 | 7.5A | STRLD |
| 9 | 20A | Fuel Pump |
| 10 | 10A | VB Solenoid |
| 11 | 10A | SRS |
| 12 | 7.5A | Meter |
| 13 | 15A | ACG |
| 14 | - | Not Used |
| 15 | 7.5A | Daytime Running Lights |
| 16 | 7.5A | Climate Control System |
| 17 | 7.5A | Accessory Key Lock* |
| 18 | 7.5A | Accessory |
| 19 | 20A | Left Power Seat Slide |
| 20 | 20A | Panoramic Glass Roof |
| 21 | 20A | Left Power Seat Reclining |
| 22 | 20A | Rear Left Power Window |
| 23 | 15A | Accessory Power Socket (Console Box) |
| 24 | 20A | Left Front Power Window |
| 25 | 15A | Left Door Lock |
| 26 | 10A | Left Front Fog Light |
| 27 | 10A | Left Small Light (Exterior) |
| 28 | 10A | Left Daytime Running Light |
| 29 | 7.5A | TPMS |
| 30 | 15A | Left Headlight |
| 31 | - | Not Used |
| 32 | 7.5A | STS* |
* Not available on all models
Passenger compartment fuse box B (Passenger’s side):
| Fuse/Relay N° | Rating | Functions |
| 1 | 10A | Right Daytime Running Light |
| 2 | 10A | Right Small Light (Exterior) |
| 3 | 10A | Right Front Fog Light |
| 4 | 15A | Right Headlight |
| 5 | - | Not Used |
| 6 | 7.5A | Right Small Light (Interior) |
| 7 | - | Not Used |
| 8 | 20A | Right Power Seat Reclining |
| 9 | 20A | Right Power Seat Slide |
| 10 | 10A | Right Door Lock |
| 11 | 20A | Right Rear Power Window |
| 12 | 10A | SMART* |
| 13 | 20A | Right Front Power Window |
| 14 | - | Not Used |
| 15 | 20A | Audio Amp |
| 16 | 15A | Accessory Power Socket (Center Console) |
| 17 | - | Not Used |
| 18 | 7.5A | Power Lumbar |
| 19 | 20A | Seat Heaters |
| 20 | - | Not Used |
| 21 | - | Not Used |
| 22 | - | Not Used |
* Not available on all models
Engine compartment fuse box A (Primary):
| Fuse/Relay N° | Rating | Functions |
| 1 |
120A 40A |
BATTERY Passenger's Side Fuse Box STD |
| 2 |
- - 30A 40A 30A 30A |
Not Used Not Used Headlight Washer* Passenger's Side Fuse Box Option Right e-pretensioner* Left e-pretensioner* |
| 3 |
50A 40A - 60A 40A 30A 30A - |
IG Main Sub Fan Motor Not Used Driver's Fuse Box STD Main Fan Motor Driver's Light Main Wiper Motor Not Used |
| 4 | 40A | Heater Motor |
| 5 | 30A | Passenger's Light Main |
| 6 | - | Not Used |
| 7 | - | Not Used |
| 8 | 40A | Rear Defroster |
| 9 | 7.5A | Trailer Turn/Stop Lights |
| 10 | 15A | Stop & Horn |
| 11 | 7.5A | Trailer Small Lights |
| 12 | 30A | ADS* |
| 13 | 15A | IG Coil |
| 14 | 15A | FI Sub |
| 15 | 10A | Back Up |
| 16 | 7.5A | Interior Light |
| 17 | 15A | FI Main |
| 18 | 15A | DBW |
| 19 | 15A | Woofer |
| 20 | 7.5A | MG Clutch |
| 21 | 7.5A | Radiator Fan Timer |
* Not available on all models
Engine compartment fuse box B (Secondary):
| Fuse/Relay N° | Rating | Functions |
| 1 | 40A | VSA Motor |
| 2 | 20A | VSA FSR |
| 3 | - | Not Used |
| 4 | - | Not Used |
| 5 | 30A | SH-AWD |
| 6 | 40A | Power Tailgate Motor |
| 7 | 20A | Tilt Steering Wheel |
| 8 | 20A | Telescopic Steering Wheel |
| 9 | 15A | Hazard |
| 10 | 7.5A | Headlight Hi/Lo Solenoid |
| 11 | 7.5A | Power Management System |
| 12 | 7.5A | Smart Accessory* |
| 13 | 20A | Rear Seat Heaters |
| 14 | 20A | Sunshade |
| 15 | 20A | Power Tailgate Closer |
| 16 | - | Not Used |
| 17 | - | Not Used |
| 18 | - | Not Used |
| 19 | - | Not Used |
| 20 | - | Not Used |
| 21 | - | Not Used |
| 22 | - | Not Used |
* Not available on all models
