Ducati Panigale Superleggera V4 2020 Fuse Box Info
Fuse box location:
The fuse boxes are located above the battery.
Fuse Box Diagram | Layout
Fuse box A:
| Fuse/Relay N° | Rating | Functions |
| 1 | 5A | EMS/ABS/IMU |
| 2 | 7.5A | DASH/BBS/SMEC |
| 3 | - | - |
| 4 | - | - |
| 5 | 5A | Accessories (SW) |
| 6 | 20A | Injection relay |
| 7 | 7.5A | Diagnostics/Recharge |
| 8 | 5A | Spare |
| 9 | 7.5A | Spare |
| 10 | 20A | Spare |
Fuse box B:
| Fuse/Relay N° | Rating | Functions |
| 1 | 25A | EMS powered relays |
| 2 | 10A | Fuel pump relay |
| 3 | - | - |
| 4 | 15A | Instrument panel |
| 5 | 15A | Black Box System (BBS) |
| 6 | 25A | ABS 1 |
| 7 | 10A | ABS 2 |
| 8 | 10A | Spare |
| 9 | 15A | Spare |
| 10 | 25A | Spare |
The main fuse is located on the right side of the fuse box B, on solenoid starter.
