Ducati Streetfighter V4 S 2021 Fuse Box

Ducati Streetfighter V4 S 2021 Fuse Box Info



Fuse box location:

The fuse boxes are located above the battery.



Fuse Box Diagram | Layout



Fuse box A:

Fuse/Relay N° Rating Functions
1 5A EMS/ABS/IMU
2 7.5A DASH/BBS/SMEC
3 - -
4 - -
5 5A Accessories/SW
6 20A Injection relay
7 7.5A Diagnostics/Recharge
8 20A Spare
9 15A Spare
10 5A Spare

Fuse box B:

Fuse/Relay N° Rating Functions
1 25A EMS powered relays
2 10A Fuel pump relay
3 - -
4 15A Instrument panel
5 15A Black Box System (BBS)
6 25A ABS UBMR
7 10A ABS UBVR
8 25A Spare
9 15A Spare
10 10A Spare

Main fuse (30A) is located on solenoid starter.
