Ducati Diavel V4 2023 Fuse Box Info
Fuse box location:
Fuses are located next to the battery.
Fuse Box Diagram | Layout
Fuse box A:
| Fuse/Relay N° | Rating | Functions |
| 1 | 5A | KEY EMS / ABS / IMU |
| 2 | 7.5A | KEY2 DASH / BBS / SMEC |
| 3 | - | KEY3 Lights |
| 4 | - | KEY4 SBS |
| 5 | 5A | KEY Accessories |
| 6 | 20A | +30 IGN RELAY |
| 7 | 7.5A | +30 Diagnosis / charge |
Fuse box B:
| Fuse/Relay N° | Rating | Functions |
| 1 | 25A | +30 EMS LOAD RELAY |
| 2 | 10A | +30 FUEL PUMP RELAY |
| 3 | - | +30 Starter RELAY |
| 4 | 15A | +30 Instrument panel |
| 5 | 10A | +30 Black Box System (BBS) |
| 6 | 25A | +30 ABS UBMR |
| 7 | 10A | +30 ABS UBVR |
| Fuse/Relay N° | Rating | Functions |
| 8 | 30A | Main fuse |
| 9 | 30A | Solenoid starter fuse |
| 10 | 30A | Spare |
