Yamaha YZF-R1 2019 Fuse Box

Yamaha YZF-R1 2019 Fuse Box Info



Fuse box location:





Fuse Box Diagram | Layout



Fuse box A:

Fuse/Relay N° Rating Functions
1 7.5A Hazard fuse
2 15A Fuel injection system fuse
3 7.5A Electronic throttle valve fuse
4 7.5A Backup fuse
5 10A Sub radiator fan motor fuse
6 15A Radiator fan motor fuse
7 - Spare fuse

Fuse box B:

Fuse/Relay N° Rating Functions
1 15A Ignition fuse
2 7.5A Signaling system fuse
3 7.5A ABS ECU fuse
4 15A ABS solenoid fuse
5 7.5A Headlight fuse
6 2A Terminal fuse 1
7   Spare fuse
8 7.5A SCU fuse (YZF-R1M)

Main fuse (50A), ABS motor fuse (30A) are located under the rider seat.
