Yamaha MT-07 2021 Fuse Box Info
Fuse box location:
Fuses are located under the rider seat.
Fuse Box Diagram | Layout
Fuse box A:
| Fuse/Relay N° | Rating | Functions |
| 1 | 10A | Radiator fan motor fuse |
| 2 | 7.5A | Backup fuse |
| 3 | 10A | Fuel injection system fuse |
| 4 | 7.5A | Headlight fuse |
| 5 | 7.5A | Signaling system fuse |
| 6 | 10A | Ignition fuse |
| 7 | - | Spare fuse |
Fuse box B:
| Fuse/Relay N° | Rating | Functions |
| 7 | - | Spare fuse |
| 8 | 20A | ABS solenoid fuse |
| 9 | 30A | ABS motor fuse |
| 10 | 7.5A | Accessory fuse |
| 11 | 7.5A | ABS ECU fuse |
| 12 | 3A | Terminal fuse 1 |
Main fuse is 30A and is located under starter relay cover.
