Genesis Electrified G80 2023 Fuse Box Info
Passenger compartment fuse box location:
The fuse box is located at the left side of the steering column at the bottom of the instrument panel.
Engine compartment fuse box location:
Luggage compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay | Rating | Functions |
| Module 9 | 10A | Overhead Console, AMP, A/V & Navigation Head Unit, Driver/Passenger Power Seat Module, Inverter (Rear), Rear Seat LH/RH Heater Unit, Electro Chromic Mirror, Rear Seat Console Remote Control Switch, SDC, Smart Phone Wireless Charger, Data Link Connector |
| Module 11 | 10A | Head Lamp LH/RH, ADAS Unit (Parking), Multifunction Switch |
| Module12 | 10A | IAU, IBU |
| A/C3 | 10A | A/C Control Module, Front A/C Controller, Rear A/C Controller |
| A/BAG IND | 10A | Instrument Cluster, Overhead Console |
| E-Shifter2 | 10A | Electronic ATM Shift Dial |
| Spare | 15A | Not Used |
| Module 10 | 10A | ICU Junction Block (ESU) |
| Module 7 | 10A | Driver Door Module, Stop Lamp Switch, IBU, IAU, Multifunction Switch |
| Multi Media | 25A | A/V & Navigation Head Unit |
| Module 13 | 10A | ICU Junction Block (ESU), A/C Control Module, Front A/C Controller, Rear A/C Controller, Instrument Cluster, Head-Up Display, Security Indicator |
| Cluster | 10A | Instrument Cluster, Head-Up Display |
| IBU 2 | 10A | IBU |
| Airbag 2 | 15A | SRS Control Module, Passenger Occupant Detection Sensor |
| Presafety Seat Belt 3 |
10A | Pre-Active Seat Belt Unit |
| Module8 | 10A | Rear Corner Radar LH/RH, ECS Unit, Crash Pad Switch, ADAS Unit (Driving), ADAS Unit (Parking), Front View Camera, Front Console Switch, Steering Tilt & Telescopic Unit |
| Spare | 10A | Not Used |
| Module3 | 10A | Rear Corner Radar LH/RH, Front Console Keyboard, Rear Seat Console Remote Control Switch, VESS Unit, Steering Tilt & Telescopic Unit, Front Corner Radar LH/RH, Smart Phone Wireless Charger, Clock Spring |
| P/Window LH | 30A | Rear Power Window Module LH, Driver Power Window Module |
| Curtain | 10A | IBU |
| P/Seat PASS 2 | 25A | Passenger Power Seat Module |
| Trunk Open | 10A | Trunk Latch Motor |
| Airbag 1 | 15A | SRS Control Module |
| E-Shifter 1 | 10A | Electronic ATM Shift Dial, SCU |
| Module 4 | 10A | Driver/Passenger Power Outside Mirror, Hazard Switch, Rear Seat Console Remote Control Switch, Rain Sensor, Data Link Connector, A/C Control Module, Rear Occupant Alert (ROA) Sensor, Multifunction Switch, Passenger Power Seat Module |
| P/Seat DRV 1 | 25A | Driver Power Seat Module |
| P/Seat | 10A | Driver Lumbar Support Unit |
| Power Handle | 15A | Steering Tilt & Telescopic Unit |
| Module 5 | 15A | Driver Door Module, Driver/Passenger Power Seat Switch, Driver/Passenger Power Seat Module, PTL Unit, Driver Lumbar Support Unit |
| IBU 1 | 10A | BLE Unit, IBU, IAU, Driver/Passenger Door Outside Handle |
| Power Outlet | 20A | Armrest Power Outlet |
| P/Seat DRV 2 | 25A | Driver Power Seat Module |
| P/Seat PASS 1 | 25A | Passenger Power Seat Module |
| S/Heater DRV | 20A | Driver Power Seat Module |
| S/Heater PASS |
20A | Passenger Power Seat Module |
| Door Lock | 20A | Center Door Lock/Unlock Relay, Driver Door Unlock Relay |
| Spare | 10A | Not Used |
| Module 2 | 10A | CDM, P/R Junction Block (Blower Relay, Rear Heated Relay) |
| Module 6 | 10A | Armrest Lamp, IBU, A/V & Navigation Head Unit, IAU, ADAS Unit (Parking), Front Console Keyboard, Electronic ATM Shift Dial, Front Tray Lamp, VESS Unit, Rear Seat Console Remote Control Switch, AMP, Rear Console USB Charger |
| Brake Switch | 10A | Stop Lamp Switch, IBU |
Engine compartment fuse box:
| Fuse/Relay | Rating | Functions |
| LDC | 225A | ICCU (LDC) |
| B+5 | 150A | P/R Junction Block (Fuse(EWP 1, EWP 2, EOP 1, HEAD LAMP LH, HEAD LAMP RH, VCU 2)), PCB Block (Fuse(IG1, IG2, IG3 1, ACC)) |
| MDPS 1 | 125A | MDPS Unit |
| COOLING FAN | 100A | Cooling Fan Motor |
| REAR HEATED | 80A | Rear Heated Relay |
| IEB 1 | 60A | IEB Unit |
| IEB 2 | 60A | IEB Unit |
| BLOWER | 50A | Blower Relay |
| IEB 3 | 50A | IEB Unit |
| E-SHIFTER | 40A | E-Shifter Relay |
| VCU 1 | 30A | VCU |
| WIPER | 30A | Wiper Motor |
| HEAD LAMP LH | 30A | Head Lamp LH |
| EOP 1 | 40A | Electronic Traction Motor Oil Pump (Front) |
| HEAD LAMP RH | 30A | Head Lamp RH |
| EOP 2 | 40A | Electronic Traction Motor Oil Pump (Rear) |
| OBC | 10A | VCMS, ICCU |
| HORN | 15A | PCB Block (Horn Relay) |
| INVERTER 1 | 10A | Inverter (Front) |
| BMS | 15A | BMU |
| HTD IND | 10A | Front A/C Controller |
| EWP 2 | 20A | Electronic Water Pump (BSA) |
| EWP 1 | 20A | Electronic Water Pump (Radiator) |
| VCU 2 | 20A | VCU |
| IG1 | 30A | IG1 Relay |
| IG3 1 | 30A | IG3 Relay |
| IG2 | 30A | IG2 Relay |
| ACC | 30A | ACC Relay |
| VCU 4 | 10A | VCU |
| Module 1 | 10A | Front Radar, Front Corner Radar LH/RH, Inverter (Front) |
| Sensor 5 | 10A | VESS Unit |
| MDPS 2 | 10A | MDPS Unit |
| IEB 4 | 10A | IEB Unit |
| Active Hood | 10A | Not Used |
| IG3 3 | 10A | Electronic Traction Motor Oil Pump (Rear), Inverter (Rear), SCU, ICU Junction Block (IPS Control Module), VCU, VCMS |
| IG3 6 | 10A | ICU Junction Block (ESU), Front A/C Controller, Rear A/C Controller, Instrument Cluster, A/V & Navigation Head Unit, Coolant Valve, A/C Control Module, A/C PTC Heater, Incar Temperature Sensor, Electronic A/C Compressor, Cooling Fan Motor, Vehicle Charger Indicator |
| IG3 7 | 10A | BMU, Electronic Traction Motor Oil Pump (Front), ICCU |
| EWP 3 | 15A | Electronic Water Pump (PEM) |
| IG3 2 | 10A | Inverter (Front) |
| IG3 4 | 10A | CDM, VESS Unit, Electronic Water Pump (Radiator), Electronic Water Pump (BSA), Coolant 3Way Valve (BSA) |
| Washer | 15A | Washer Relay |
Luggage compartment fuse box::
| Fuse/Relay | Rating | Functions |
| B+4 | 50A | ICU Junction Block (Fuse(P/Seat PASS 2, Module 4, Door Lock, Trunk Open)) |
| B+2 | 30A | ICU Junction Block (Fuse(IBU 1, E-Shifter 1, Spare (B+), Module 2, Module 5 |
| B+1 | 50A | ICU Junction Block (Fuse(Brake Switch), IPS1, IPS3, IPS4, IPS7, Long/Short Term Load Latch Relay) |
| B+3 | 50A | ICU Junction Block (Fuse(P/Seat, Curtain, P/Window LH, S/Heater DRV, S/Heater PASS, P/Seat DRV 1, P/Seat DRV 2, P/Seat PASS 1, Power Handle)) |
| Charger | 15A | Charging Connector Lock/Unlock Relay |
| P/Window RH | 30A | Rear Power Window Module RH, Passenger Power Window Module |
| AMP | 25A | AMP |
| P/Door RL | 15A | Rear Door Latch LH |
| Solar Charger 2 | 15A | SDC |
| P/Door PASS | 15A | Passenger Door Latch |
| Solar Charger 1 | 20A | SDC |
| Presafety Seat Belt 1 |
30A | Pre-Active Seat Belt Unit |
| P/Door RR | 15A | Rear Door Latch RH |
| ECS | 15A | ECS Unit |
| P/Door DRV | 15A | Driver Door Latch |
| Presafety Seat Belt 2 |
30A | Pre-Active Seat Belt Unit |
| Child Lock | 15A | Child Lock/Unlock Relay |
| Inverter 2 | 10A | Inverter (Rear) |
| S/Heater Rear LH |
20A | Rear Seat LH Heater Unit |
| Power Trunk | 30A | PTL Unit (Power Trunk Lid) |
| S/Heater Rear RH |
20A | Rear Seat RH Heater Unit |
Battery fuse box panel:
| Fuse/Relay | Rating | Functions |
| B+8 | 100A | Rear Junction Block (Fuse(B+2, B+4, Solar Charger 1, P/Door Rear LH, P/Door Rear RH, Presafety Seat Belt 2)) |
| B+7 | 100A | Rear Junction Block (Fuse(B+3, S/Heater Rear LH, Child Lock, S/Heater Rear RH, Power Trunk, P/Door DRV, P/Door PASS)) |
| B+6 | 100A | Rear Junction Block (Fuse(B+1, AMP, P/Window RH, ECS, Presafety Seat Belt 1, Charger)) |
| AMS | 10A | 12V Battery Sensor |
