Holden Commodore 2012 Fuse Box Info
Passenger compartment fuse box location:
The instrument panel fuse box is located in the left hand side kick panel.
Engine compartment fuse box location:
Luggage compartment fuse box location:
The rear fuse box is located on the left hand side of the boot, above the battery.
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| Circuit breakers | ||
| 1 | 20A | POWER WINDOWS BATTERY |
| 2 | 20A | POWER WINDOWS RAP |
| 3 | 20A | POWER SEATS |
| 4 | - | SPARE |
| Fuses | ||
| 1 | 10A | AIRBAGS |
| 2 | 10/30A | REAR END RELEASE |
| 3 | 25A | DOOR LOCKS |
| 4 | 15A | INADVERT POWER/LED DIM |
| 5 | 15A | COURTESY LIGHTS/RT FT TURN LIGHT |
| 6 | 15A | RT RR TURN LIGHT/RT SIDE INDICATOR |
| 7 | 5A | EDI |
| 8 | 15A | LT FT TURN LIGHT/LT SIDE INDICATOR |
| 9 | 10A | BCM LOGIC |
| 10 | 15A | STOP LIGHTS/PARKING ASSIST |
| 11 | 15A | CONSOLE LIGHTING |
| 12 | 2A | IGN SW/THEFT DETERRENT |
| 13 | 20A | REAR LIGHTER |
| 14 | 20A | CONSOLE APO (AUXILIARY POWER OUTLET) |
| 15 | 2A | OUTSIDE MIRROR/RPA OPTION |
| 16 | 10A | PHONE/KEY LK/ISRVM/RAIN SENSOR |
| 17 | 20A | SUNROOF |
| 18 | 20A | REAR WIPER |
| 19 | - | SPARE |
| 20 | - | SPARE |
| 21 | - | SPARE |
| 22 | 20A | FRONT LIGHTER/FRONT APO |
| 23 | 2A | STRG WHEEL ILLUMINATION |
| 24 | 2A | RAP CONTROL PWR WDO |
| Relays | ||
| 1 | - | RAP-RETAIN ACCESSORY POWER RELAY |
| 2 | - | ALL DOOR LOCK RELAY |
| 3 | - | PAS DOOR UNLOCK RELAY |
| 4 | - | SPARE |
| 5 | - | REAR END RELEASE RELAY |
| 6 | - | DRIVERS DOOR UNLOCK RELAY |
| 7 | - | SPARE |
| 8 | - | ACCESSORY POWER RELAY |
| 9 | - | FUEL SHUT/OFF SOLENOID RELAY |
| 10 | - | FUEL SHUT/OFF SOLENOID RELAY |
| 11 | - | SPARE |
| 12 | - | SPARE |
Engine compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| Fuses | ||
| FU1 | 20A | BRAKE VACUUM PUMP |
| FU2 | 40A | REAR DEFOG |
| FU3 | 40A | ABS MOTOR |
| FU4 | - | SPARE |
| FU5 | 50A | BATT MAIN 1 |
| FU6 | - | SPARE |
| FU7 | 50A | BATT MAIN 2 |
| FU8 | 40A | STARTER |
| FU9 | 40A | HVAC BLOWER MOTOR |
| FU10 | 30A | FAN 1 ENGINE COOLING |
| FU11 | - | SPARE |
| FU12 | 30A | FAN 2 ENGINE COOLING |
| F1 | 10A | COMM ENABLE |
| F2 | 10A | HVAC BATT |
| F3 | 10A | REVERSE LIGHT |
| F4 | 15A | FOG LAMPS (FRONT) |
| F5 | 25A | ABS VALVES |
| F6 | - | SPARE |
| F7 | 30A | HEADLIGHT WASH |
| F8 | 15A | HORN |
| F9 | 15A | TCM |
| F10 | 10/20A | LEFT LOW BEAM (BASE/HID) |
| F11 | 10A | VAPORISER CONTROL MODULE (VCM) |
| F12 | 10/20A | RIGHT LOW BEAM (BASE/HID) |
| F13 | - | SPARE |
| F14 | - | SPARE |
| F15 | 30A | FRONT WIPER |
| F16 | - | SPARE |
| F17 | 10A | THEFT HORN |
| F18 | 10A | A/C CLUTCH |
| F19 | 10A | RIGHT HIGH BEAM |
| F20 | - | SPARE |
| F21 | 15A | FRONT WASHER (WSW) |
| F22 | - | SPARE |
| F23 | 10A | LEFT HI BEAM |
| F24 | - | SPARE |
| F25 | 15A | REVERSE LOCKOUT/TOSS/FLEX FUEL SNSR |
| F26 | 25A | REAL TIME DAMPING |
| F27 | - | SPARE |
| F28 | 15A | ECM 1-V8/ODD COILS-V6 |
| F29 | 20A | EVEN COILS-V6/EVEN INJECTORS & COILS-V8 |
| F30 | - | SPARE |
| F31 | - | SPARE |
| F32 | 15A | EMISSION 2 |
| F33 | 15A | EMISSION 1 |
| F34 | - | SPARE |
| F35 | 20A | ECM 1-V6/ODD INJECTORS & COILS-V8 |
| F36 | - | SPARE |
| F37 | 10A | HVAC IGN |
| F38 | 10A | IGNITION IP/BODY |
| F39 | 15A | IGNITION ENGINE/FSCM |
| F40 | 10A | AIRBAGS |
| F41 | - | SPARE |
| F42 | 10A | RIGHT PARKING LIGHT |
| F43 | 10A | LEFT PARKING LIGHT |
| Relays | ||
| 1 | - | SPARE RELAY |
| 2 | - | COMMS ENABLE RELAY |
| 3 | - | A/C CLUTCH COMPRESSOR RELAY |
| 4 | - | REVERSE LIGHTS RELAY |
| 5 | - | FOG LIGHT RELAY FRONT |
| 6 | - | HEADLIGHT LO BEAM RELAY |
| 7 | - | HEADLAMP WASH RELAY |
| 8 | - | RR DEFOG RELAY |
| 9 | - | FRONT WIPER HIGH RELAY |
| 10 | - | FRONT WIPER LOW RELAY |
| 11 | - | HEADLIGHT HI BEAM RELAY |
| 12 | - | CRANK RELAY |
| 13 | - | POWER TRAIN RELAY |
| 14 | - | IGNITION RELAY |
| 15 | - | FRONT WINDSCREEN WASH RELAY |
| 16 | - | HORN RELAY |
| 17 | - | ENGINE COOLING FAN 1 RELAY |
| 18 | - | PARKING LIGHTS RELAY |
| 19 | - | ENGINE COOLING FAN 2 RELAY |
| 20 | - | ENGINE COOLING FAN 3 RELAY |
| 21 | - | VACUUM PUMP RELAY |
Luggage compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| Fuses | ||
| 1 | 10A | REAR SEAT ENTERTAINMENT |
| 2 | 30A | AMPLIFIER |
| 3 | 10A | DEALER OPTIONS |
| 4 | 15A | RADIO & INFOTAINMENT |
| 5 | 10A | IPC/RFA/DLC/LAMP |
| 6 | 20A | REAR ACCESSORY POWER OUTLET (APO) |
| 7 | 30A | TRAILER |
| 8 | 10A | LIFTGATE MODULE LOGIC |
| 9 | 15A | FUEL SHUT/OFF SOLENOID |
| 10 | 7.5A | RVC SENSOR |
| 11 | 15A | ECM BATT |
| 12 | 20A | FUEL SYSTEM CONTROL MODULE |
| Relays | ||
| 1 | - | SPARE |
| 2 | - | SPARE |
