Škoda Fabia 2016 Fuse Box Info
Fuse box location:
The fuse box is located on the bottom of the dash panel behind a cover.
Engine compartment fuse box:
Fuse arrangement in engine compartment.
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° | Functions |
| 1 | Left parking light, parking light, high-mounted brake light |
| 2 | Central locking, front and rear window washer system (only with KESSY or ACC) |
| 3 | Ignition |
| 4 | Right-hand light, rear fog light, license plate light |
| 5 | Power windows - driver |
| 6 | Interior lighting |
| 7 | Horn |
| 8 | Towing hitch - left light |
| 9 | Operating lever beneath the steering wheel, engine control unit (only without KESSY), automatic gearbox (only without KESSY), selector lever of the automatic transmission (only without KESSY), ESC (only without KESSY), towing equipment (only without KESSY), power steering (only without KESSY) |
| 10 | Power windows - rear left |
| 11 | Headlight cleaning system |
| 12 | Infotainment display |
| 13 | 12-volt socket in luggage compartment |
| 14 | Operating lever under the steering wheel, light switch, ignition key removal lock (automatic transmission), diagnostic connector, headlight flasher, SmartGate, rain sensor, light sensor, reversing camera |
| 15 | Air conditioning, automatic transmission |
| 16 | Instrument cluster |
| 17 | Anti-theft alarm, horn |
| 18 | Not assigned |
| 19 | Not assigned |
| 20 | Not assigned |
| 21 | Not assigned |
| 22 | Front and rear window washer system (only without KESSY or without ACC) |
| 23 | Not assigned |
| 24 | Blower fan for the air conditioning system, heating, air conditioning, heating |
| 25 | Not assigned |
| 26 | Heated front seats |
| 27 | Rear window wiper |
| 28 | Not assigned |
| 29 | Airbag |
| 30 | Power windows, light switches, reversing light switch, exterior mirrors, feed for the central toolbar, feed for the side toolbar, rear view mirror |
| 31 | Fuel pump, radiator fan, cruise control, front and rear window washer, engine start |
| 32 | Diagnostic connector, headlamp levelling, air conditioning, park assist |
| 33 | Clutch pedal switch |
| 34 | Heated windscreen washer jets |
| 35 | Not assigned |
| 36 | Heated front seats |
| 37 | Radar |
| 38 | Not assigned |
| 39 | Electrical auxiliary heating |
| 40 | Not assigned |
| 41 | Rear window heater |
| 42 | Power windows - front passenger |
| 43 | Trailer device - electrical outlet |
| 44 | Cigarette lighter, 12-volt power socket |
| 45 | Power windows - rear right |
| 46 | Front and rear window washer, operating lever under the steering wheel |
| 47 | Trailer device - electrical outlet |
| 48 | Towing hitch - right light |
| 49 | Fuel pump |
| 50 | Infotainment |
| 51 | Heating of the external mirror |
| 52 | KESSY |
| 53 | KESSY steering lock |
| 54 | Not assigned |
| 55 | Heated front seats |
| 56 | Not assigned |
| 57 | Not assigned |
| 58 | Not assigned |
| 59 | Not assigned |
Engine compartment fuse box:
| Fuse/Relay N° | Functions |
| 1 | Radiator fan |
| 2 | Glow plug system |
| 3 | ABS or ESC |
| 4 | Electrical auxiliary heating |
| 5 | Electrical auxiliary heating |
| 6 | Automatic gearbox |
| 7 | Engine control system |
| 8 | Windscreen wipers |
| 9 | Battery data module |
| 10 | ABS or ESC |
| 11 | Not assigned |
| 12 | Injectors, valve for fuel metering, control valve for oil pressure, valve for exhaust gas recirculation cooler |
| 13 | Brake pedal switch |
| 14 | Fuel pump, coolant pump |
| 15 | Engine control system |
| 16 | Starter |
| 17 | Engine control unit |
| 18 | Additional electrical heating, radiator fan, wastegate, oil temperature sensor, valve for activated charcoal filter, valve for intake manifold |
| 19 | Lambda probe |
| 20 | Preheating unit, crankcase ventilation heating, ignition coils |
