Škoda Fabia 2014 Fuse Box Info
Fuse box location:
The fuse box is located on the bottom of the dash panel behind a cover.
Engine compartment fuse box:
Fuse arrangement in engine compartment.
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° | Functions |
| 1 | Left parking light, parking light, high-mounted brake light |
| 2 | Central locking system |
| 3 | Relay for ignition |
| 4 | Right-hand light, rear fog light, license plate light |
| 5 | Power windows - driver |
| 6 | Central control unit, interior lighting |
| 7 | Horn |
| 8 | Tow hitch |
| 9 | Steering wheel module, engine control unit (only without KESSY), automatic gearbox (only without KESSY), selector lever of the automatic gearbox (only without KESSY), ESC (only without KESSY), control unit for trailer detection (only without KESSY), power steering (only without KESSY) airbag (only without KESSY) |
| 10 | Power windows - rear left |
| 11 | Headlight cleaning system |
| 12 | Radio display |
| 13 | 12-volt socket in luggage compartment |
| 14 | Steering wheel module, light switch, ignition key removal lock (automatic gearbox), diagnostic connector, headlight flasher, SmartGate controller, rain sensor, light sensor |
| 15 | Control unit for air conditioning system, selector lever of the automatic gearbox |
| 16 | Instrument cluster |
| 17 | Alarm system, horn |
| 18 | Not assigned |
| 19 | Not assigned |
| 20 | Not assigned |
| 21 | Not assigned |
| 22 | Front- and rear windscreen wiper system |
| 23 | Not assigned |
| 24 | Blower fan for air conditioning system, heating, control unit for air conditioning, heating |
| 25 | Not assigned |
| 26 | Heated front seats |
| 27 | Rear window wiper |
| 28 | Not assigned |
| 29 | Airbag (only with KESSY) |
| 30 | Power windows, light switches, reverse light switches, control unit for air conditioning system, control unit for park assist, exterior mirror, power feed for center button strip, power feed for side button strip, interior mirror |
| 31 | Fuel pump, control unit for radiator fan, cruise control, coil of the relay for the front and rear windscreen wipers |
| 32 | Diagnostic connector, headlight range adjustment |
| 33 | Coil on starter relay, clutch pedal switch |
| 34 | Heated windscreen washer jets |
| 35 | Not assigned |
| 36 | Heated front seats |
| 37 | Radar |
| 38 | Not assigned |
| 39 | Electrical auxiliary heating system |
| 40 | Not assigned |
| 41 | Rear window heater |
| 42 | Power windows - front passenger |
| 43 | Tow hitch |
| 44 | Cigarette lighter, 12-volt power socket |
| 45 | Power windows - rear right |
| 46 | Front and rear windscreen wiper system, steering wheel module |
| 47 | Tow hitch |
| 48 | Tow hitch |
| 49 | Control unit for fuel pump |
| 50 | Radio |
| 51 | Heating of the external mirror |
| 52 | KESSY control unit |
| 53 | KESSY steering lock |
| 54 | Not assigned |
| 55 | Heated front seats |
| 56 | Not assigned |
| 57 | Not assigned |
| 58 | Not assigned |
| 59 | Not assigned |
Engine compartment fuse box:
| Fuse/Relay N° | Functions |
| 1 | Radiator fan |
| 2 | Control unit for glow plug system |
| 3 | Control unit for ABS / ESC |
| 4 | Electrical auxiliary heating system |
| 5 | Electrical auxiliary heating system |
| 6 | Automatic gearbox |
| 7 | Engine control unit |
| 8 | Windscreen wipers |
| 9 | Central control unit |
| 10 | Control unit for ABS/ESC |
| 11 | Not assigned |
| 12 | Engine components |
| 13 | Brake pedal switch |
| 14 | Engine components, coil of the fuel pump relay |
| 15 | Engine control unit |
| 16 | Starter |
| 17 | Engine control unit |
| 18 | Engine components, coils of the relay for auxiliary electric heater, radiator fan |
| 19 | Lambda probe |
| 20 | Engine components, control unit for glow plug system, heating the crankcase ventilation |
