Mitsubishi Outlander PHEV 2022 Fuse Box Info
Passenger compartment fuse box location:
The fuse box (LHD vehicles) is located at the left side of the steering column at the bottom of the instrument panel, behind the cover. The fuse box (RHD vehicles) is located behind the glove box.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | 30A | Power window control |
| 2 | 30A | Defogger |
| 3 | 30A | Heater |
| 4 | 30A | Windscreen wipers |
| 5 | 20A | Door locks |
| 6 | 10A | Rear fog light |
| 7 | 15A | 12 V power outlet |
| 8 | 15A | Rear window wiper |
| 9 | 20A | Sunroof |
| 10 | 10A | Power switch |
| 11 | 10A | Option |
| 12 | 15A | Hazard warning flasher |
| 13 | 10A | 4-wheel drive system |
| 14 | 15A | Stop lamps (Brake lamps) |
| 15 | 10A | Gauges |
| 16 | 7.5A | SRS airbag |
| 17 | 15A | Radio |
| 18 | 7.5A | Control unit relay |
| 19 | 15A | Interior lights (Room lights) |
| 20 | 7.5A | Reversing lamps (Backup lamps) |
| 21 | 7.5A | Heated door mirror |
| 22 | 10A | Outside rearview mirrors |
| 23 | 15A | Cigarette lighter/Accessory socket |
| 24 |
7.5A 15A |
Charge Heated steering wheel |
| 25 | 30A | Power seat (Driver seat) |
| 26 | 30A | Heated seats |
| 27 | 30A | Power seat (Passenger seat) |
Engine compartment fuse box A:
| Fuse/Relay N° | Rating | Functions |
| SBF1 | 30A | Air conditioning condenser fan motor |
| SBF2 | - | - |
| SBF3 | - | - |
| SBF4 | 40A | Radiator fan motor |
| SBF5 | 40A | Anti-lock braking system |
| SBF6 | - | - |
| SBF7 | 30A | Anti-lock braking system |
| BF1 | 30A | Power liftgate |
| BF2 | 30A | Audio system amplifier |
| BF3 | 30A | IOD |
| BF4 | - | - |
| 1 | - | - |
| 2 | 15A | Wiper deicer |
| 3 | 7.5A | Electric parking brake |
| 4 | 10A | Daytime running lights |
| 5 | 15A | Front fog lights |
| 6 | 15A | Heated steering wheel |
| 7 | 20A | Headlight washer |
| 8 | 20A | Security horn |
| 9 | 10A | Horn |
| 10 | 15A | ETV |
| 11 | 15A | Charging lid lock |
| 12 | 7.5A | Engine |
| 13 | 20A | ENG/POWER |
| 14 | 15A | Fuel pump |
| 15 | 10A | Ignition coil |
| 16 | - | - |
| 17 | 10A | Headlight high beam (left) |
| 18 | 10A | Headlight high beam (right) |
| 19 | 20A |
Headlight low beam (left) LED |
| 20 | 20A |
Headlight low beam (right) LED |
| 21 | 10A |
Headlight low beam (left) Halogen |
| 22 | 10A |
Headlight low beam (right) Halogen |
| 23 | - | - |
| #1 | 10A | Spare fuse |
| #2 | 15A | Spare fuse |
| #3 | 20A | Spare fuse |
Engine compartment fuse box B:
| Fuse/Relay N° | Rating | Functions |
| SBF1 | 30A | Electrical Parking Lock |
| SBF2 | 30A | Vacuum pump (Regenerative brake) |
| 1 | 20A | Water pump (Electric motor) |
| 2 | 7.5A | Battery management unit |
| 3 | 15A | Drive battery PTC heater |
| 4 | 7.5A | Fuel tank filler door |
| 5 | 7.5A | Solenoid valve (Air conditioning) |
| 6 | 7.5A | Water pump (Air conditioning) |
| 7 | 10A | Electric motor unit control |
| 8 | 7.5A | Heated windscreen |
| 9 |
10A 15A |
Power feeder and charger connector (12V) Drive battery fun motor |
| 10 | 15A | Ignition control |
| 11 | 7.5A | Ignition control |
