Lincoln LS 2001 Fuse Box Info
Passenger compartment fuse box location:
The fuse box is located on the right hand side kick panel.
Engine compartment fuse box location:
Luggage compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | 5A | Starter Relay Coil |
| 2 | 5A | Radio |
| 3 | 5A | ABS/TCS/AdvanceTrac |
| 4 | 5A | Cluster, PCM Relay, Fuel Pump Relay, REM, Transit Relay |
| 5 | 5A | T/A Switch, O/D Cancel Switch, Autolamp Sensor, Heated Seat Modules |
| 6 | 10A | OBD II |
| 7 | 5A | DDM, DSM, Anti-theft LED, Security Horn, PCM, Power Mirror |
| 8 | 5A | Right Front Turn, Right Front Repeater, Right Front Sidemarker, Right Front Park Lamps |
| 9 | 10A | Right Front Low Beam |
| 10 | 5A | Left Front Turn, Left Front Repeater, Left Front Sidemarker, Left Front Park Lamps |
| 11 | 10A | Left Front High Beam |
| 12 | - | Not Used |
| 13 | 5A | Cluster |
| 14 | 10A | RCM, DATC |
| 15 | 5A | Not Used (Spare) |
| 16 | 5A | E/C Mirror, Heated Seat Controls, RSM (Rain Sensor Module) |
| 17 | 5A | RCM, Alternator Warning Lamp |
| 18 | 20A | Radio, CIA |
| 19 | 15A | Tilt/Tele Motors |
| 20 | 10A | FEM, DATC, Cluster, Brake Shift Interlock, REM |
| 21 | 10A | Power Folding Mirrors |
| 22 | 10A | DDM |
| 23 | 10A | Right Front High Beam |
| 24 | 5A | PATS |
| 25 | 10A | Left Front Low Beam |
| 26 | 3A | Wiper Relay, Windshield Washer |
| 27 | 10A | Radio, Cellphone |
| 28 | 5A | Security Horn |
| 29 | 5A | Trailer Tow Ignition Sense, VEMS, FEM |
| 30 | 5A | FEM |
| 31 | - | Not Used |
| 32 | 20A | Cigar Lighter |
| 33 | 10A | Switch Backlighting |
| 34 | 10A | Not Used (Spare) |
| 35 | 5A | Stop Lamp Signal |
Engine compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | 10A | A/C Clutch |
| 2 | - | Not Used |
| 3 | 15A | Fog Lamp |
| 4 | 15A | Horn |
| 5 | 20A | Fuel Injectors |
| 6 | 15A | Transmission Solenoid |
| 7 | - | Not Used |
| 8 | - | Not Used |
| 9 | - | Not Used |
| 10 | - | Not used |
| 11 | 15A | HEGO’s |
| 12 | 10A | COP’s |
| 13 | 30A | Heated Wiper Park |
| 14 | 30A | ABS Module |
| 15 | - | Not used |
| 16 | 30A | Blower Motor |
| 17 | 20A | Thermactor Air Pump (Low Emission Vehicles Only) |
| 18 | 40A | PCM |
| 19 | - | Not Used |
| 20 | 30A | Wiper Motor |
| 21 | 30A | Starter Solenoid |
| 22 | 30A | ABS Motor |
| 23 | - | Not Used (Fuse Plug) |
| 24 | - | Not Used |
| Relay 01 | - | Wiper Hi/Lo |
| Relay 02 | - | Wiper Park |
| Relay 03 | - | COP’s and HEGO’s |
| Relay 04 | - | Not Used |
| Relay 05 | - | Auxiliary Coolant Pump (V8) |
| Relay 06 | - | Horn |
| Relay 07 | - | Fog Lamps |
| Relay 08 | - | A/C Clutch |
| Relay 09 | - | Wiper Run/Acc |
| Relay 10 | - | Blower Motor |
| Relay 11 | - | Not used |
| Relay 12 | - | Heated Wiper Park |
| Relay 13 | - | Not used |
| Relay 14 | - | PCM Power |
| Relay 15 | - | Starter Motor |
| Diode | - | PCM |
Luggage compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | 15A | Decklid Release Solenoid |
| 2 | 10A | Right Rear Turn Lamp |
| 3 | 5A | Left Rear Stop Lamp |
| 4 | 10A | Fuel Door Release Solenoid |
| 5 | 10A | Courtesy and Map Lamps |
| 6 | 10A | Left Rear Turn and Back-up Lamps |
| 7 | 5A | Right Rear Stop Lamp |
| 8 | 10A | Center High Mounted Stop Lamp |
| 9 | 5A | Heated Mirror |
| 10 | 20A | Powerpoint |
| 11 | 15A | Heated Seats |
| 12 | 5A | Transit Relay (if equipped) |
| 13 | - | Not used |
| 14 | 5A | Phone, CD, VEMS |
| 15 | 5A | Alternator Sense |
| 16 | 20A | Moonroof |
| 17 | 15A | Fuel Pump |
| 18 | 20A | Subwoofer Amplifier |
| 19 | 20A | REM - Left Rear Window |
| 20 | 20A | DDM - Driver Window |
| 21 | 20A | Driver Lumbar, Power Seats |
| 22 | 20A | Ignition |
| 23 | 30A | SSP4 |
| 24 | 30A | SSP3 |
| 25 | 40A | P-J/B |
| 26 | 20A | FEM - Front Passenger Window |
| 27 | 30A | SSP1 |
| 28 | 20A | Passenger Lumbar, Power Seats |
| 29 | 30A | Rear Defroster |
| 30 | 20A | REM - Right Rear Window |
| 31 | 20A | Ignition Switch (V6 manual trans) |
| 32 | 30A | SSP2 |
| Relay 001 | - | SSP1 |
| Relay 002 | - | SSP4 |
| Relay 003 | - | Rear Defroster |
| Relay 004 | - | SSP3 |
| Relay 005 | - | SSP2 |
| Relay 006 | - | Not used |
| Relay 007 | - | Fuel Pump |
| Diode 01 | - | Not Used |
| Diode 02 | - | Fuel Pump Motor |
