Kia XCeed 2024 Fuse Box Info
Passenger compartment fuse box location:
The fuse box is located at the left side of the steering column at the bottom of the instrument panel.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay Name | Rating | Functions |
| BATTERY MANAGEMENT 2 | 10A | BMS (Battery Management System) |
| MEMORY 1 | 10A | Driver IMS (Integrated memory system) Module, Air Conditioner Control Module, Power Tail Gate Module |
| MODULE 1 | 10A | Active Air Flap, Data Link Connector, Instrument Cluster, Hazard Switch, ICM (Integrated Circuit Module) Relay Box (Outside Mirror Folding/Unfolding Relay), Auto Light & Photo Sensor, Console Switch, Driver/Passenger Smart Key Outside Handle |
| TAIL GATE | 10A | Tail Gate Relay |
| POWER WINDOW RH | 25A | Power Window Right Handle side Relay, Driver/Passenger Safety Power Window Module, Rear Safety Power Window Module Right Handle side |
| POWER WINDOW LH | 25A | Power Window Left Handle side Relay, Driver/Passenger Safety Power Window Module, Rear Safety Power Window Module Left Handle side |
| POWER SEAT DRIVER | 25A | Driver IMS (Integrated memory system) Module, Driver Seat Manual Switch |
| MODULE 4 | 7.5A | Forward Collision-Avoidance Assist Unit, Lane Keeping Assist Unit, Rear Corner Radar LH/RH, Parking Assist Control Module, Crash Pad Switch, IBU (Integrated Body Control Unit), Electric Parking Brake Switch, Dosing Control Module, Active Air Flap |
| E-CALL | 10A | MTS (Mozen Telematics System) E-Call Module |
| SEAT HEATER REAR | 20A | Rear Seat Warmer Control Module |
| HEATED MIRROR | 10A | Driver/Passenger Power Outside Mirror, Air Conditioner Control Module, ECM (Engine Control Module)/PCM (Power train Control Module) |
| SEAT HEATER FRONT | 20A | Front Seat Warmer Control Module, Front Air Ventilation Seat Control Module |
| AMP | 25A | Low DC (Direct Current)-DC (Direct Current) Converter (AMP (Amplifier)), AMP (Amplifier) |
| MULTI MEDIA | 15A | Low DC (Direct Current)-DC (Direct Current) Converter (Audio/AMP (Amplifier)), Audio, Audio/Video & Navigation Head Unit |
| MODULE 5 | 10A | Rear Seat Warmer Control Module, MTS (Mozen Telematics System) E-Call Module, Electro Chromic Mirror, Audio, Audio/Video & Navigation Head Unit, Auto Transmission Shift Lever Illumination, Air Conditioner Control Module, Low DC (Direct Current)-DC (Direct Current) Converter (Audio/AMP (Amplifier)), Front Seat Warmer Control Module, Front Air Ventilation Seat Control Module, Driver IMS (Integrated memory system) Module, Head Lamp Left Handle side/Right Handle side |
| REAR WIPER | 15A | Rear Wiper Motor, ICM (Integrated Circuit Module) Relay Box (Rear Wiper Relay) |
| DOOR LOCK | 20A | Door Lock/Unlock Relay |
| IBU 1 | 15A | IBU (Integrated Body Control Unit) |
| BRAKE SWITCH | 10A | IBU (Integrated Body Control Unit), Stop Lamp Switch |
| POWER SEAT PASSENGER | 10A | Front Seat Warmer Control Module, Front Air Ventilation Seat Control Module |
| IG 1 | 25A | Engine Room Junction Block (Fuse - ECU5, SENSOR4, ABS3, TCU2) |
| WIPER | 10A | Engine Room Junction Block (Front Wiper (Low) Relay), Front Wiper Motor, IBU (Integrated Body Control Unit), ECM (Engine Control Module)/PCM (Power train Control Module) |
| AIR CONDITIONER 1 | 7.5A | Engine Room Junction Block (COOLING FAN 3 Relay, PTC HEATER 2 Relay, BLOWER Relay, PTC HEATER 1 Relay, PTC HEATER 3 Relay), Air Conditioner Control Module |
| AIR BAG 2 | 10A | SRS (Supplemental Restraint System) Control Module |
| WASHER | 15A | Multifunction Switch |
| MDPS | 7.5A | MDPS (Motor Driven Power Steering) Unit - MDPS(Motor Driven Power Steering) is the same as EPS(Electric Power Steering) |
| MODULE 7 | 7.5A | Rear Seat Warmer Control Module, Front Seat Warmer Control Module, Front Air Ventilation Seat Control Module, Nozzle Heater, Engine Room Junction Block (HEAD LAMP HIGH Relay, DCU (Dosing Control Unit) Relay), Cooling Fan Motor |
| SUNROOF 2 | 20A | Panorama Sunroof Motor |
| SUNROOF 1 | 20A | Panorama Sunroof Motor |
| CLUSTER | 7.5A | Instrument Cluster |
| MODULE 3 | 7.5A | Sport Mode Switch, Stop Lamp Switch |
| START | 7.5A | ICM (Integrated Circuit Module) Relay Box (Burglar Alarm Relay), Transmission Range Switch, Engine Room Junction Block (PDM 3 (IG1) Relay), IBU (Integrated Body Control Unit), ECM (Engine Control Module), PCM (Power train Control Module) |
| IBU 2 | 7.5A | IBU (Integrated Body Control Unit) |
| AIR BAG INDICATOR | 7.5A | Instrument Cluster, Hazard Switch |
| MODULE 6 | 7.5A | IBU (Integrated Body Control Unit) |
| MODULE 2 | 10A | Audio, Audio/Video & Navigation Head Unit, Low DC (Direct Current)-DC (Direct Current) Converter (Audio/AMP (Amplifier)), IBU (Integrated Body Control Unit), MTS (Mozen Telematics System) E-Call Module, Wireless Charger, Engine Room Junction Block (POWER OUTLET Relay), AMP (Amplifier), Power Outside Mirror Switch |
| AIR BAG 1 | 15A | SRS (Supplemental Restraint System) Control Module |
| AIR CONDITIONER 2 | 10A | Engine Room Junction Block (BLOWER Relay), Air Conditioner Control Module, Blower Resistor, Blower Motor, ECM (Engine Control Module)/PCM (Power train Control Module) |
| LDC (B+) | 15A | Audio, Audio/Video & Navigation Head Unit, Instrument Cluster, Air Conditioner Control Module, Low DC (Direct Current)-DC (Direct Current) Converter (Audio/AMP (Amplifier)) |
| POWER OUTLET | 20A | Front Power Outlet, Power Outlet Left Handle side |
Engine compartment fuse box:
| Fuse/Relay Name | Rating | Functions |
| ALTERNATOR | 150/180/200A | Fuse: BURGLAR ALARM, HEAD LAMP HIGH, ABS1, ABS2, DCU1, POWER TAIL GATE MODULE, POWER OUTLET1, Alternator |
| MDPS | 80A | MDPS (Motor Driven Power Steering) Unit - MDPS(Motor Driven Power Steering) is the same as EPS(Electric Power Steering) |
| BATTERY 5 | 60A | Fuse: COOLING FAN1, REAR HEATED, PTC HEATER2, PTC HEATER3, FUEL HEATER, Engine Control Relay |
| BATTERY 2 | 60A | Instrument Panel Junction Block |
| BATTERY 3 | 60A | Instrument Panel Junction Block |
| BATTERY 4 | 50A | Instrument Panel Junction Block (Fuse: TAIL GATE, POWER WINDOW RH, POWER WINDOW LH, POWER SEAT DRIVER, SEAT HEATER FRONT, AMP, POWER SEAT PASSENGER, SUNROOF2, SUNROOF1) |
| COOLING FAN 1 | 60/50A | COOLING FAN 2 Relay, COOLING FAN 1 Relay |
| REAR HEATED | 40A | REAR HEATED Relay |
| ABS 2 | 30A | ABS (Antilock Brake System) Module, ESC (Electronic Stability Control) Module |
| BLOWER | 40A | BLOWER Relay |
| REAR HEATED | 40A | REAR HEATED Relay |
| IG1 | 40A | Ignition Switch, PDM 3 (IG1) Relay, PDM 2 (ACC) Relay |
| IG2 | 40A | Ignition Switch, START Relay, PDM 4 (IG2) Relay |
| GLOW | 80A | Glow Unit |
| PTC HEATER 1 | 50A | PTC HEATER 1 Relay |
| PTC HEATER 2 | 50A | PTC HEATER 2 Relay |
| PTC HEATER 3 | 50A | PTC HEATER 3 Relay |
| FUEL HEATER | 30A | FUEL HEATER Relay |
| POWER OUTLET 3 | 20A | Rear Power Outlet |
| POWER OUTLET 2 | 20A | Front Power Outlet, Power Outlet Right Handle side |
| DCU 2 | 20A | Dosing Control Module |
| TCU 1 | 15A | TCM (Transmission Control Module) |
| CLUTCH ACTUATOR 2 | 15A | Electronic Clutch Module |
| VACUUM PUMP | 20A | Vacuum Pump |
| FUEL PUMP | 20A | FUEL PUMP Relay |
| COOLING FAN 2 | 40A | COOLING FAN 3 Relay, COOLING FAN 2 Relay |
| DCT 3 | 40A | Smart Gear Actuator |
| BATTERY 1 | 40A | Instrument Panel Junction Block (LONG TERM LOAD LATCH RELAY, Fuse: MODULE1, SEAT HEATER REAR, DOOR LOCK, IBU1, BRAKE SWITCH, AIR BAG2) |
| DCT 1 | 40A | TCM (Transmission Control Module) |
| CLUTCH ACTUATOR 1 | 40A | Electronic Clutch Module |
| DCT 2 | 40A | TCM (Transmission Control Module) |
| BURGLAR ALARM | 10A | Burglar Alarm Relay |
| HEAD LAMP HIGH | 10A | HEAD LAMP HIGH Relay |
| ABS 1 | 40A | ESC (Electronic Stability Control) Control Module |
| ABS 2 | 30A | ESC (Electronic Stability Control) Control Module, EPB |
| BLOWER | 40A | BLOWER Relay |
| DCU 1 | 40A | DCU (Dosing Control Unit) Relay |
| CVVD 1 | 40A | CVVD (Continuously Variable Valve Duration) Actuator |
| POWER TAIL GATE MODULE | 30A | Power Tail Gate Module |
| POWER OUTLET 1 | 40A | POWER OUTLET Relay |
| DCU 4 | 20A | Dosing Control Module |
| DCU 3 | 15/20A | Dosing Control Module |
| SENSOR 2 | 10A |
[Smartstream G1.0 T-GDi / Smartstream G1.0 T-GDi MHEV] Air Conditioner Compressor Relay, Purge Control Solenoid Valve, RCV Control Solenoid Valve, COOLING FAN 1 Relay, Oil Control Valve (Intake/Exhaust) [[Smartstream G1.5 T-GDi] / Smartstream G1.5 T-GDi MHEV] Air Conditioner Compressor Relay, Purge Control Solenoid Valve, RCV Control Solenoid Valve, COOLING FAN 1 Relay, Oil Control Valve (Intake/Exhaust) [(Gasoline) 1.6 MPI] Purge Control Solenoid Valve, Variable Intake Solenoid Valve, COOLING FAN 3 Relay, COOLING FAN 2 Relay, Oil Control Valve (Intake/Exhaust) [(Gasoline) 1.6 T-GDi] Oil Control Valve #1/#2, CCV, Cooling Fan 2 Relay, PCSV, RCV |
| ECU 2 | 10A |
[Smartstream G1.0 T-GDi / Smartstream G1.0 T-GDi MHEV] ECM (Engine Control Module) [[Smartstream G1.5 T-GDi] / Smartstream G1.5 T-GDi MHEV] ECM (Engine Control Module) [(Gasoline) 1.6 MPI] ECM (Engine Control Module)/PCM (Power train Control Module) [(Gasoline) 1.6 T-GDi] ECM (Engine Control Module) |
| ECU 1 | 20A |
[Smartstream G1.0 T-GDi / Smartstream G1.0 T-GDi MHEV] ECM (Engine Control Module) [[Smartstream G1.5 T-GDi] / Smartstream G1.5 T-GDi MHEV] ECM (Engine Control Module) [(Gasoline) 1.6 MPI] ECM (Engine Control Module)/PCM (Power train Control Module) [(Gasoline) 1.6 T-GDi] ECM (Engine Control Module) |
| INJECTOR | 15A | [(Gasoline) 1.6 MPI] Injector #1~#4 |
| Mild Hybrid Starter and Generator | 15A | MHSG (MILD HYBRID STARTER & GENERATOR) |
| SENSOR 1 | 15A |
[Smartstream G1.0 T-GDi / Smartstream G1.0 T-GDi MHEV] Oxygen Sensor (Up), Oxygen Sensor (Down) [[Smartstream G1.5 T-GDi] / Smartstream G1.5 T-GDi MHEV] Oxygen Sensor (Up), Oxygen Sensor (Down) [(Gasoline) 1.6 MPI] Oxygen Sensor (Up), Oxygen Sensor (Down) [(Gasoline) 1.6 T-GDi] ECM (Engine Control Module), Oxygen Sensor (UP/Down) |
| IGNITION COIL | 20A |
[[Smartstream G1.0 T-GDi / Smartstream G1.0 T-GDi MHEV]] Ignition Coil #1~#3 [[Smartstream G1.5 T-GDi] / Smartstream G1.5 T-GDi MHEV] Ignition Coil #1~#4 [(Gasoline) 1.6 MPI] Ignition Coil #1~#4, Condenser [(Gasoline) 1.6 T-GDi] Ignition Coil #1~#4, Condenser |
| ECU 3 | 15A |
[Smartstream G1.0 T-GDi / Smartstream G1.0 T-GDi MHEV] ECM (Engine Control Module) [[Smartstream G1.5 T-GDi] / Smartstream G1.5 T-GDi MHEV] ECM (Engine Control Module) [(Gasoline) 1.6 MPI] ECM (Engine Control Module)/PCM (Power train Control Module) [(Gasoline) 1.6 T-GDi] ECM (Engine Control Module) |
| AIR CONDITIONER | 10A |
[Smartstream G1.0 T-GDi / Smartstream G1.0 T-GDi MHEV] Air Conditioner Compressor [[Smartstream G1.5 T-GDi] / Smartstream G1.5 T-GDi MHEV] Air Conditioner Compressor [(Gasoline) 1.6 T-GDi] Air Conditioner Compressor |
| ECU 5 | 10A |
[Smartstream G1.0 T-GDi / Smartstream G1.0 T-GDi MHEV]] ECM (Engine Control Module) [[Smartstream G1.5 T-GDi] / Smartstream G1.5 T-GDi MHEV] ECM (Engine Control Module) [(Gasoline) 1.6 MPI] ECM (Engine Control Module)/PCM (Power train Control Module) [(Gasoline) 1.6 T-GDi] ECM (Engine Control Module) |
| SENSOR 4 | 15A | [[Smartstream G1.5 T-GDi] / Smartstream G1.5 T-GDi MHEV] Vacuum Pump |
| CVVD 2 | 15A | CVVD (Continuously Variable Valve Duration) Actuator |
| ABS 3 | 10A | [ALL] ESC (Electronic Stability Control) Control Module, Clutch Master Cylinder |
| TCU 2 | 15A |
[Smartstream G1.0 T-GDi/ Smartstream G1.0 T-GDi MHEV]: INHIBITOR SWITCH, TCM (Transmission Contorl Module) [Smartstream G1.5 T-GDi/ Smartstream G1.5 T-GDi MHEV] : INHIBITOR SWITCH, TCM (Transmission Contorl Module) [(Gasoline) 1.6 T-GDi]: INHIBITOR SWITCH, TCM (Transmission Contorl Module) [(Gasoline) 1.6 MPI] : INHIBITOR SWITCH |
| CLUTCH ACTUATOR 3 | 15A | Electronic Clutch Module |
| SENSOR 3 | 10A |
[(Gasoline) 1.6 MPI] FUEL PUMP Relay [Smartstream G1.0 T-GDi / Smartstream G1.0 T-GDi MHEV] FUEL PUMP Relay [[Smartstream G1.5 T-GDi] / Smartstream G1.5 T-GDi MHEV] FUEL PUMP Relay [(Gasoline) 1.6 MPI] FUEL PUMP Relay [(Gasoline) 1.6 T-GDi] FUEL PUMP Relay |
| ECU 4 | 15A |
[Smartstream G1.0 T-GDi / Smartstream G1.0 T-GDi MHEV] ECM (Engine Control Module) [[Smartstream G1.5 T-GDi] / Smartstream G1.5 T-GDi MHEV] ECM (Engine Control Module) [(Gasoline) 1.6 MPI] ECM (Engine Control Module)/PCM (Power train Control Module) [(Gasoline) 1.6 T-GDi] ECM (Engine Control Module) |
| WIPER | 25A | [ALL] Wiper Relay |
| HORN | 15A | [ALL] Horn Relay |
| Battery Fuse Panel | ||
| AMS | 10A | AMS |
