Kia Stinger 2021 Fuse Box

Kia Stinger 2021 Fuse Box Info



Passenger compartment fuse box location:

The fuse box is located at the left side of the steering column at the bottom of the instrument panel.



Engine compartment fuse box location:





Luggage compartment fuse box location:





Fuse Box Diagram | Layout



Passenger compartment fuse box:

Fuse/Relay Name Rating Functions
MULTI MEDIA 1 25A Low DC-DC Converter (Audio)
AIR BAG 15A SRS (Supplemental Restraint System) Control Module
INTERIOR LAMP 10A Overhead Console Lamp, Center Room Lamp, Room Lamp, Vanity Lamp Switch Left Handle side/Right Handle side, Luggage Lamp Left Handle side/Right Handle side, Glove Box Lamp, Driver/Passenger Door Mood Lamp, Driver/Passenger Door Lamp, Driver/Passenger Foot Lamp
STOP LAMP 10A IBU, Stop Lamp Switch
CLUSTER 10A Instrument Cluster, Head-Up Display
E-SHIFTER 2 10A Electronic Auto Transmission Shift Lever (IG1)
IBU 4 10A IBU (IG1)
MULTI MEDIA 3 10A Instrument Cluster, Head-Up Display, Air Conditioner Switch
MULTI MEDIA 2 10A Audio
MEMORY 1 10A Air Conditioner Control Module, Air Conditioner Switch, Security Indicator, Head-Up Display
IBU 3 10A IBU (B+)
E-SHIFTER 1 10A Electronic Auto Transmission Shift Lever (B+)
A/BAG IND 10A Instrument Cluster, Passenger Air Bag IND
IBU 1 10A IBU (B+)
DDM 10A Driver Door Module, Driver/Passenger Power Outside Mirror
MODULE 2 10A IBU (IG2)
MODULE 3 10A Auto Transmission Shift Lever Switch, Driver Door Module, Stop Lamp Switch
DOOR LOCK 20A Door Lock Relay, Door Unlock Relay, Two Turn Unlock Relay
S/HEATER DRV/PASS 25A Front Air Ventilation Seat Control Module, Front Seat Warmer Control Module
TAIL GATE 10A Tail Gate Lid Relay, Fuel Lid Relay, Crash Pad Switch
IBU 2 10A Rain Sensor
SPARE 20A Spare
MODULE 8 10A Cooling Fan Controller (BLDC Motor), Around View Monitor, Front Air Ventilation Seat Control Module, Front/Rear Seat Warmer Control Module
MODULE 7 10A IBU, ECS Unit, AWD (All Wheel Drive) ECM (Electronic Control Module), Smart Cruise Control Module, Auto Transmission Shift Lever Indicator, Console Switch (Front/Upper), Blind-Spot Collision Warning Unit Left Handle side/Right Handle side, Steering Angle Sensor, Steering Tilt & Telescopic Module, Multi- Function Camera Unit, Crash Pad Switch
POWER HANDLE 15A Steering Tilt & Telescopic Module
MODULE 9 10A Driver Air Lumbar Control Unit
MODULE 1 10A Data Link Connector, Console Switch (Upper), Mood Lamp Control Unit
MODULE 5 10A Air Conditioner Control Module, Air Conditioner Switch, Audio, Head Lamp Left Handle side/Right Handle side, Low DC-DC Converter (Audio/AMP (Amplifier)), Electro Chromic Mirror, AMP (Amplifier), Driver Integrated memory system Control Module, Front Air Ventilation Seat Control Module, Front/Rear Seat Warmer Control Module
SUNROOF 20A Sunroof Control Unit (Glass)
P/WINDOW RH 25A Passenger Power Window Module, Rear Power Window Module Right Handle side
CHARGER 10A Front/Rear USB Charger
WASHER 15A Multifunction Switch
MDPS 10A MDPS (Motor Driven Power Steering) Unit (R-MDPS (Motor Driven Power Steering))
P/SEAT (DRV) 30A Driver Integrated memory system Control Module, Drive Seat Module
P/SEAT (PASS) 30A Passenger Seat Module
P/WINDOW LH 25A Driver Power Window Module, Rear Power Window Module Left Handle side
MODULE 6 10A IBU, Low DC-DC Converter (Audio/AMP (Amplifier)), Electronic Auto Transmission Shift Lever (SBW (Shift By Wire)), Engine Room Junction Block (RLY. 4 - Power Outlet Relay)
A/C 10A Air Conditioner Control Module, Air Conditioner Switch, Engine Room Junction Block (Blower Relay)
MODULE 4 10A Head Lamp Left Handle side/Right Handle side, AFS Control Unit, Auto Head Lamp Leveling Device Module



Engine compartment fuse box:

Fuse/Relay Name Rating Functions
ALT

175A

200A

Alternator, Multi Fuse

- COOLING FAN 1 / B+5 / B+4 / B+3 / OPCU / ESC1 / ESC2 / BLOWER / POWER TAIL GATE
COOLING FAN 2 100A [BLDC (Brushless Direct Current) Motor] Cooling Fan Controller
START 30A Start Relay
COOLING FAN 1 80A [BLDC (Brushless Direct Current) Motor] Cooling Fan Controller
B+5 50A

Instrument Panel Junction Block

(Fuse - STOP LAMP / Leak Current Autocut Device Fuse / INTERIOR LAMP)
B+4 50A

Instrument Panel Junction Block

(Fuse - DOOR LOCK / POWER HANDLE / SUNROOF / P/SEAT (DRV) / P/SEAT (PASS))
B+3 50A

Instrument Panel Junction Block

(Fuse - S/HEATER DRV/PASS / TAIL GATE / MODULE9 / P/WINDOW RH / P/WINDOW LH)
OPCU 50A Electric Oil Pump Inverter
ESC 1 40A ESC (Electronic Stability Control) Control Module
ESC 2 40A ESC (Electronic Stability Control) Control Module, Multipurpose Check Connector
BLOWER 40A Blower Relay
POWER TAIL GATE 30A Power Tail Gate Module
MDPS 100A MDPS (Motor Driven Power Steering) Unit
B+6 60A Engine Control Relay, Fuse - HORN / WIPER1 / H/LAMP H / B/ALARM HORN)
B+1 60A Instrument Panel Junction Block (Fuse - IBU1 / IBU2)
B+2 50A Instrument Panel Junction Block (Fuse - E-SHIFTER1 / MODULE1)
E-CVVT 1 40A [THETA II 2.0L T-GDI Engine] E-CVVT Relay
VACUUM PUMP 20A Vacuum Pump Relay
AWD 20A AWD (All Wheel Drive) ECM (Electronic Control Module)
IG 2 20A IG2 Relay
POWER OUTLET 2 20A Front Power Outlet #2
POWER OUTLET 1 20A Front Power Outlet #1
A/C 10A Air Conditioner Control Module
E-CVVT 3 20A [THETA II 2.0L T-GDI Engine] ECM (Engine Control Module)
E-CVVT 2 20A [THETA II 2.0L T-GDI Engine] ECM (Engine Control Module)
ESC 3 10A ESC (Electronic Stability Control) Control Module, Multipurpose Check Connector
ECU 3 10A ECM (Engine Control Module)
ECU 2 15A ECM (Engine Control Module)
HORN 20A Horn Relay
WIPER 1 30A Wiper Power Relay
TCU 2 15A TCM (Transmission Control Module)
SENSOR 4 10A Brake Vacuum Switch, Vacuum Pump Relay, Electric Oil Pump Inverter
TCU 1 20A TCM (Transmission Control Module)
WIPER 2 10A IBU (Integrated Body Control Unit), ECM (Electronic Control Module)
SENSOR 1 15A Rear Sub Junction Block (Fuel Pump Relay)
SENSOR5 20A

[THETA II 2.0L T-GDI Engine] Ignition Coil #1/#2/#3/#4

[Lambda II PE 3.3L T-GDI Engine] Ignition Coil #1/#2/#3/#4/#5/#6
H/LAMP HI 10A Head Lamp (High) Relay
ECU 1 20A ECM (Engine Control Module)
SENSOR 3 15A [THETA II 2.0L T-GDI Engine] Oxygen Sensor (Up) [Lambda II PE 3.3L T-GDI Engine] Oxygen Sensor #2/#4
SENSOR 2 10A

[THETA II 2.0L T-GDI Engine] Electronic Thermostat, Oil Control Valve, Purge Control Solenoid Valve,

RCV (Recirculation Valve Control) Control Solenoid Valve, Canister Close Valve

[Lambda II PE 3.3L T-GDI Engine] Electronic Thermostat, Oil Pressure Solenoid Valve, Oil Control Valve #1/#2/#3/#4 (Intake/Exhaust), RCV (Recirculation Valve Control) Control Solenoid Valve, Purge Control Solenoid Valve, Canister Close Valve
B/ALARM HORN 10A Burglar Alarm Horn Relay



Luggage compartment:

Rear fuse box panel:

Fuse/Relay Name Rating Functions
ECS 15A ECS (Electronic Control Suspension) Unit
S/HEATER REAR 20A Rear Seat Warmer Control Module
HEATED MIRROR 10A Air Conditioner Switch, Driver/Passenger Power Outside Mirror
FUEL PUMP 20A Fuel Pump Relay
SPARE1 10A -
SPARE2 15A -
SPARE3 15A -
REAR HEATED 30A Rear Heated Relay
AMP 2 25A AMP (Amplifier) (MOBIS/PREMIUM)
SPARE4 15A -
AMP 1 30A Low DC-DC Converter (AMP (Amplifier))
IG 1 15A IG1 Relay
ACC 30A ACC Relay



Battery box fuse panel:

Fuse/Relay Name Rating Functions
B+1 80A Rear Sub Junction Block (Fuse - FUEL PUMP / REAR HEATED/ AMP1)
B+2 80A Rear Sub Junction Block (Fuse - ECS / S/HEATER REAR / IG1)
START 40A Engine Room Junction Block (Power Outlet Relay), Fuse -START / ECU2 / TCU1)
AMS 10A Battery Sensor
