Kia K900 2020 Fuse Box Info
Passenger compartment fuse box location:
The fuse box is located at the left side of the steering column at the bottom of the instrument panel.
Engine compartment fuse box location:
Luggage compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box::
| Fuse/Relay Name | Rating | Functions |
| MULTI MEDIA2 | 15A | Audio/Video & Navigation Head Unit |
| MULTI MEDIA1 | 30A | Fuse - MULTI MEDIA2, MULTI MEDIA4, MULTI MEDIA3 |
| AIR BAG1 | 15A | SRS (Supplemental Restraint System) Control Module |
| INTERIOR LAMP | 10A | Overhead Console Lamp, Room Lamp, Glove Box Lamp, Front Foot Lamp Left Handle side/Right Handle side, Luggage Lamp Left Handle side/Right Handle side, Driver/Passenger Door Foot Lamp, Rear Door Foot Lamp Left Handle side/Right Handle side, Driver/Passenger Seat Foot Lamp |
| BRAKE SWITCH | 10A | IBU (Integrated Body Control Unit), Stop Lamp Switch |
| CLUSTER | 10A | Instrument Cluster, Head-Up Display |
| AFS | 10A | [Auto Dynamic] AFS (Adaptive Front Lighting System) Control Unit, Head Lamp Left Handle side/Right Handle side |
| PRESAFETY SEAT BELT | 10A | Pre-Safe Seat Belt Control Unit |
| MULTI MEDIA4 | 10A | Rear Seat USB Jack, Instrument Cluster |
| MULTI MEDIA3 | 10A | DIS (Driver Information System) |
| MEMORY1 | 10A | Power Trunk Module, Driver/Passenger Seat Relay Module, Front Air Conditioner Controller, Driver/Passenger Power Seat Module, Air Conditioner Control Module, Driver/Passenger Power Seat Switch, Instrument Cluster, Rear Seat Relay Module Left Handle side/Right Handle side, Security Indicator, Rear Power Seat Switch Left Handle side/Right Handle side, Analog Clock, Head-Up Display, Rear LCD |
| E-SHIFTER1 | 10A | Electronic Auto Transmission Shift Lever (B+) |
| IBU2 | 10A | IBU (Integrated Body Control Unit) (IG1) |
| AIR BAG IINDICATOR | 10A | Instrument Cluster, Front Air Conditioner Controller |
| CURTAIN | 15A | IBU (Integrated Body Control Unit) (B+) |
| IBU1 | 15A | IBU (Integrated Body Control Unit) (B+) |
| MEMORY2 | 10A | Driver/Passenger Power Outside Mirror |
| DOOR AREA POWER CONTROL UNIT | 10A | Door Area power control Unit |
| AIR BAG2 | 10A | SRS (Supplemental Restraint System) Control Module |
| MODULE5 | 10A | Door Area power control Unit, Stop Lamp Switch |
| DOOR LOCK | 20A | Door Lock Relay, Door Unlock Relay |
| DRIVER POWER SEAT2 | 25A | Driver Power Seat Module, Driver Seat Relay Module, Driver Lumbar Support Unit |
| TRUNK LID | 10A | Trunk Lid Relay, Fuel Lid Relay, Fuel Filler Door & Trunk Lid Switch |
| MODULE9 | 10A | Multifunction Switch, Cooling Fan Controller (BLDC (Brushless Direct Current) Type), Surround View Monitor Unit, Rear Seat Armrest Console Switch |
| MODULE6 | 10A | IBU (Integrated Body Control Unit), 4WD (4 Wheel Drive) ECM (Electronic Control Module), ESC (Electronic Stability Control) Unit, Lane Keeping Assist Unit (Line), Crash Pad Switch, Steering Tilt & Telescopic Module |
| POWER HANDLE | 15A | Steering Tilt & Telescopic Module |
| REAR LH POWER SEAT2 | 15A | Rear Seat Relay Module Left Handle side (8WAY) |
| PASSENGER POWER SEAT2 | 25A | Passenger Power Seat Module, Passenger Seat Relay Module, Passenger Lumbar Support Unit |
| MODULE3 | 10A | Data Link Connector, Front Console Switch, Rain Sensor, Blind-Spot Collision Warning Unit Left Handle side/Right Handle side, Rear Seat Armrest Console Switch, Rain Sensor |
| MODULE7 | 10A | Multipurpose Check Connector, Multifunction Switch, Keyboard, Audio/Video & Navigation Head Unit, MTS (Mozen Telematics System) E-Call Module, Air Quality Sensor, AMP (Amplifier), Air Conditioner Control Module, Electro Chromic Mirror, Front Air Conditioner Controller, Driver/Passenger Seat Relay Module, Driver/Passenger Seat Warmer Control Module, Rear Seat Warmer Control Module Left Handle side/Right Handle side, Driver/Passenger Power Seat Module, Driver/Passenger CCS (Climate Control Seat) Module, Rear Seat CCS (Climate Control Seat) Module Left Handle side/Right Handle side, Rear Seat Armrest Console Switch |
| SUNROOF | 20A | Sunroof Control Unit (Glass) |
| REAR LH POWER SEAT1 | 25A | Rear Seat Relay Module Left Handle side |
| PASSENGER POWER WINDOW | 30A | Passenger Power Window Module, Rear Power Window Module Right Handle side |
| POWER OUTLET4 | 20A | Rear Seat Power Outlet |
| MODULE10 | 10A | IBU (Integrated Body Control Unit) (IG2) |
| E-SHIFTER2 | 10A | Electronic Auto Transmission Shift Lever Switch |
| DRIVER POWER SEAT1 | 30A | Driver Power Seat Module, Driver Seat Relay Module |
| PASSENGER POWER SEAT1 | 25A | Passenger Power Seat Module, Passenger Seat Relay Module |
| DRIVER POWER WINDOW | 30A | Driver Power Window Module, Rear Power Window Module Left Handle side |
| MODULE4 | 10A | Rear Seat Wireless Charger, Rear Seat Console Lamp, Keyboard, IBU (Integrated Body Control Unit), AMP (Amplifier), Rear Seat Audio Switch, Rear Seat USB Charger, MTS (Mozen Telematics System) E-Call Module, Audio/Video & Navigation Head Unit, Analog Clock, Front Tray Lamp, Surround View Monitor Unit, Front USB Charger, Front Wireless Charger, DIS (Driver Information System), Front Console Lamp, Electronic Auto Transmission Shift Lever Switch, Engine Room Junction Block (Power Outlet Relay) |
| AIR CONDITIONER3 | 10A | Engine Room Junction Block (Front Blower Relay), Rear LCD, Rear Sub Junction Block (Rear Blower Relay), Ionizer, Air Conditioner Control Module, Front Air Conditioner Controller |
| MODULE8 | 10A | [Auto Static] Auto Head Lamp Leveling Device Module, Head Lamp Left Handle side/Right Handle side |
Engine compartment fuse box:
| Fuse/Relay Name | Rating | Functions |
| ALT | 200A | Alternator, Fuse - R-MDPS, Multi Fuse #1 - COOLING FAN (BLDC)/COOLING FAN (DC)/B+5/B+3/POWER OUTLET1/ESC1/ESC2/ACC/IG2 |
| R-MDPS | 125A | Rack-MDPS (Motor Driven Power Steering) Unit |
| COOLING FAN (BLDC) | 80A | [BLDC (Brushless Direct Current) Type - Middle East] Cooling Fan Controller |
| B+5 | 60A | Instrument Panel Junction Block (Fuse - BRAKE SWITCH/MULTI MEDIA2/MULTI MEDIA1/INTERIOR LAMP/MULTI MEDIA4/MULTI MEDIA3/MEMORY1/E-CALL/MEMORY2/Door Area power control Unit) |
| B+3 | 60A | Instrument Panel Junction Block (Fuse - DRIVER POWER SEAT2/TRUNK LID/REAR LH POWER SEAT2/PASSENGER POWER SEAT2/REAR LH POWER SEAT1/PASSENGER POWER WINDOW/DRIVER POWER WINDOW) |
| POWER OUTLET1 | 40A | Power Outlet Relay |
| ESC1 | 40A | ESC (Electronic Stability Control) Control Module, Multipurpose Check Connector |
| ESC2 | 40A | ESC (Electronic Stability Control) Control Module |
| ACC | 40A | ACC Relay |
| IG2 | 30A | IG2 Relay |
| B+6 | 60A | Engine Control Relay, Fuse - HORN/WIPER/MODULE1/BURGLAR ALARM |
| B+1 | 60A | Instrument Panel Junction Block (Fuse - IBU1) |
| B+2 | 50A | Instrument Panel Junction Block (Fuse - E-SHIFTER1/AIR BAG2/MODULE3) |
| BLOWER | 40A | Front Blower Relay |
| IG1 | 40A | IG1 Relay |
| PRESAFETY SEAT BELT1 | 30A | Pre-Safe Seat Belt Control Unit |
| PRESAFETY SEAT BELT2 | 30A | Pre-Safe Seat Belt Control Unit |
| B+4 | 40A | Instrument Panel Junction Block (Fuse - CURTAIN/DOOR LOCK/POWER HANDLE/SUNROOF/DRIVER POWER SEAT1/PASSENGER POWER SEAT1) |
| AIR CONDITIONER2 | 10A | A/C2 Relay |
| 4WD | 20A | 4WD (4 Wheel Drive) ECM (Electronic Control Module) |
| FUEL PUMP | 20A | Fuel Pump Relay |
| AIR CONDITIONER1 | 10A | Air Conditioner Control Module |
| TCU2 | 20A | TCM (Transmission Control Module) |
| ECU3 | 15A | ECM (Engine Control Module) |
| START1 | 30A | Start1 Relay |
| ESC3 | 10A | ESC (Electronic Stability Control) Control Module |
| R-MDPS2 | 10A | Rack-MDPS (Motor Driven Power Steering) Unit |
| POWER OUTLET2 | 20A | Front Tray Power Outlet |
| HORN | 20A | Horn Relay |
| WIPER | 30A | Wiper Motor |
| WASHER | 15A | Washer Relay |
| TCU1 | 15A | TCM (Transmission Control Module), Start2 Relay |
| POWER OUTLET3 | 20A | Front Power Outlet |
| SENSOR1 | 15A | Fuel Pump Relay |
| IGNITION COIL | 20A | [Lambda II 3.3L/3.8L GDI Engine] Ignition Coil #1/#2/#3/#4/#5/#6 |
| MODULE1 | 10A | Active Air Flap |
| ECU2 | 10A | ECM (Engine Control Module) |
| MODULE2 | 10A | Active Air Flap, Smart Cruise Control Radar |
| BURGLAR ALARM | 10A | Burglar Alarm Horn Relay |
| ECU1 | 20A | ECM (Engine Control Module) |
| SENSOR3 | 15A | [Lambda II 3.3L Engine] Oxygen Sensor #1 (B1/S1), Oxygen Sensor #2 (B2/S1), Oxygen Sensor #3 (B1/S2), Oxygen Sensor #4 (B2/S2) |
| WIPER | 10A | [Lambda II 3.3L/3.8L GDI Engine] Oil Control Valve #1/#2/#3/#4 (Intake/Exhaust), Oil Pressure Solenoid Valve, Electronic Thermostat, Purge Control Solenoid Valve, Variable Intake Solenoid Valve #1/#2, A/C2 Relay |
Luggage compartment fuse box:
| Fuse/Relay Name | Rating | Functions |
| PASSENGER SEAT HEAT | 20A | Passenger CCS (Climate Control Seat) Module, Passenger Seat Warmer Control Module |
| DRIVER SEAT HEAT | 20A | Driver CCS (Climate Control Seat) Module, Driver Seat Warmer Control Module |
| REAR LH SEAT HEAT | 20A | Rear Seat CCS (Climate Control Seat) Module Left Handle side, Rear Seat Warmer Control Module Left Handle side |
| POWER DOOR RR LH | 15A | Rear Power Door Latch Left Handle side |
| REAR RH SEAT HEAT | 20A | Rear Seat CCS (Climate Control Seat) Module Right Handle side, Rear Seat Warmer Control Module Right Handle side |
| REAR RH POWER SEAT2 | 15A | Rear Seat Relay Module Right Handle side |
| POWER DOOR PASSENGER | 15A | Passenger Power Door Latch |
| ECS | 15A | ECS (Electronic Control Suspension) Unit |
| HEATED INDICATOR | 10A | Front Air Conditioner Controller |
| REAR LH POWER SEAT3 | 15A | Rear Seat Lumbar Support Unit Left Handle side |
| AMP | 25A | AMP (Amplifier) (Premium/Premium High |
| POWER TRUNK | 20A | Power Trunk Module |
| REAR RH POWER SEAT1 | 25A | Rear Seat Relay Module Right Handle side |
| REAR RH POWER SEAT3 | 15A | Rear Seat Lumbar Support Unit Right Handle side |
| REAR BLOWER | 20A | Rear Blower Relay |
| POWER DOOR DRIVER | 15A | Driver Power Door Latch |
| POWER DOOR REAR RH | 15A | Rear Power Door Latch Right Handle side |
| REAR HEATED | 30A | Rear Heated Relay |
Battery box fuse panel:
| Fuse/Relay Name | Rating | Functions |
| START | 80A |
Engine Room Junction Block (a) NON ISG : FUSE-TCU2/ECU3/START1 (b) ISG : FUSE-TCU2/ECU3/START1/POWER OUT- LET1/ACC/IG1 |
| B+7 | 100A | Rear fuse box panel |
| AMS | 10A | Battery Sensor |
