Kia Soul 2017 Fuse Box Info
Passenger fuse box location:
The fuse box is located at the left side of the steering column at the bottom of the instrument panel.
Engine compartment fuse box:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay Name | Rating | Functions |
| POWER OUTLET | 20A | P_OUTLET |
| ACC | 10A | O_S_MIRR_SW, AMP, AUDIO/UVO/AVN 4.0_HEAD UNIT, BCM, MOOD_LAMP_UNIT, SMK_UNIT, LDC_AMP(400W), LDC_AMP(200W), ISG, USB_CHARGER, ICM_BOX(POWER_OUTLET_RLY_COIL), E_CALL_UNIT |
| HEAD LAMP | 25A | C/LIGHT, REAR_P_OUTLET |
| DRL | 10A | BCM(DAY_RUNNNIG_LIGHT_LAMP_POWER) |
| MODULE 6 | 7.5A | SUNROOF_MOTOR, LUGGAGE_PORTABLE_LAMP(CHARGE_POWER), SEAT_EXTN_DRV(HEATED), REAR_SEAT(IGN2 |
| WIPER FRT 2 | 25A | FRONT_WIPER_MOTOR(POWER), FRONT_WIPER_RLY(LOW) |
| WIPER RR | 15A | REAR_WIPER_MOTOR, MULTI_FUNCTION_SW(WIPER), REAR_WIPER_RLY, REAR_WIPER_RLY_COIL |
| AMP | 30A | AMP, LDC_AMP(400W) |
| MODULE 5 | 7.5A | BCM, SMK_UNIT |
| WIPER FRT 1 | 10A | MULTI_FUNCTION_SW(WIPER), BCM(WASHER_MOTOR_POWER) |
| HEATED STEERING | 15A | STEERING_HEATED |
| A/CON 1 | 7.5A | AIR_CONTROL_UNIT(MANUAL, AUTO), IONIZER, PTC_RLY_COIL, BLOWER_RLY_COIL |
| HEATED MIRROR | 10A | OUTSIDE_MIRROR(HEATED), ECU(ELEC. LOAD DEFROST), AIR_CONTROL_UNIT_MANUAL/AUTO(HEATED_SIGNAL) |
| LIFTGATE OPEN | 15A | T/GATE_OPEN_RLY(T/GATE_LATCH_MOTOR), T/GATE_OPEN_RLY_COIL |
| S/HEATER FRT | 20A | FRONT_SEAT_EXTN(HEATED_POWER) |
| DR LOCK | 20A | DOOR_LOCK_RLY, DOOR_LOCK_RLY_COIL, DOOR_UNLOCK_RLY_COIL, DEAD_LOCK_RLY, DEAD_LOCK_RLY_COIL |
| A/BAG IND | 7.5A | CLUSTER |
| A/BAG | 15A | ACU, WCS_ECU |
| MODULE 4 | 10A | POWER_OUTLET_EXTN, HLLD_SW, AUDIO/UVO/AVN4.0_HEAD_UNIT, E_CALL_UNIT, I_S_MIRR_ECM, LDC_AMP(200W), LDC_AMP(200W), DIAGNOSIS, AUTO_HLLD_ECU, AIR_CONTROL_UNIT(MANUAL, AUTO), SEAT_EXTN_DRV, REAR_SEAT_WARMER_SW, REAR_SEAT_HEATER_UNIT |
| STOP LAMP | 15A | HAZARD_SW(ESS_INDICATOR_POWER), STOP_SIGNAL_ELECTRONIC_MODULE |
| MODULE 7 | 10A | KEY_LOCK_SOLENOID, OBD_II(POWER) |
| S/HEATER RR | 20A | REAR_SEAT(HEATED_POWER) |
| P/WDW RH | 25A | FRONT_P/WINDOW_SW(POWER), P/WINDOW_SAFETY_ECU(POWER) |
| P/WDW LH | 25A | FRONT_P/WINDOW_SW(POWER), P/WINDOW_SAFETY_ECU(POWER) |
| MODULE 1 | 10A | BCM, SPORTS_MODE_SW(ATM_SHIFT_LOCK_SOLENOID) |
| ABS | 10A | ABS/ESP_UNIT |
| MODULE 2 | 10A | LOWER_SW, CENTER_SW, STOP_LP_SW, WATER_FUEL_SNSR |
| MODULE 3 | 10A | HLLD_ACTR, TPMS_UNIT, BLIND_SPOT_DETECTOR, REAR_PARKING_ASSIST_SYSTEM_SNSR, SMART_PARKING_ASSIST_SYSTEM_SNSR, SMART_PARKING_ASSIST_SYSTEM_UNIT, LANE_DEPARTURE_WARNING_SYSTEM_UNIT, OIL_LEVEL_SNSR_EXTN |
| VACUUM PUMP 2 | 15A | VACUUM_PUMP |
| ECU | 7.5A | ENGINE_CONTROL_UNIT, AIR_FLOW_SNSR, START_RLY_COIL, SMK_UNIT, SMATRA_IMMOBILIZATION, GLOW_UN |
| IOD 2 | 15A | LDC_AMP(200W), AUDIO/UVO/AVN4.0_HEAD_UNIT |
| IOD 3 | 7.5A | E_CALL_UNIT |
| AEB | 15A | AUTONOMOUS_EMERGENCY_BRAKING_UNIT |
| CLUSTER | 10A | CLUSTER |
| TCU | 15A | SPEED_SNSR (MT), BACK_UP_LAMP_SW, OIL_PUMP_INVERTER, INHIBITOR, TRANSMISSION_CONTROL_UNIT |
| IOD 4 | 7.5A | TPMS_UNIT(POWER), CLUSTER, AIR_CONTROL_UNIT(MANUAL, AUTO), BCM, REARPARKING_ASSIST_SYSTEM_BUZZER, OUTSIDE_MIRROR_FOLDING_RLY, OUTSIDE_MIRROR_FOLDING_RLY_COIL, OUTSIDE_MIRROR_UNFOLDING_RLY, OUTSIDE_MIRROR_UNFOLDING_RLY_COIL, RAIN_SNSR |
| SPARE | 10A | - |
| SUNROOF 2 | 20A | SUNROOF_MOTOR(POWER) |
| P/SEAT DRV | 30A | SEAT_EXTN_DRV(POWER) |
| SUNROOF 1 | 20A | SUNROOF_MOTOR(POWER) |
| MDPS | 7.5A | MDPS_UNIT |
| A/CON 2 | 7.5A | AIR_CONTROL_UNIT_MANUAL(MAX_BLOWER), AIR_CONTROL_UNIT_AUTO(BLOWER_MOTOR) |
| START | 7.5A | E/R_FUSE & RELAY_BOX(RELAY - START / SUB START), PDM |
| IOD 1 | 7.5A | GLOVE_BOX_LAMP, DOOR_WARNING_SW, OVER_HEAD_CONSOLE_LAMP, PERSONAL_LAMP, SUNVISOR_LAMP, LUGGAGE_LAMP, PORTABLE_LAMP(DOOR) |
| PDM 2 | 7.5A | SMK_UNIT(BATT_CPU), SMATRA_IMMOBILIZATION(BATT) |
| P/SEAT PASS | 30A | SEAT_EXTN_PASS(POWER) |
| PDM 1 | 20A | SMK_UNIT(POWER) |
| BRAKE SWITCH | 10A | STOP_LAMP_SW(NORMAL_OPEN), SMK_UNIT |
Engine compartment fuse box:
| Fuse/Relay Name | Rating | Functions |
| IG1 | 40A | IGN_SW(B1), BUTTON_START_RLY(IG1), BUTTON_START_RLY(ACC) |
| BLOWER | 40A | BLOWER_RLY, BLOWER_MOTOR |
| REAR HEATED | 40A | REAR_GLASS_HEATED_RLY, REAR_GLASS_HEATED_RLY_COIL |
| ECU 2 | 30A | MAIN_RLY, MAIN_RLY_COIL |
| ECU 3 | 15A | ECU(AFTER_AIN_RELAY) |
| IGN COIL | 20A | IGNITION_COIL(POWER) |
| ECU 1 | 20A | ECU(AFTER_MAIN_RELAY) |
| SENSOR 1 | 10A | STOP_LAMP_SW(NORMAL_CLOSE), O2_SNSR, PURGE_CONTROL_SOLENOID_VALVE, OCV, PCSV, VIS, CAM_P_SNSR, CAM POSITION SENSOR, VGT_VACCUM |
| SENSOR 2 | 10A | CMP, COOLING_FAN_LOW_RLY_COIL, AIR_FLAP_SNSR, VIS , EGR_VALVE, O2_SNSR, LAMBDA_SNSR, WGV, EGR_ACTUATOR |
| INJECTOR | 10A | - |
| B/UP LAMP | 10A | RR_COMBI_LAMP(BACK_UP_LAMP) |
| WIPER | 10A | ECU(WIPER_SWITCH) |
| FUEL PUMP | 15A | FUEL_PUMP_MOTOR |
| HORN | 15A | HORN_RLY, HORN_RLY_COIL, HORN |
| TCU4 | 15A | TRANSMISSION_CONTROL_UNIT |
| A/CON | 10A | A/CON_RLY |
| H/LAMP WASHER | 20A | HEAD_LAMP_WASHER_RLY, HEAD_LAMP_WASHER_RLY_COIL, HEAD_LAMP_WASHER_MOTOR |
| POWER OUTLET 4 | 20A | P_OUTLET |
| B+ 1 | 50A | SMART_JUNCTION_BLOCK(B+1) |
| B+ 2 | 50A | SMART_JUNCTION_BLOCK(B+2) |
| TCU 3 | 30A | TRANSMISSION_CONTROL_UNIT |
| B+ 3 | 50A | SMART_JUNCTION_BLOCK(B+3) |
| IG2 | 40A | IGN_SW(IG2), BUTTON_START_RLY(IG2), START_RLY |
| MDPS | 80A | MDPS_UNIT |
| ALT (GAMMA) | 125A | ALTERNATOR |
| ALT (NU) | 180A | ALTERNATOR |
| TCU | 20A | TRANSMISSION_CONTROL_UNIT |
| DEICER | 20A | DEICER |
| ECU 4 | 15A | ECU(BATT_DIRECT) |
| ECU 5 | 15A | ECU(BATT_DIRECT) |
| POWER OUTLET 3 | 20A | P_OUTLET |
| VACUUM PUMP 1 | 10A | VACUUM_PUMP |
| COOLING FAN |
40A 60A |
COOLING_FAN_MOTOR, SUB_FUEL_PUMP, SUB_FUEL_VALVE, COOLING_FAN_PWM_MOTOR |
|
INVERTER TCU2 |
50A | OIL_PUMP_INVERTER, TRANSMISSION_CONTROL_UNIT |
| ABS 1 | 40A | ABS/ESP_UNIT(MOTOR) |
| ABS 2 | 30A | ABS/ESP_UNIT(SOLENOID) |
