Hyundai i10 2022 Fuse Box Info
Passenger compartment fuse box location:
The fuse box is located at the left side of the steering column at the bottom of the instrument panel, behind the cover.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay Name | Rating | Functions |
| HAZARD WARNING SIGNAL |
15A | TURN SIGNAL LAMP |
| DOOR LOCK | 20A | CENTRAL DOOR LOCK/UNLOCK |
| FRONT FOG LAMP |
15A | FRONT FOG LAMP |
| BRAKE SWITCH | 10A | STOP SWITCH |
| POWER WINDOW LH |
25A | POWER WINDOW LH |
| POWER WINDOW RH |
25A | POWER WINDOW RH |
| POWER WINDOW SAFETY |
25A | FRONT POWER WINDOW DRV SIDE |
| POWER OUTLET |
20A | FRONT POWER OUTLET |
| CIGAR LIGHTER |
15A | CIGAR LIGHTER |
| ACC | 10A | LDC, E-CALL, AUDIO/INFOTAINMENT SYSTEM, IBU, etc. |
| OUTSIDE MIRROR HEATED |
10A | OUTSIDE MIRROR LH/RH |
| AIR BAG INDICATOR |
7.5A | CLUSTER, MTC/FATC |
| AIR BAG 1 | 10A | ACU |
| AIR BAG 2 | 10A | ACU |
| INTERIOR LAMP | 10A | ROOM LP, LUGGAGE LP, GLOVE LP |
| MULTI MEDIA |
20A | AUDIO/INFOTAINMENT SYSTEM, LDC |
| MOTOR DRIVEN POWER STEERING |
7.5A | MDPS |
| SEAT HEATER |
20A | SEAT WARMER LH/RH |
| ANTI-LOCK BRAKE SYSTEM |
7.5A | ABS |
| CLUSTER | 7.5A | CLUSTER |
| HEATED STEERING |
7.5A | STEER’G HEATED |
| E-CALL (EMERGENCY CALL) |
7.5A | E-CALL |
| TRANSMISSION CONTROL UNIT |
15A | CLUTCH SW, TGS_LEVER, B/UP SW |
| ELECTRONIC (ENGINE) CONTROL UNIT |
10A | ECU |
| REAR FOG LAMP | 10A | REAR FOG LAMP |
| DAYTIME RUNNING LIGHT |
10A | DRL LAMP |
| WIPER SYSTEM RR |
15A | MF_SW, REAR WIPER MOTOR |
| WINDSCREEN WIPING SYSTEM (CONTINUOUS) |
20A | MF_SW, FRONT WIPER MOTOR |
| START | 7.5A | START RLY |
| AIR CONDITIONER 1 |
7.5A | MTC/FATC, BLOWER RLY |
| AIR CONDITIONER 2 |
7.5A | FATC, BLOWER MOTOR |
| MODULE 1 | 7.5A | STOP SW |
| MODULE 2 | 10A | MFC, IBU(PDW-R), ESC SW, CONSOLE_SW |
| MODULE 3 | 7.5A | MTC/FATC, TGS_LEVER_AMT_IND, OBD, E-CALL, HLLD, AUDIO/INFOTAINMENT SYSTEM, LDC, WPC |
| MODULE 4 | 7.5A | IBU/SLM |
| MODULE 5 | 10A | IBU, S_HTD |
| MODULE 6 | 10A | HAZARD DO LOCK SW, OBD |
| MEMORY | 10A | MTC/FATC, CLUSTER |
| IBU (INTEGRATED BODY CONTROL UNIT) |
15A | IBU |
| IBU (INTEGRATED BODY CONTROL UNIT) |
10A | IBU |
| SPARE | 10A | - |
Engine compartment fuse box:
| Fuse/Relay Name | Rating | Functions |
| MAIN | 30A | ECU (MT, AMT) |
| FUEL PUMP | 20A | FUEL PUMP |
| COOLING FAN 1 | 35A | C/FAN MOTOR HI |
| COOLING FAN 2 | 35A | C/FAN MOTOR LOW |
| AIR CONDITIONER |
20A | A/CON COMP |
| START | 20A | ECU |
| BUGLER ALARM HORN |
20A | BUGLER ALARM HORN |
| HORN | 20A | HORN |
| BLOWER | 35A | ICU, BLOWE MOTOR |
| ALTERNATOR | 125/150A | ALTERNATOR |
| MOTOR DRIVEN POWER STEERING |
80A | MDPS |
| BLOWER | 40A | ICU, BLOWE MOTOR |
| REAR HEATED | 30A | ICU, REAR HEATED |
| AMT 1 | 40A | AMT |
| AMT 2 | 40A | AMT |
| BATTERY 1 | 30A | ICU |
| BATTERY 2 | 30A | ICU |
| BATTERY 3 | 50A | ICU |
| BATTERY 4 | 50A | ICU |
| COOLING FAN | 30/40A | C/FAN MOTOR |
| ELECTRONIC STABILITY CONTROL 1 |
40A | ESC |
| ELECTRONIC STABILITY CONTROL 2 |
40A | ESC |
| POWER OUTLET |
40A | POWER OUTLET |
| IGNITION 1 | 30A | ICU |
| IGNITION 2 | 30A | ICU, START SOL |
| ELECTRONIC (ENGINE) CONTROL UNIT 1 |
30A | ECU |
| BACK UP LAMP | 10A | BACK UP LAMP |
| WINDSCREEN WIPING SYSTEM (CONTINUOUS) |
10A | ECU |
| FUEL PUMP | 15A | FUEL PUMP |
| HORN | 15A | HORN |
| AIR CONDITIONER |
10A | A/CON COMP |
| ELECTRONIC (ENGINE) CONTROL UNIT 2 |
15A | MAIN RLY |
| ELECTRONIC (ENGINE) CONTROL UNIT 3 |
15A | MAIN RLY |
| ELECTRONIC (ENGINE) CONTROL UNIT 4 |
15A | MAIN RLY |
| INJECTOR | 15A | INJECTOR |
| IGNITION COIL | 15A | IGNITION COIL |
| AMT 3 | 15A | AMT |
| ALTERNATOR MANAGEMENT SYSTEM |
10A | BATT SENSOR |
