Hyundai Genesis Sedan 2012 Fuse Box Info
Passenger compartment fuse box location:
The fuse box is located on the left hand side of the instrument panel facing the driver’s side door.
The fuse box is located on the right hand side of the instrument panel facing the passenger’s side door.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box (Driver’s side):
| Fuse/Relay Name | Rating | Functions |
| P/WDW (LH) | 30A | Driver Power Window Module, Rear Door Module LH |
| P/WDW (RH) | 30A | Passenger Power Window Module, Rear Door Module RH |
| MODULE 2 | 10A | Console Switch LH/RH, ECS Control Module, Steering Angle Sensor, Key Lock Module,Tire Pressure Monitoring Module |
| CURISE SW | 10A | Multifunction Switch, Crash Pad Switch, A/C Control Module, Instrument Cluster, Rear Seat Warmer Module LH, Driver Seat Warmer Module Rear Seat Warmer Module RH, Passenger Seat Warmer Module, Passenger CCS Control Module, Driver CCS Control Module, Generator |
| START | 10A | Transaxle Range Switch |
| PDM 2 | 10A | FOB Holder, Start Stop Button Switch |
| CLUSTER | 10A | Instrument Cluster |
| A/CON(IG1) | 10A | A/C Control Module |
| KEY ILLUMINATION | 10A | Start Stop Button Switch, Door Warning Switch, Fob Holder, Key Solenoid |
| IG KEY SUPPLY | 30A | E/R Junction Box Fuse (INHIBITOR SW 15A, ECU-2 10A, EHPS 10A, CRUISE 10A, TCU 15A, ESP 10A,STOP LP 10A, AFLS 10A) |
| NTELLIGENT A/PEDAL | 10A | Intelligent Accel Pedal Unit |
| DR LOCK DRV | 10A | Driver Door Module |
| STOP LP | 10A | Stop Lamp Switch |
| A/BAG IND | 10A | Instrument Cluster (Air Bag IND.) |
| AFLS | 10A | Auto Head Lamp Leveling Device Sensor, Adaptive Front Lighting Module, Head Lamp LH, Head Lamp RH |
| PDM 1 | 10A | PDM |
| SECURITY LP | 10A | Data Link Connector, Auto Light Sensor & Security Indicator, Rear Door Module LH/RH,Shift Lock |
| MODULE 1 | 10A | FAM, IPM, Tilt & Telescopic Module, PDM, Driver Door Module, Passenger Door Module, IMS Control Module, Multifunction Switch, Electronic Parking Brake Module, Power Trunk Lid Control Module, Forward & Rear Parking Assist Control Module |
| MODULE 3 | 10A | FAM, Multifunction Switch, Tilt & Telescopic Module, Instrument Cluster, Driver Door Module, Passenger Door Module, Power Trunk Lid Control Module, IMS Control Module, Rear Curtain Module |
| P/HANDLE | 15A | Tilt & Telescopic Module |
| ECS | 15A | ECS Control Module |
| A/BAG | 15A | SRS Control Module |
| AUDIO(B+) | 15A | Audio, Front Monitor, AV Head Module, Rear Monitor (With AV), Rear Audio Switch, Media Module (With AV) |
| S/HEATER DRV | 15A | Driver CCS Control Module, Driver Seat Warmer Module (W/O CCS) |
| P/TRUNK | 30A | Power Trunk Lid Control Module |
| F/LID | 10A | Trunk Lid & Fuel Filler Door Switch (Fuel Filler Door Switch) |
| AUDIO(IG1) | 10A | AV Head Module, Audio, Active Headrest Sensor Module |
| RF RECEIVER | 10A | RF Receiver |
| A/CON(B+) | 10A | A/C Control Module,Tire Pressure Monitoring Module |
| I.O.D | 30A | I/P Junction Box LH Fuse (MODULE 3 10A, AUDIO(B+) 15A ,Rf Receiver 10A , A/CON(IG1) 15A) |
Passenger compartment fuse box (Passenger’s side):
| Fuse/Relay Name | Rating | Functions |
| CURTAIN (RR) | 10A | Rear Curtain Module |
| MIRROR | 10A | Driver Door Module, Passenger Door Module |
| IG KEY SUPPLY | 30A | E/R Junction Box Fuse (AQS 10A, WASHER 15A) |
| SUNROOF | 20A | Overhead Console Lamp |
| CONSOLE SW | 10A | Console Switch LH/RH, Piezo Buzzer |
| A/CON(IG2) | 10A | Active Incar Sensor, A/C Control Module |
| P/SEAT PASS | 20A | Passenger Power Seat Relay Box |
| S/HEATER RR | 20A | Rear Seat Warmer Module LH/RH, Rear Power Seat Control Switch |
| MODULE 1 | 10A | Instrument Cluster, Rheostat, Driver CCS Control Module, Passenger CCS Control Module, PDM, IPM |
| MODULE 3 | 10A | Electro Chromic Mirror, Overhead Console Lamp, Rain Sensor, Rear Curtain Module, Camera Module |
| S/HEATER PASS | 20A | Passenger CCS Control Module, Passenger Seat Warmer Module |
| DR LOCK PASS | 15A | Passenger Door Module |
| P/SEAT RR | 10A | Rear Power Seat Relay Box, Rear Slide Limit Switch LH |
| HTD STRG | 15A | Steering Wheel Heater |
| P/OUTLET RR | 15A | Rear Accessory Socket |
| P/OUTLET FRT | 10A | ACC Socket Relay |
| MODULE 2 | 10A | A/C Control Module, IPM, PDM, Key Lock Module |
| PDM | 25A | PDM |
| AUDIO | 10A | Audio, Camera Module, Rear Audio Switch, Front Monitor, Media Module, AV Head Module |
Engine compartment fuse boxes:
| Fuse/Relay Name | Rating | Functions |
| ALT | 200A | Generator |
| I/P LH PWR | 60A | I/P Junction Box LH |
| I/P RH PWR | 60A | I/P Junction Box RH |
| C/FAN | 60A | Cooling Fan Relay |
| EHPS | 80A | EHPS Module |
| AIR ECS | 40A | ECS Compressor Relay |
| AMP 1 | 40A | AV JBL AMP |
| AMP 2 | 30A | AMP |
| PDM(ACC) | 30A | PDM (ACC) Relay |
| VDC/ESC 1 | 30A | VDC/ESC Control Module, Multipurpose Check Connector |
| VDC/ESC 2 | 30A | VDC/ESC Control Module, Multipurpose Check Connector |
| PDM(IG1) | 30A | PDM (IG1) Relay |
| PDM(IG2) | 30A | PDM (IG2) Relay |
| P/SEAT DRV | 30A | Driver Power Seat Relay Box, IMS Control Module, Driver Lumbar Support Switch |
| H/LP WASHER | 20A | Head Lamp Washer Relay |
| VACUUM PUMP | 20A | Brake Vacuum Pump Relay |
| P/OUTLET FRT | 25A | ACC Socket Relay |
| TRUNK | 10A | Trunk Lid Relay |
| IMS | 10A | - |
| STOP LP | 10A | Stop Lamp Relay, Stop Lamp Switch, IPM |
| B/UP LP | 10A | Rear Combination Lamp LH/RH (IN), Electro Chromic Mirror, Camera Module, Rear Curtain Module |
| ECU | 30A | Engine Control Relay |
| BLOWER | 40A | Blower Relay |
| IGN SW 2 (PRESAFETY PASS) | 40A | gnition Switch (IG 2, START), Presafety Seat Belt Passenger |
| RR HTD | 40A | E/R Junction Box Fuse (AQS 10A, WASHER 15A) |
| IGN SW 1 (PRESAFETY DRV) | 40A | Ignition Switch (IG 1, ACC), Presafety Seat Belt Driver |
| A/CON | 10A | A/C Control Module |
| EPB 1 | 15A | Electric Parking Brake Module |
| EPB 2 | 15A | Electric Parking Brake Module |
| HORN | 15A | Horn Relay |
| IPM | 10A | IPM, Head Lamp (Low) Relay |
| AQS | 10A | AQS Sensor, Electronic Control Wiper Module, Blower Relay |
| DEICER | 15A | Heated Glass (FR) Relay |
| WASHER | 15A | Washer Relay |
| WIPER | 30A | Wiper Motor |
| HTD MIRR | 10A | A/C Control Module, Power Outside Mirror & Mirror Folding Motor LH/RH |
| TCU | 15A | TCM |
| AFLS | 10A | Head Lamp LH/RH |
| EHPS | 10A | EHPS Module |
| VDC/ESC | 10A | ESC Control Module, Multipurpose Check Connector |
| ECU(IG1) | 10A | ECM |
| IGN COIL | 20A | Ignition Coil #1,2,3,4,5,6 |
| INJECTOR(B+) | 15A | Injector Drive Box |
| SENSOR 1 | 10A | ECM, Mass Air Flow Sensor, Oxygen Sensor #1,2,3,4 |
| SENSOR 2 | 10A | Canister Purge Control Solenoid Valve, Variable Intake Manifold Valve, Oil Control Valve, ECM, Cooling Fan Relay, Immobilizer Module, Fuel Pump Resister |
| SENSOR 3 | 10A | ECM, Injector #1~#6, Fuel Pump Relay |
| H/LP RH | 15A | Head Lamp RH |
| H/LP LH | 15A | Head Lamp LH |
| INJECTOR(IG1) | 10A | Injector Drive Box |
| CRUSIE | 10A | Smart Cruise Control Module |
| STOP LP | 10A | Stop Lamp Switch, Stop Lamp Relay, Generator,Vacuum Sw |
| ECU(B+) | 15A | ECM,TCM,Injector Drive Box |
| ROOM LP | 10A | Room Lamp Relay |
| F/PUMP | 20A | Fuel Pump Relay |
| START | 30A | Start Solenoid |
