Honda Accord 2013 Fuse Box

Honda Accord 2013 Fuse Box Info



Fuse box location:

The interior fuse box is under the dashboard on the driver’s side.



Engine compartment fuse box:





Fuse Box Diagram | Layout



Passenger compartment fuse box:

Fuse/Relay N° Rating Functions
1 7.5A A/C
2 7.5A DRL
3 - -
4 - -
5 7.5A Meter
6 7.5A SRS
7 (7.5A) Option*
8 10A MISS SOL
9 20A Fuel Pump
10 7.5A ABS/VSA
11 - -
12 7.5A Front Wiper
13 15A ACG
14 (20A) Rear Accessory Power Socket (Console Compartment)
15 (20A) Driver’s Power Seat Reclining*
16 (20A) Moonroof*
17 (20A) Front Seat Heaters*
18 - -
19 10A Passenger Side Door Unlock
20 10A Driver Side Rear Door Unlock
21 10A Driver’s Door Lock
22 10A Passenger Side Door Lock
23 10A Driver’s Door Unlock
24 10A SRS
25 10A Illumination
26 7.5A Key Lock
27 10A Parking Lights
28 (10A) Lumbar Support*
29 10A Right Headlight High Beam
30 15A Washer
31 (10A) SMART*
32 20A Driver’s Power Window
33 20A Front Passenger’s Power Window
34 20A Rear Driver Side Power Window
35 20A Rear Passenger Side Power Window
36 (20A) Driver’s Power Seat Sliding*
37 7.5A ACCESSORY
38 - -
39 10A Left Headlight High Beam
40 20A Accessory Power Socket (Console Panel)
41 10A Driver Side Rear Door Lock
42 20A Door Lock
a (7.5A) Audio*
b (20A) ACM*
c (15A) Rear Seat Heaters*
d (20A) Premium Amp*
e - -
f - -
g (20A) Passenger’s Power Seat Reclining*
h (20A) Passenger’s Power Seat Sliding*

* Not available on all models



Engine compartment fuse box:

Fuse/Relay N° Rating Functions
1 125A Battery
2 70A EPS
  (60A) Fuse Box Main 1
  (40A) Fuse Box Option 1
  - -
  - -
  40A ABS/VSA FSR
  30A ABS/VSA Motor
3 - -
  - -
  - -
  - -
4 (15A) Front Fog Light*
5 10A Horn
6 10A Stop Light
7 15A FI Sub
8 (7.5A) DRL
9 15A IG Coil
10 20A Injector*2
11 15A Hazard
12 60A Fuse Box Main 2
  (40A) Fuse Box Option 2


50A

30A*4

IG Main 1
  30A IG Main 2*4


20A*2

30A*3

Sub Fan Motor
  30A Headlight Low Beam Main
  30A Fuse Box
  30A Wiper Motor
  30A Main Fan Motor
  30A Starter Motor*4
13 40A Rear Defogger
14 40A Heater Motor
15 15A FI Main
16 (10A) Heated Door Mirror*
17 7.5A MG Clutch
18 15A DBW
19 20A Small Light
20 7.5A Interior Light
21 10A Back Up
22 10A Audio
23 7.5A Fan Timer
24

10A

15A*5

Right Headlight Low Beam
25

10A

15A*5

Left Headlight Low Beam
26 - -

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

*2: 4-cylinder models

*3: 6-cylinder models

*4: Models with smart entry system

*5: Models with LED low beam headlights
