Honda Accord 2006 Fuse Box Info
Fuse box location:
The interior fuse box is on the driver’s lower left side.
Engine compartment fuse box:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
Fuse/Relay N° | Rating | Functions |
1 | 15A | Drive by Wire |
2 | 15A | Ignition Coi |
3 | 10A | Day Light |
4 | 15A | Laf Heater |
5 | 10A | Radio |
6 | 7.5A | Interior Light |
7 | 10A | Back-Up Lights |
8 | 20A | Door Lock |
9 | 15A | Front Accessory Sockets |
10 | 7.5A | IG OPDS |
11 | 30A | IG Wiper |
12 | - | Not used |
13 | 20A | Passenger’s Power Seat Recline** |
14 | 20A | Driver’s Power Seat Slide** |
15 | 20A | Heated Seat** |
16 | 20A | Driver’s Power Seat Recline** |
17 | 20A | Passenger’s Power Seat Slide** |
18 | 15A | IG ACG |
19 | 15A | IG Fuel Pump |
20 | 7.5A | IG Washer |
21 | 7.5A | IG Meter |
22 | 10A | IG SRS |
23 | 7.5A | IGP (PGM-FI ECU) |
24 | 20A | Left Rear Power Window |
25 | 20A | Right Rear Power Window |
26 | 20A | Right Front Power Window |
27 | 20A | Driver’s Power Window |
28 | 20A | Moonroof*** |
29 | - | Not used |
30 | 7.5A | IG HAC |
31 | - | Not used |
32 | 7.5A | ACC |
33 | 7.5A | HAC OP |
* U.S. models
** U.S. EX, EX-L, LX-V6 and EX-V6 Canadian EX-L, SE-V6 and EX-V6
*** U.S. EX, EX-L, LX-V6 and EX-V6 Canadian SE, EX-L, SE-V6 and EX-V6
Engine compartment fuse box:
Fuse/Relay N° | Rating | Functions |
1 | 10A | Left Headlight Low |
2 | 30A | Rear Defroster Coil* |
3 | 10A | Left Headlight Hi |
4 | 15A | Small Light |
5 | 10A | Right Headlight Hi |
6 | 10A | Right Headlight Low |
7 | 7.5A | Back Up |
8 | 15A | FI ECU |
9 | 20A | Condenser fan |
10 | - | Not Used |
11 |
20A 30A |
Cooling Fan** Cooling Fan*** |
12 | 7.5A | MG. Clutch |
13 | 20A | Horn, Stop |
14 | 40A | Rear Defroster |
15 | 40A | Back Up, ACC |
16 | 15A | Hazard |
17 |
30A 30A |
ABS Motor** TCS Motor*** |
18 |
20A 40A |
ABS F/S** TCS*** |
19 | 40A | Ignition Coil, DRL (Canada) |
20 | 40A | Power Seats, Seat Heaters**** |
21 | 40A | Heater Motor |
22 |
100A - |
Battery Not Used |
23 |
50A 50A |
+B IG1 Main Power Window Main |
* U.S. EX, EX-L LX-V6 and EX-V6 Canadian SE, EX-L, SE-V6 and EX-V6
** U.S. VP, LX, SE, EX and EX-L Canadian DX-G, SE and EX-L
*** U.S. LX-V6 and EX-V6 Canadian SE-V6 and EX-V6
**** Except Canadian DX-G
