Honda Accord 2008 Fuse Box Info
Fuse box location:
The driver’s side interior fuse box is under the dashboard on the driver’s side. The fuse label is attached on the side panel. The passenger’s side interior fuse box is on the lower right side panel.
Engine compartment fuse box:
Fuse Box Diagram | Layout
Passenger compartment fuse box (Driver’s side):
| Fuse/Relay N° | Rating | Functions |
| 1 | - | Not Used |
| 2 | - | Not Used |
| 3 | 15A | Washer |
| 4 | 7.5A | Wiper |
| 5 | 7.5A | Meter |
| 6 | 7.5A | ABS/VSA |
| 7 | 15A | ACG |
| 8 | 7.5A | STS |
| 9 | 20A | Fuel Pump |
| 10 | 10A | VB SOL |
| 11 | 10A | SRS |
| 12 | 7.5A | ODS (Occupant Detection System) |
| 13 | - | Not Used |
| 14 | 10A | ACM* |
| 15 | 7.5A | Daytime Running Lights |
| 16 | 7.5A | A/C |
| 17 | 7.5A | Accessory, Key, Lock |
| 18 | 7.5A | Accessory |
| 19 | 20A | Driver’s Power Seat Sliding* |
| 20 | 20A | Moonroof* |
| 21 | 20A | Driver’s Power Seat Reclining* |
| 22 | 20A | Rear Left Power Window |
| 23 | 15A | Front Accessory Power Socket |
| 24 | 20A | Driver’s Power Window |
| 25 | 10A | Driver’s Side Door Lock |
| 26 | 10A | Left Front Fog Light* |
| 27 | 10A | Left Side Small Lights (Exterior) |
| 28 | 10A | Left Headlight High Beam |
| 29 | 7.5A | TPMS |
| 30 | 10A | Left Headlight Low Beam |
| 31 | - | Not Used |
* If equipped
Passenger compartment fuse box (Passenger’s side):
| Fuse/Relay N° | Rating | Functions |
| 1 | 10A | Right Headlight High Beam |
| 2 | 10A | Right Side Small Lights (Exterior) |
| 3 | 10A | Right Front Fog Light* |
| 4 | 10A | Right Headlight Low Beam |
| 5 | - | Not Used |
| 6 | 7.5A | Interior Lights |
| 7 | - | Not Used |
| 8 | 20A | Front Passenger’s Power Seat Reclining* |
| 9 | 20A | Front Passenger’s Power Seat Sliding* |
| 10 | 10A | Right Side Door Lock |
| 11 | 20A | Rear Right Power Window |
| 12 | 15A | Rear Accessory Power Socket |
| 13 | 20A | Front Passenger’s Power Window |
| 14 | - | Not Used |
| 15 | 20A | Premium AMP* |
| 16 | - | Not Used |
| 17 | - | Not Used |
| 18 | 10A | Lumbar Support* |
| 19 | 15A | Seat Heater* |
| 20 | - | Not Used |
| 21 | - | Not Used |
| 22 | - | Not Used |
* If equipped
Engine compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1-1 |
100A 120A |
Battery* Battery** |
| 1-2 | 40A | Passenger’s Side Fuse Box |
| 2-1 | - | Not Used |
| 2-2 | 40A | ABS/VSA |
| 2-3 | 30A | ABS/VSA Motor |
| 2-4 | 40A | Passenger’s Side Fuse Box |
| 2-5 | - | Not Used |
| 2-6 | - | Not Used |
| 3-1 |
- 30A |
Not Used* Sub Fan Motor** |
| 3-2 | 30A | Wiper Motor |
| 3-3 | 30A | Main Fan Motor |
| 3-4 | 30A | Driver’s Side Light Main |
| 3-5 | 60A | Driver’s Side Fuse Box |
| 3-6 | 30A | Passenger’s Side Light Main |
| 3-7 | 40A | Driver’s Side Fuse Box |
| 3-8 | 50A | IG Main |
| 4 | 40A | Rear Defroster |
| 5 |
20A - |
Sub Fan Motor* Not Used** |
| 6 | - | Not Used |
| 7 | - | Not Used |
| 8 | 40A | Heater Motor |
| 9 | 15A | Hazard |
| 10 | 20A | Horn, Stop |
| 11 | - | Not Used |
| 12 | - | Not Used |
| 13 | 15A | IG Coil |
| 14 | 15A | FI Sub |
| 15 | 10A | Back Up |
| 16 | 7.5A | Interior Lights |
| 17 | 15A | FI Main |
| 18 | 15A | DBW |
| 19 |
- 7.5A |
Not Used* Back Up, FI ECU** |
| 20 | 7.5A | MG Clutch |
| 21 | 7.5A | Fan Relay |
* 2.4 engine models
** V6 models
