Honda Fit 2008 Fuse Box Info
Passenger compartment fuse box location:
The interior fuse box is behind the driver’s coin tray.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | 10A | Back Up Light |
| 2 | - | Not Used |
| 3 | 10A | METER |
| 4 | 10A | Turn Light |
| 5 | - | Not Used |
| 6 | 30A | Front Wipers |
| 7 | 10A | SRS |
| 8 | (7.5A) | Daytime Running Light*2 |
| 9 | 20A | Rear Defogger |
| 10 | 7.5A | HAC |
| 11 | 15A | Fuel Pump |
| 12 | 10A | Rear Wiper |
| 13 | 10A | SRS |
| 14 | 15A | IGP |
| 15 | 20A | Left Rear Power Window |
| 16 | 20A | Right Rear Power Window |
| 17 | 20A | Right Front Power Window |
| 18 |
(7.5A) (10A) |
TPMS*1 Daytime Running Light*2 |
| 19 | - | Not Used |
| 20 | - | Not Used |
| 21 | (20A) | Fog Light*1 |
| 22 | 10A | Small Light |
| 23 | 10A | LAF |
| 24 | - | Not Used |
| 25 | 7.5A | ABS |
| 26 | 7.5A | Radio |
| 27 | 15A | ACC Socket |
| 28 | (20A) | Power Door Lock*1 |
| 29 | 20A | Driver’s Power Window |
| 30 | - | Not Used |
| 31 | 7.5A | LAF |
| 32 | 15A | DBW |
| 33 | 15A | Ignition Coil |
*1 If equipped
*2 Canadian models
Engine compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | 80A | Battery |
| 2 | 60A | EPS |
| 3 | 50A | Ignition |
| 4 | 30A | ABS |
| 5 | 40A | Blower Relay |
| 6 | 40A | Power Window |
| 7 | (30A) | (HAC Option) |
| 8 | 10A | Back Up |
| 9 | 30A | Small Light |
| 10 | 30A | Cooling Fan |
| 11 | 30A | Condenser Fan, MG Clutch* |
| 12 | 20A | Right Headlight |
| 13 | 20A | Left Headlight |
| 14 | 10A | Hazard |
| 15 | 30A | ABS F/S |
| 16 | 15A | Horn, Stop |
* If equipped
Secondary Fuse Box (On the battery):
| Fuse/Relay N° | Rating | Functions |
| 80A | Battery |
