Honda Odyssey 2015 Fuse Box Info
Passenger compartment fuse box location:
The driver’s side interior fuse box is under the dashboard on the driver’s side. The fuse label is attached to the side panel. The passenger’s side interior fuse box is under the dashboard. Push down the tab and slide the cover upward to remove it.
Engine compartment fuse box location:
The primary under-hood fuse box is located on the passenger’s side. The secondary fuse box is located next to the battery.
Luggage compartment fuse box location:
The rear fuse box is located at the left side of cargo area.
Fuse Box Diagram | Layout
Passenger compartment fuse box (Driver’s Side):
| Fuse/Relay N° | Rating | Functions |
| 1 | 7.5A | Front Passenger's Door Lock |
| 2 | 7.5A | Rear Passenger's Door Lock |
| 3 | 7.5A | Driver’s Door Lock |
| 4 | 7.5A | Front Passenger's Door Unlock |
| 5 | 7.5A | Rear Passenger's Door Unlock |
| 6 | 7.5A | Driver’s Door Unlock |
| 7 | 20A | Door Lock Main |
| 8 | 10A | HAC Option* |
| 9 | (20A) | Driver’s Side Power Slide Door Closer* |
| 10 | 15A | Rear Fuse Box |
| 11 | 7.5A | Meter |
| 12 | 20A | Engine Compartment Fuse Box (Passenger Side) |
| 13 | 7.5A | Accessory |
| 14 | 7.5A | STS* |
| 15 | 20A | Driver’s Power Seat Sliding |
| 16 | 20A | Moonroof* |
| 17 | 20A | Rear Driver’s Side Power Window |
| 18 | (10A) | Smart Entry System* |
| 19 | 20A | Driver’s Power Window |
| 20 | - | - |
| 21 | 20A | Fuel Pump |
| 22 | 15A | Passenger’s Side Fuse Box |
| 23 | 7.5A | VSA |
| 24 | 7.5A | ACG AS |
| 25 | 7.5A | STRLD |
| 26 | 7.5A | HAC |
| 27 | (7.5A) | DRL |
| 28 | 7.5A | ACC Key Lock |
| 29 | (7.5A) | Driver’s Power Seat Lumbar Support* |
| 30 | 7.5A | TPMS |
| 31 | - | - |
| 32 | 20A | Driver’s Power Seat Reclining |
| 33 | (40A) | Driver’s Side Power Slide Door Motor* |
| 34 | - | - |
* Not available on all models
Passenger compartment fuse box (Passenger’s Side):
| Fuse/Relay N° | Rating | Functions |
| 1 | (30A) | Premium Amp* |
| 2 | 20A | Rear Passenger’s Side Power Window |
| 3 | 10A | ACM |
| 4 | - | - |
| 5 | (15A) | Seat Heaters* |
| 6 | - | - |
| 7 | (20A) | Front Passenger’s Power Seat Sliding |
| 8 | (20A) | Front Passenger’s Power Seat Reclining |
| 9 | - | - |
| 10 | - | - |
| 11 | - | - |
| 12 | - | - |
| 13 | (20A) | Passenger’s Side Power Slide Door Closer* |
| 14 | 15A | Rear Accessory Power Socket |
| 15 | - | - |
| 16 | - | - |
| 17 | - | - |
| 18 | 20A | Front Passenger’s Power Window |
| 19 | 10A | SRS |
| 20 | 7.5A | ECU AS |
| 21 | (7.5A) | Headlight Adjuster* |
| 22 | - | - |
| 23 | (7.5A) | OPDS* |
| 24 | (7.5A) | OPDS* |
| 25 | 7.5A | Illumination (Interior) |
| 26 | - | - |
| 27 | 15A | Front Accessory Power Socket |
| 28 | - | - |
* Not available on all models
Engine compartment fuse box (Passenger’s Side):
| Fuse/Relay N° | Rating | Functions |
| 1 | - | - |
| 2 | - | - |
| 3 | 15A | ACG FR |
| 4 | 15A | Washer |
| 5 | 7.5A | VB SOL |
| 6 | 7.5A | ECU FR |
| 7 | - | - |
| 8 | 15A | FI Sub |
| 9 | 15A | DBW |
| 10 | 15A | FI Main |
| 11 | 15A | Ignition Coil |
| 12 | - | - |
| 13 | - | - |
| 14 | - | - |
| 15 | 20A | Radio |
| 16 | 10A | Back Up |
| 17 | 7.5A | MG Clutch |
| 18 | (20A) | Front Fog Lights* |
| 19 | - | - |
| 20 | 10A | Right Headlight High Beam |
| 21 | - | - |
| 22 | 10A | Small Lights |
| 23 | - | - |
| 24 | 10A | Left Headlight High Beam |
| 25 | - | - |
| 26 | 15A | Right Headlight Low Beam |
| 27 | 15A | Left Headlight Low Beam |
| 28 | 7.5A | Oil Level |
| 29 | 30A | Main Fan |
| 30 | 30A | Sub Fan |
| 31 | 30A | Wiper Main |
* Not available on all models
Engine compartment fuse box (Driver’s Side):
| Fuse/Relay N° | Rating | Functions |
| 1 | 125A | Main Fuse |
| 2-1 | 60A | Fan Main |
| 2-2 | 50A | Passenger’s Side Fuse Box 2 |
| 2-3 | (60A) | HondaVACTM* |
| 2-4 | 30A | Interior Light, FI Main |
| 2-5 | 30A | Stop & Horn, Hazard |
| 2-6 | 30A | Rear Blower, Battery Management System |
| 2-7 | 30A | VSA FSR |
| 2-8 | 40A | VSA Motor |
| 3-1 | 50A | Driver’s Side Fuse Box 2 |
| 3-2 | 50A | IG1 Main *1 |
| 3-2 | 40A | Starter Motor *2 |
| 3-3 | 60A | Rear Fuse Box 1 |
| 3-4 | 50A | Passenger’s Side Fuse Box 1 |
| 3-5 | 50A | Driver’s Side Fuse Box 1 |
| 3-6 | 60A | Engine Compartment Fuse Box (Passenger Side) Main |
| 3-7 | (40A) | Passenger’s Side Power Sliding Door Motor* |
| 3-8 | 40A | Front Blower |
| 4 | 40A | Rear Defroster |
| 5 | - | - |
| 6 | 30A | IG Main 2* |
| 7 | 30A | IG Main 1* |
| 8 | 7.5A | Battery Management System |
| 9 | 20A | Stop & Horn |
| 10 | 15A | Hazard |
| 11 | 7.5A | Interior Lights |
* Not available on all models
*1 Models without smart entry system
*2 Models with smart entry system
Luggage compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | (20A) | Power Tailgate Closer* |
| 2 | (7.5A) | Trailer Small Light* |
| 3 | - | - |
| 4 | (10A) | Tailgate* |
| 5 | 7.5A | Rear Driver’s Side Door Lock |
| 6 | - | - |
| 7 | - | - |
| 8 | (10A) | Trailer* |
| 9 | (20A) | Trailer Charge* |
| 10 | (7.5A) | Trailer Back Light* |
| 11 | (7.5A) | Trailer Hazard* |
| 12 | 10A | Rear Wiper |
| 13 | 7.5A | ECU RR |
| 14 | (40A) | Power Tailgate Motor* |
| 15 | (30A) | AC Inverter* |
| 16 | - | - |
| 17 | - | - |
| 18 | - | - |
* Not available on all models
