Honda Odyssey 2005 Fuse Box Info
Passenger compartment fuse box location:
The interior fuse boxes are located under the dashboard on the driver’s and passenger’s side.
Engine compartment fuse box location:
The primary under-hood fuse box is on the passenger’s side. The secondary under-hood fuse box is behind the primary fuse box.
Fuse Box Diagram | Layout
Passenger compartment fuse box (Driver’s Side):
| Fuse/Relay N° | Rating | Functions |
| 1 | - | Not Used |
| 2 | 15A | IG Coil |
| 3 | 10A | Daytime Running Light* |
| 4 | 15A | LAF |
| 5 | 7.5A | Radio |
| 6 | 7.5A | Interior Lights |
| 7 | 7.5A | Back Up |
| 8 | 20A | Door Lock |
| 9 | 10A | Front Accessory Socket |
| 10 | 7.5A | OPDS |
| 11 | 30A | IG, Wiper |
| 12 | - | Not Used |
| 13 | 20A | Left PSD Closer** |
| 14 | 20A | Dr Power Seat Slide** |
| 15 | 20A | ADJ Pedals** |
| 16 | 20A | Dr Power Seat Recline** |
| 17 | 20A | Power Tailgate Closer** |
| 18 | 15A | IG PCU |
| 19 | 15A | IG Fuel Pump |
| 20 | 10A | IG Washer |
| 21 | 7.5A | IG Meter |
| 22 | 10A | IG SRS |
| 23 | 7.5A | IGP |
| 24 | 20A | Left Rear Window |
| 25 | 20A | Right Rear Window |
| 26 | 20A | Passenger’s Window |
| 27 | 20A | Driver’s Window |
| 28 | 20A | Moonroof |
| 29 | - | Not Used |
| 30 | 10A | IG HAC |
| 31 | - | Not Used |
| 32 | 10A | ACC |
| 33 | 7.5A | HAC Option |
* Canadian models
** If equipped
Passenger compartment fuse box (Passenger’s Side):
| Fuse/Relay N° | Rating | Functions |
| 1 | 30A | Rear Blower |
| 2 | - | Not Used |
| 3 | 15A | DBW |
| 4 | 20A | Door Lock |
| 5 | - | Not Used |
| 6 | 15A | Heated Seat |
| 7 | 7.5A | Instrument Panel |
| 8 | 20A | Right Power Sliding Door* |
| 9 | 10A | Accessory Sockets |
* If equipped
Engine compartment fuse box (Primary):
| Fuse/Relay N° | Rating | Functions |
| 1 | 10A | Left Headlight Low |
| 2 | 30A | Rear Defroster Coil |
| 3 | 10A | Left Headlight High |
| 4 | 15A | Small Lights |
| 5 | 10A | Right Headlight Low |
| 6 | 10A | Right Headlight High |
| 7 | 7.5A | Back Up |
| 8 | 15A | FI ECU |
| 9 | 30A | Condenser Fan |
| 10 | - | Not used |
| 11 | 30A | Cooling Fan |
| 12 | 7.5A | MG Clutch |
| 13 | 20A | Horn, Stop |
| 14 | 30A | Defroster |
| 15 | 40A | Back Up |
| 16 | 15A | Hazard |
| 17 | 30A | VSA Motor |
| 18 | 30A | VSA |
| 19 | 30A | Option 1 |
| 20 | 40A | Option 2 |
| 21 | 40A | Heater Motor |
| 22 |
70A 120A |
+B AS F/B Battery |
| 23 |
50A 40A |
+B IGI Main Power Window |
Engine compartment fuse box (Secondary):
| Fuse/Relay N° | Rating | Functions |
| 1 | - | Not Used |
| 2 | 40A | Left Power Sliding Door* |
| 3 | 40A | Right Power Sliding Door* |
| 4 | 40A | Power Tailgate* |
| 5 | 20A | Premium |
| 6 | 20A | AC Inverter |
| 7 | 10A | Front Fog Light* |
| 8 | 10A | ACM |
| 9 | 7.5A | TPMS* |
| 10 | - | Not Used |
| 11 | 7.5A | Rear Entertainment System* |
* If equipped
