Honda Odyssey 2013 Fuse Box Info
Passenger compartment fuse box location:
The driver’s side interior fuse box is under the dashboard on the driver’s side. The fuse label is attached to the side panel. The passenger’s side interior fuse box is under the dashboard. Push down the tab and slide the cover upward to remove it.
Engine compartment fuse box location:
The primary under-hood fuse box is located on the passenger’s side. The secondary fuse box is located next to the battery.
Luggage compartment fuse box location:
The rear fuse box is located at the left side of cargo area.
Fuse Box Diagram | Layout
Passenger compartment fuse box (Driver’s Side):
| Fuse/Relay N° | Rating | Functions |
| 1 | 7.5A | Door Lock Motor 1 (Lock) |
| 2 | 7.5A | Door Lock Motor 2 (Lock) |
| 3 | 7.5A | Driver’s Door Lock Motor (Lock) |
| 4 | 7.5A | Door Lock Motor 1 (Unlock) |
| 5 | 7.5A | Door Lock Motor 2 (Unlock) |
| 6 | 7.5A | Driver’s Door Unlock |
| 7 | 20A | Door Lock Main |
| 8 | - | Not Used |
| 9 | 20A | Driver’s Side Power Slide Door Closer* |
| 10 | 15A | Rear Fuse Box |
| 11 | 7.5A | Meter |
| 12 | 20A | Primary Under-hood Fuse Box |
| 13 | 7.5A | Accessory |
| 14 | 7.5A | STS |
| 15 | 20A | Driver’s Power Seat Sliding |
| 16 | 20A | Moonroof* |
| 17 | 20A | Rear Left Power Window |
| 18 | - | - |
| 19 | 20A | Driver’s Power Window |
| 20 | - | - |
| 21 | 20A | Fuel Pump |
| 22 | 15A | Passenger’s Side Fuse Box |
| 23 | 7.5A | VSA |
| 24 | 7.5A | ACG AS |
| 25 | 7.5A | STRLD |
| 26 | 7.5A | HAC |
| 27 | 7.5A | DRL |
| 28 | 7.5A | ACC Key Lock |
| 29 | 7.5A | Driver’s Power Seat Lumbar Support* |
| 30 | 7.5A | TPMS |
| 31 | - | - |
| 32 | 20A | Driver’s Power Seat Reclining |
| 33 | 40A | Driver’s Side Power Slide Door Motor* |
| 34 | - | - |
* Not available on all models
Passenger compartment fuse box (Passenger’s Side):
| Fuse/Relay N° | Rating | Functions |
| 1 | 30A | Premium Amp* |
| 2 | 20A | Rear Right Power Window |
| 3 | 10A | ACM |
| 4 | - | - |
| 5 | 20A | Seat Heaters* |
| 6 | - | - |
| 7 | 20A | Front Passenger’s Power Seat Sliding* |
| 8 | 20A | Front Passenger’s Power Seat Reclining* |
| 9 | - | - |
| 10 | - | - |
| 11 | - | - |
| 12 | - | - |
| 13 | 20A | Passenger’s Side Power Slide Door Closer* |
| 14 | 15A | Rear Accessory Power Socket |
| 15 | 15A | Front Accessory Power Socket* |
| 16 | - | - |
| 17 | - | - |
| 18 | 20A | Front Passenger’s Power Window |
| 19 | 10A | SRS |
| 20 | 7.5A | ECU AS |
| 21 | 7.5A | Auto Leveling Headlight* |
| 22 | - | - |
| 23 | 7.5A | OPDS |
| 24 | - | - |
| 25 | 7.5A | Instrument Panel Illumination |
| 26 | - | - |
| 27 | 15A | Front Accessory Power Socket |
| 28 | - | - |
* Not available on all models
Engine compartment fuse box (Primary):
| Fuse/Relay N° | Rating | Functions |
| 1 | - | - |
| 2 | - | - |
| 3 | 15A | ACG FR |
| 4 | 15A | Washer |
| 5 | 7.5A | VB SOL |
| 6 | 7.5A | ECU FR |
| 7 | - | - |
| 8 | 15A | FI Sub |
| 9 | 15A | DBW |
| 10 | 15A | FI Main |
| 11 | 15A | Ignition Coil |
| 12 | - | - |
| 13 | 7.5A | FI ECU |
| 14 | - | - |
| 15 | 20A | Radio |
| 16 | 10A | Back Up |
| 17 | 7.5A | MG Clutch |
| 18 | 20A | Front Fog Lights* |
| 19 | - | - |
| 20 | 10A | Right Headlight High Beam |
| 21 | - | - |
| 22 | 10A | Small Lights |
| 23 | - | - |
| 24 | 10A | Left Headlight High Beam |
| 25 | - | - |
| 26 | 15A | Right Headlight Low Beam |
| 27 | 15A | Left Headlight Low Beam |
| 28 | 7.5A | IGPS Oil Level |
| 29 | 30A | Cooling Fan |
| 30 | 30A | Sub Fan |
| 31 | 30A | Wiper Main |
* Not available on all models
Engine compartment fuse box (Secondary):
| Fuse/Relay N° | Rating | Functions |
| 1 | 125A | Battery |
| 2-1 | 60A | Fan Main |
| 2-2 | 50A | Passenger’s Side Fuse Box 2 |
| 2-3 | 30A | Rear Blower |
| 2-4 | 30A | FI Main |
| 2-5 | 40A | VSA Motor |
| 2-6 | 30A | Stop & Horn, Hazard |
| 2-7 | 30A | VSA FSR |
| 2-8 | 30A | Battery Management System Main |
| 3-1 | 50A | Driver’s Side Fuse Box 2 |
| 3-2 | 50A | IG1 Main |
| 3-3 | 60A | Rear Fuse Box 1 |
| 3-4 | 50A | Passenger’s Side Fuse Box 1 |
| 3-5 | 50A | Driver’s Side Fuse Box 1 |
| 3-6 | 60A | Primary Under-hood Fuse Box Main |
| 3-7 | 40A | Front Blower |
| 3-8 | 40A | Passenger’s Side Power Slide Door Motor* |
| 4 | - | - |
| 5 | - | - |
| 6 | 40A | Rear Window Defogger |
| 7 | - | - |
| 8 | 7.5A | Battery Management System |
| 9 | 20A | Stop & Horn |
| 10 | 15A | Hazard |
| 11 | 7.5A | Interior Lights |
* Not available on all models
Luggage compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | 20A | Power Tailgate Closer* |
| 2 | - | Not Used |
| 3 | - | - |
| 4 | 10A | Tailgate* |
| 5 | 7.5A | Rear Left Door Lock |
| 6 | - | - |
| 7 | - | - |
| 8 | - | Not Used |
| 9 | - | Not Used |
| 10 | - | Not Used |
| 11 | - | Not Used |
| 12 | 10A | Rear Wiper |
| 13 | 7.5A | ECU RR |
| 14 | 40A | Power Tailgate Motor* |
| 15 | 30A | AC Inverter* |
| 16 | - | - |
| 17 | - | - |
| 18 | - | - |
* Not available on all models
