Ford Mustang 1996 Fuse Box Info
Passenger compartment fuse box location:
The fuse box is located below and to the left of the steering wheel by the brake pedal.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | 15A | Turn signal lamps, Backup lamps, Airbag module, DRL module, Overdrive cancel, Brake shift solenoid, Heated backlite relay coil, Conv. top relay coil, Illum. entry module (shut-off) |
| 2 | 30A | Windshield wiper and washer system |
| 4 | 10A | Airbag module (aux. pwr.) |
| 5 | 15A | Headlamp switch, Exterior lamps, Cluster illum. |
| 6 | 15A | Clock (illum.), Speed control amp., Air conditioning clutch coil, RKE module (shut-off) |
| 7 | 10A | ABS |
| 8 | 10A | Chime for keys in ignition, Courtesy lamps, Engine compartment lamp, Glove compartment lamp, Power mirrors, Radio (MCM), Instrument cluster (MCM), Clock, Trunk lamp, Anti-theft (door open sig) |
| 9 | 15A | Hazard warning, Stoplamps, Brake shift interlock sol. |
| 10 | 15A | IMCR (Cobra only) |
| 11 | 15A | Radio |
| 12 | 20A | Deck lid release, Door locks |
| 13 | 10A | Instrument panel, Illumination lamps, PRNDL illum., Ashtray illum. |
| 14 | 20A | Power windows |
| 15 | 10A | Low oil module, Low coolant module, Safety belt chime, Cluster warning lamps, Cluster gauges |
| 16 | 20A | Flass-to-pass, Fog lamps, Anti-theft module, Low beams, Ext. lamps |
| 17 | 30A | Air conditioning and heater blower motor |
| 18 | 20A | Generator warning lights, EEC pwr. relay coil |
Engine compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| IGN SW | 40A | Turn signal lamps, Backup lamps, Air bag module, DRL module, Overdrive cancel, Brake shift solenoid, Heated backlight relay coil, Convertible top relay coil, Illuminated entry module (shut-off), HEGO (4.6L only), ABS, Low oil module, Low coolant module, Safety belt chime, Cluster warning lamps, Claster gauges, Transmission shift module (4.6L only), Generator warning lights, EEC power relay coil, Ignition coil, TFI module (4.6L only), Starter relay |
| IGN SW | 40A | Windshield washer and wiper systems, Clock (illumination), Speed control amp., Air conditioning clutch coil, RKE module (shut-off), Anti-theft module (shut-off), Radio, Power windows |
| Htd Baclite | 40A | Rear windows defrost |
| Fuel Pump | 20A | Electric fuel pump |
| IGN SW | 40A | Air conditioning and heater blower motor |
| Fan | 60A | Elec. drive fan |
| Hd. Lps. | 50A | Headlamps, Air bag module (aux. pwr.), Chime for key in ignition, Courtesy lamps, Engine compartment lamp, Glove compartment lamp, Power mirrors, Radio (MCM), Instrument cluster (MCM), Clock, Trunk lamp, Anti-theft (door open sig.), Flash-to-pass, Low beams, Ext. lamps, Deck lid release, Door locks |
| EEC | 20A | EEC power |
| ABS | 60A | Anti-lock brakes |
| Power Seats | 25A | Power seats |
| DRL | 20A | Daytime runing lights |
| Int. Lamps | 25A | Interior lamps |
| AUDIO | 25A | Radio amplifier, Subwoofer amplifier |
| ALT | 20A | Generator regulator |
| Cigar Lighter | 30A | Cigar lighter, Power point |
| Convertible Top | 30A | Convertible top |
| Thermactor | 30A | Thermactor (Cobra models) |
