Ford Explorer 2008 Fuse Box

Ford Explorer 2008 Fuse Box Info


Passenger compartment fuse box location:

The fuse box is located below the instrument panel on the driver’s side.


Engine compartment fuse box location:

The power distribution box is located in the engine compartment.



Fuse Box Diagram | Layout


Passenger compartment fuse box::

Fuse/Relay N° Rating Functions
1 20A Moonroof, Adjustable pedals, Memory seats, Memory lumbar
2 5A Microcontroller power (SJB)
3 20A Radio
4 10A OBD II connector
5 5A Moonroof, Door lock switch illumination, Rearview mirror with
6 20A Liftglass release motor, Door unlock/lock
7 15A Trailer stop/turn
8 15A Ignition switch power, PATS, Cluster
9 2A 6R TCM/PCM (Ignition RUN/START), Fuel pump relay
10 5A Front wiper RUN/ACC relay in PDB
11 5A Radio start
12 5A Rear wiper motor RUN/ACC, Trailer battery charge relay in PDB, Radio
13 15A Heated mirror, Manual climate rear defrost indicator
14 20A Horn
15 10A Reverse lamps
16 10A Trailer reverse lamps
17 10A RCM (restraints), Passenger occupancy
18 10A Reverse park aid, IVD switch, IVD, 4x4 module, 4x4 switch, Heated seat switches, Compass, Electrochromatic mirror, AUX climate control
19 - Not used
20 10A Manual climate, DEATC, Brake shift
21 - Not used
22 15A Brake switch, Bi-color stop lamps, CHMSL, All turn lamps
23 15A Interior lamps, Puddle lamps, Battery saver, Instrument
illumination, Homelink
24 2A Cluster, Theft LED
25 15A Trailer tow park lamps
26 15A License plate/rear park lamp, Front park lamps, Manual climate
27 15A Tri-color stop lamps
28 10A Manual/DEATC
CB1 25A Windows
    The following relays are located on either side of the passenger
compartment fuse panel
Relay 1 - Delayed ACC


Engine compartment fuse box:

Fuse/Relay N° Rating Functions
1 50A BATT 2 (SJB)
2 50A BATT 3 (SJB)
3 50A BATT 1 (SJB)
4 30A Fuel pump, Injectors
5 30A Third row seat (left)
6 40A ABS pump
7 40A Powertrain Control Module (PCM)
8 40A Heated windshield (left)
9 40A Heated windshield (right)
10 30A Power seat (right)
11 30A Starter
12 30A Third row seat (right)
13 30A Trailer tow battery charger



Memory seats (DSM)

Non-memory seats

15 40A Rear defrost, Heated mirrors
16 40A Front blower motor
17 30A Trailer electronic brakes
18 30A Auxiliary blower motor
19 30A Running boards
20 30A Front wiper motor
21 20A Rear power point
22 20A Subwoofer
23 20A 4x4
24 10A Powertrain Control Module (PCM) Keep Alive Power, Canister vent
25 20A Front power point/Cigar lighter
26 20A 4x4 module
27 20A 6R Transmission module (4.6L engine only)
28 20A Heated seats
29 20A Headlamps (right)
30 25A Rear wiper
31 15A Fog lamps
32 5A Power mirrors
33 30A ABS valve
34 20A Headlamps (left)
35 10A AC clutch
36 20A Console bin power point
37 30A Driver window motor
38 15A 5R Transmission (4.0L engine only)
39 15A PCM power
40 15A Fan clutch, PCV valve (4.0L engine only), AC clutch relay, GCC fan
42 15A Redundant brake switch, EVMV, MAFS, HEGO, EVR, VCT1 (4.6L
engine only), VCT2 (4.6L engine only), CMCV (4.6L engine only),
43 15A Coil on plug (4.6L engine only), Coil tower (4.0L engine only)
44 15A Injectors
45A - Not used
45B - GCC fan relay
46A - Not used
46B - Not used
49 - Fuel pump relay
50A - Fog lamps relay
50B - AC clutch relay
51 - Not used
52 - A/C clutch (diode)
53 - One Touch Integrated Start (OTIS) (diode)
54 - Trailer battery charger relay
55A - PCM relay
55B - Front wiper relay
56A - Blower relay
56B - Starter relay
