Ford Edge 2015 Fuse Box Info
Fuse box location:
The fuse panel is located under the instrument panel to the left of the steering column.
Engine compartment fuse box:
The power distribution box is located in the engine compartment.
Fuse Box Diagram | Layout
Passenger compartment fuse box:
Fuse/Relay N° | Rating | Functions |
1 | 10A* | Demand lighting (glove box, vanity, dome), Battery saver relay coil, Second row easy fold relay coil |
2 | 7.5A* | Memory seats, Lumbar, Power mirrors, Driver seat module logic power |
3 | 20A* | Driver door unlock |
4 | 5A* | Not used (spare) |
5 | 20A* | Not used (spare) |
6 | 10A** | Not used (spare) |
7 | 10A** | Not used (spare) |
8 | 10A** | Not used (spare) |
9 | 10A** | Not used (spare) |
10 | 5A** | Keypad, Power liftgate module logic power, Hands free liftgate module |
11 | 5A** | Not used (spare) |
12 | 7.5A** | Climate control module |
13 | 7.5A** | Cluster, Steering column control module, Smart datalink connector (gateway) module |
14 | 10A** | Not used (spare) |
15 | 10A** | Datalink power |
16 | 15A* | Not used (spare) |
17 | 5A** | Not used (spare) |
18 | 5A** | Ignition switch, Push button start switch, Key inhibit solenoid |
19 | 7.5A** | Not used (spare) |
20 | 7.5A** | Active front steering logic power |
21 | 5A** | Humidity and in–car temperature sensor |
22 | 5A** | Occupant classification sensor |
23 | 10A* | Delayed accessory (power inverter logic, moonroof logic, driver window switch power) |
24 | 20A* | Central lock unlock |
25 | 30A* | Driver door (window, mirror), Driver door module, Driver door lock indicator, Driver lock switch illumination |
26 | 30A* | Front passenger door (window, mirror), Front passenger door module, Front passenger lock indicator, Front passenger switch illumination (window, lock) |
27 | 30A* | Moonroof |
28 | 20A* | Amplifier |
29 | 30A* | Not used (spare) |
30 | 30A* | Not used (spare) |
31 | 15A* | Not used (spare) |
32 | 10A* | Global positioning system, Centerstack display, Voice control (SYNC), Radio transceiver module |
33 | 20A* | Radio |
34 | 30A* | Run-start bus (fuse 19, 20, 21, 22, 35, 36, 37, circuit breaker 38) |
35 | 5A* | Restraints control module |
36 | 15A* | Auto-dimming rear view mirror, Heated seat, Auto high beam/lane departure mirror module, Rear heated seat module logic power |
37 | 15A* | Heated steering wheel module (without active front steering) |
38 | 30A*** | Rear power windows, Rear window switch illumination |
* Micro fuse ** Dual micro fuse *** Circuit breaker |
Engine compartment fuse box:
Fuse/Relay N° | Rating | Functions |
1 | 30A*** | Not used (spare) |
2 | - | Starter relay |
3 | 15A* | Rear wiper, Rain sensor |
4 | - | Blower motor relay |
5 | 20A*** | Power point 3 - back of console |
6 | - | Not used |
7 | 20A* | Powertrain control module - vehicle power 1 |
8 | 20A* | Powertrain control module - vehicle power 2 |
9 | - | Powertrain control module relay |
10 | 20A*** | Power point 1 - driver front |
11 | 15A** | Powertrain control module - vehicle power 4 |
12 | 15A** | Powertrain control module - vehicle power 3 |
13 | - | Not used |
14 | - | Not used |
15 | - | Run-start relay |
16 | 20A*** | Power point 2 - console bin |
17 | 20A*** | Power point 4 - luggage compartment |
18 | 20A* | RH HID headlamp |
19 | 10A* | Run-start electronic power assist steering |
20 | 10A* | Run/start lighting |
21 | 15A* | Transmission oil pump logic power (start/ stop) |
22 | 10A* | Air conditioner clutch solenoid |
23 | 15A* | Run-start 6, Blind spot information system, Rear view camera, Adaptive cruise control, Heads-up display, Voltage quality module (start/stop), Front split view camera, Front split view camera module |
24 | 10A* | Not used (spare) |
25 | 10A** | Run-start anti-lock brake system |
26 | 10A** | Run-start powertrain control module |
27 | - | Not used |
28 | 10A* | Rear washer pump |
29 | - | Not used |
30 | - | Not used |
31 | - | Not used |
32 | - | Electronic fan 1 relay |
33 | - | A/C clutch relay |
34 | 15A* | Not used (spare) |
35 | - | Not used |
36 | - | Not used |
37 | 10A* | Power transfer unit fan |
38 | - | Electronic fan 2 relay |
39 | - | Electric fan 3 relay |
40 | - | Horn relay |
41 | - | Not used |
42 | - | Fuel pump relay |
43 | 10A* | 2nd row easy fold seat release |
44 | 20A* | LH HID headlamp |
45 | - | Not used |
46 | - | Not used |
47 | - | Not used |
48 | - | Not used |
49 | - | Not used |
50 | 20A* | Horn |
51 | - | Not used |
52 | - | Not used |
53 | - | Not used |
54 | 10A** | Brake on off switch |
55 | 10A** | ALT sensor |
* Micro fuse ** Dual micro fuse *** M-type fuse. |
Engine compartment fuse box - bottom:
There are fuses located on the bottom of the fuse box. To access the bottom of the fuse box, do the following:
1. Release the two latches, located on both sides of the fuse box.
2. Raise the inboard side of the fuse box from the cradle.
3. Move the fuse box toward the center of the engine compartment.
4. Pivot the outboard side of the fuse box to access the bottom side.
Fuse/Relay N° | Rating | Functions |
56 | - | Not used |
57 | - | Not used |
58 | 30A* | Fuel pump feed |
59 | 40A** | Electronic fan 3 |
60 | 40A** | Electronic fan 1 |
61 | - | Not used |
62 | 50A** | Body control module 1 |
63 | 25A* | Electronic fan 2 |
64 | - | Not used |
65 | 20A* | Front heated seat |
66 | - | Not used |
67 | 50A** | Body control module 2 |
68 | 40A* | Heated rear window |
69 | 30A* | Anti-lock brake system valves |
70 | 30A* | Passenger seat |
71 | - | Not used |
72 | 20A* | Transmission oil pump (start/stop) |
73 | 20A* | Rear heated seats |
74 | 30A* | Driver seat module |
75 | 25A* | Wiper motor 1 |
76 | 30A* | Power lift-gate module |
77 | 30A* | Climate control seat module |
78 | 40A* | Trailer lighting module |
79 | 40A* | Blower motor |
80 | 25A* | Wiper motor 2 |
81 | 40A* | 110 volt inverter |
82 | - | Not used |
83 | 20A* | Not used (spare) |
84 | 30A* | Starter solenoid |
85 | - | Not used |
86 | - | Not used |
87 | 60A** | Anti-lock brake system pump |
* M-type fuse ** J-type fuse. |
