Fiat Doblò 2015 Fuse Box

Fiat Doblò 2015 Fuse Box Info



Passenger compartment fuse box location:

The two fuse boxes are located at the left side of the steering column at the bottom of the instrument panel, behind the cover.



Engine compartment fuse box location:





Fuse Box Diagram | Layout



Passenger compartment fuse box:

Fuse/Relay N° Rating Functions
38 20A Door locking/unlocking motors, dead lock actuator motors, tailgate unlocking motor
36 10A Supply + battery for EOBD diagnosis socket, radio, tyre pressure monitoring control unit
43 15A Windscreen/rear window washer pump
48 20A Electric window motor on passenger-side front door
13 7.5A Left low beam, headlight corrector
47 20A Electric window motor on driver-side front door
1 10A Heated driver seat
2 10A Heated passenger seat
3 15A Cigar lighter
4 20A Third power socket on dashboard
5 20A Driver's side rear electric window
6 20A Passenger's side rear electric window



Engine compartment fuse box:

Fuse/Relay N° Rating Functions
09 10A Remote control switch for opening swing door (Cargo version)
10 10A Single tone horn
14 15A Main beam headlights
20 30A Heated rear window
30 15A Fog lights
85 15A Rear power socket
86 15A Passenger compartment power socket
