Ferrari California 2012 Fuse Box

Ferrari California 2012 Fuse Box Info



Passenger compartment fuse box location:

The fuse box 1 is located at the left side of the steering column at the bottom of the instrument panel, behind the cover. The fuse box 2 is located on the right side below the foot board.

The fuse box 3 is located under flap on the centre console.



Engine compartment fuse box location:



Fuse Box Diagram | Layout



Passenger compartment fuse box 1:

Fuse/Relay N° Rating Functions
F12 15A Right high beam
F13 15A Left high beam
F31 7.5A AC unit, body computer connector
F32 10A Dome lights, foot well and puddle lights, side markers, supplementary taillights
F35 7.5A Clutch pedal control, Cruise control, Power steering, Beams
F36 10A Satellite alarm system, parking sensors, fuel filler flap
F37 10A Stop light control
F38 15A Luggage compartment lock
F39 15A Radio, diagnosis socket, CAN box interface
F40 30A Heated rear window
F42 7.5A Alternator
F43 30A Windscreen wipers
F44 20A Passenger seat heating, cigarette lighter
F46 20A Hard top
F47 30A Driver-side door
F48 30A Passenger-side door
F49 75A Passenger compartment lighting switches and controls
F50 7.5A Air bags
F51 7.5A Semi-automatic gearbox, engine start button
F52 15A Power socket, driver seat heating
F53 10A Instrument panel
T01 20A Low beam relay
T11 30A Heated rear screen relay
T12 30A Relay services 1
T13 joint Supply jumper services 2



Passenger compartment fuse box 2:

Fuse/Relay N° Rating Functions
F01 60A +30 Radiator fans (first speed)
F02 30A +30 ABS (valves)
F03 30A +30 Ignition switch
F04 50A +30 ABS (pump)
F05 40A +30 Air conditioning and heating system
F06 50A +30 Radiator fans (second speed)
F07 20A +30 Horns
F08 7.5A Air conditioning and heating system compressor
F09 7.5A +30 Supplementary stop lights
F10 15A +30 luggage compartment lock relay
F11 25A Left bank oxygen sensor
F14 15A +30 high beams
F15 7.5A +30 alternator sensing
F16 25A +30 Right bank engine control power supply
F17 25A +30 Left bank engine control power supply
F18 10A +30 Left cylinder bank injection system power supply, LH cylinder bank injection main relay coil
F19 10A +30 Right cylinder bank injection system power supply, RH cylinder bank injection main relay coil
F20 30A +30 right injection system main relay
F21 15A +30 Fuel pump 2
F22 15A Left bank (ignition coil)
F23 10A +30 ABS (electronic)
F24 15A Right bank (ignition coil)
F30 30A +30 Starting relay
F81 40A +30 Supplementary ECU power supply
F82 70A +30 Dashboard ECU and luggage compartment ECU power supply
F83 50A +30 Air pump relay
F84 15A +30 Fuel pump relay 1
F85 25A Headlight washer
F87 25A Right bank oxygen sensors
F88 10A +15 Left cylinder bank injection system
F93 30A +30 suspension control node fuse
T02 30A High beam relay
T05 30A Fuel pump relay 2
T06 30A Luggage compartment lock actuator relay
T07 50A Horn relay
T08 30A Air conditioning and heating system compressor relay
T09 30A Left cylinder bank injection system main relay
T10 30A Right cylinder bank injection system main relay
T14 30A Fuel pump relay 1
T15 50A Radiator fan relay (second speed)
T16 50A Radiator fan relay (first speed)
T17 10/20A INT/A relay (devices excluded at ignition)
T19 30A Stop light control relay
T20 30A Starting relay
T26 30A Windscreen wiper relay (first speed)
T27 30A Windscreen wiper relay (second speed)
T28 30A Windscreen washer pump relay
T29 30A Supplementary stop light relay (third stop light)
T30 50A Air pump relay
T31 30A Headlight washer pump relay
T37 30A Left supplementary taillight relay
T38 30A Left headlight LED module power supply relay
T39 30A Right headlight LED module power supply relay



Passenger compartment fuse box 3:

Fuse/Relay N° Rating Functions
F54 2.0A +30 HI-FI amplifier
F56 30A +30 Driving position
F57 7.5A Side Markers 1 (LH front and RH rear)
F59 7.5A Reverse lights
F60 30A +30 Passenger position
F61 7.5A +30 Driving position (electronic)
F62 7.5A +30 Passenger position (electronic)
F63 15A +30 Semi-automatic gearbox main relay
F64 7.5A Fuel filler flap actuator
F65 20A Door lock actuator
F66 7.5A +30 Semi-automatic gearbox
F67 7.5A Side Markers 2 (RH front and LH rear)
F78 15A +30 Battery charger
F80 30A +30 BassBox amplifier
T21 50A Side Marker relay
T22 30A Reverse light relay
T23 30A Fuel filler flap relay
T24 30A Supplementary taillight relay
T25 30A Semi-automatic gearbox main relay



Engine compartment fuse box:

Fuse/Relay N° Rating Functions
CAL2 CAL2 Power supply (starter motor and alternator)
F70 150A Power supply and engine relay
F71 40A Hard top pump
F72 40A Parking brake power
F73 70A Dashboard ECU power
