Ram ProMaster 2014 Fuse Box Info
Fuse box location:
The fuse box is located on the driver's side under the instrument panel.
Engine compartment fuse box:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 12 | 10A | Right Low Beam |
| 13 | 10A | Left Low Beam |
| 31 | 5A | INT/A |
| 32 | 10A | SBMT |
| 34 | 7.5A | Clearance Lights |
| 36 | 15A | +30 (ACM – TPCU – RRM – DLC) |
| 37 | 5A | INT (BRAKE NO – IPC) |
| 38 | 15A | Central Locking |
| 42 | 5A | INT (BSM – SAS – BRAKE NC) |
| 43 | 20A | Bi-Directional Washer Pump |
| 47 | 20A | Driver Power Window |
| 48 | 20A | Passenger Power Window |
| 49 | 5A | INT (PAM – CCS – RRM – ECM) |
| 50 | 7.5A | INT (ORC) |
| 51 | 5A | INT (REAR CAMERA-AUX) |
| 53 | 5A | +30 (IPC) |
| 90 | 7.5A | Left High Beam |
| 91 | 7.5A | Right High Beam |
| 92 | 7.5A | Left Fog Lamp |
| 93 | 7.5A | Right Fog Lamp |
Right Central Pillar Fuses:
The right central pillar fuse panel is located on the interior side at the base of the passenger side B pillar.
| Fuse/Relay N° | Rating | Functions |
| 81 | 7.5A | Seat Heater |
| 83 | 20A | Rear Left Windows Heater |
| 84 | 20A | Rear Right Windows Heater |
| 85 | 10A | Rear Heater Prep |
Engine compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 01 | 40A | ESC Pump |
| 02 |
20A (3.6 Gasoline Engine) 50A (3.0 Diesel Engine) |
Starter Relay 3.6L (3.6 Gasoline Engine) Glow Plug Unit (3.0 Diesel Engine) |
| 04 |
50A (3.6 Gasoline Engine) 40A (3.0 Diesel Engine) |
Secondary PDC (Trans Power Relay, Vacuum Pump, KL30 for STM) (3.6 Gasoline Engine) Fuel Filter Heater (3.0 Diesel Engine) |
| 05 | 30A | SELESPEED Pump RELE (3.0 Diesel Engine) - If Equipped |
| 06 |
40A (non A/C) 60A (A/C) |
Engine Cooling Fan - 2nd Speed |
| 07 |
50A (non A/C) 60A (A/C) |
Engine Cooling Fan - 1st Speed |
| 08 | 40A | Passenger Compartment Blower |
| 09 | 15A | Rear Power Outlet |
| 10 | 15A | Horn |
| 11 | 15A | MPROP-DRV (3.0 Diesel Engine) — If Equipped |
| 14 | 20A | Power Outlet |
| 15 | 7.5A | USB Charger |
| 16 |
7.5A 7.5A |
KL15 STM (3.6), KL15 Starter Relay Coil (3.6 Gasoline Engine) KL15 MTA, KL15 Shift Lever Unit, KL15 ECM, KL15 Starter Relay Coil (3.0 Diesel Engine) |
| 17 |
20A 20A |
ECM, Injectors (3.6 Gasoline Engine) Secondary Loads, ECM (3.0 Diesel Engine) |
| 18 |
7.5A 7.5A |
KL30 ECM, KL30 Main Relay Coil (3.6 Gasoline Engine) KL30 MTA, KL30 ECM, KL30 Main Relay Coil (3.0 Diesel Engine) |
| 19 | 7.5A | A/C Compressor (If Equipped) |
| 20 | 30A | Windshield Wiper |
| 21 | 15A | Fuel Pump |
| 22 |
20A 20A |
ECM, Ignition Coils (3.6 Gasoline Engine) ECM, Primary Loads (3.0 Diesel Engine) |
| 23 | 20A | ESC Valves |
| 24 | 7.5A | KL15 Vacuum pump relay coil (3.6 Gasoline Engine) — If Equipped |
| 30 | 15A | Heated Mirrors |
Front PDC Additional Fuses:
The additional fuse box is located inside the front PDC Box.
| Fuse/Relay N° | Rating | Functions |
| 61 | 20A | Vacuum Pump (3.6 Gasoline Engine) — If Equipped |
| 62 | 30A | Transmission Power RELE (3.6 Gasoline Engine) — If Equippe |
| 64 | 7.5A | Urea Pump (3.0 Diesel Engine) — If Equipped |
| 65 | 25A | Urea NOX Sensor 1–2 — PM Sensor (3.0 Diesel Engine) — If Equipped |
| 66 | 5A | STM (3.6 Gasoline Engine) — If Equippe |
