Dodge Charger 2021 Fuse Box Info
Luggage compartment fuse box location:
The luggage fuse box is located in the rear compartment under the spare tire access panel.
Engine compartment fuse box:
Fuse Box Diagram | Layout
Luggage compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 2 | 60A | Front PDC Feed #1 |
| 3 | - | Spare |
| 4 | 60A | Front PDC Feed #2 |
| 5 |
30A 20A – Police |
Sunroof / Dome Lamp – Police |
| 6 | 40A | Exterior Lighting #1 |
| 7 | 40A | Exterior Lighting #2 |
| 8 | 30A | Interior Lighting |
| 9 | 40A | Power Locks |
| 10 | 30A | Driver Door Control Module |
| 11 | 30A | Passenger Door Control Module |
| 12 | 20A | Cigar Lighter/IP APO/RR USB (Selectable Fuse)– If Equipped |
| 15 | 40A | HVAC Blower |
| 16 | 20A | Left Spot Lamp – Police |
| 17 | 20A | Right Spot Lamp – Police |
| 18 | 30A | VISM Mod (Police) |
| 19 | - | Spare |
| 20 | - | Spare |
| 21 | 30A | Fuel Pump (Non 6.2L ADR) |
| 22 | 5A | Cyber Gateway Mod |
| 23 | 10A | Fuel Door – If Equipped/Diagnostic Port |
| 24 | 10A | Integrated Center Stack |
| 25 | 10A | Tire Pressure Monitor |
| 26 | 15A | Trans Mod (Charger Non- Police/ 300) |
| 27 | 25A | Amplifier – If Equipped |
| 31 | 25A | Power Seats – If Equipped |
| 32 | 15A | HVAC Module/ Cluster |
| 33 | 15A | Ignition Switch/Wireless Mod/ Steer Column Lock Mod/Remote Start – If Equipped |
| 34 | 10A | Steering Column Module/Clock (300) |
| 35 | 5A | Battery Sensor |
| 36 | 15A | Electronic Exhaust Valve – If Equipped |
| 37 | 20A | Radio |
| 38 | 20A | Media Hub/ Console APO |
| 42 | 30A | Rear Defrost |
| 43 | 20A | RR Heated Seat – If Equipped/ Heated Steering Wheel – If Equipped |
| 44 | 10A | Park Assist / Blind Spot / Rear View Camera – If Equipped |
| 45 | 15A | Cluster / Rearview Mirror / Lane Departure |
| 46 | - | Spare |
| 47 | 10A | Adaptive Front Lighting / Day Time Running Lamps – If Equipped |
| 49 | - | Spare |
| 50 | - | Spare |
| 51 | 20A | Front Heated / Vented Seats – If Equipped |
| 52 | 10A | Heated Cupholders/Rear Heated Seat Switches – If Equipped |
| 53 | 10A | HVAC Module/In Vehicle Temperature Sensor |
| 54 | - | Spare |
| 55 | - | Spare |
| 56 | - | Spare |
| 57 | - | Spare |
| 58 | 10A | Airbag Module |
| 59 | 20A | Adjustable Pedals – Police |
| 60 | - | Spare |
| 61 | - | Spare |
| 62 | - | Spare |
| 63 | - | Spare |
| 64 | 25A | Rear Windows (Charger/300) (Circuit Breaker) |
| 65 | 10A | Airbag Module |
| 66 | - | Spare |
| 67 | 10A | Rain and Light Sensor / Sunroof / Inside RR View Mirror / Police Run Acc Relay |
| 68 | 10A | RR USB Timer/ RR Sunshade – If Equipped |
| 69 | - | Spare |
| 70 | - | Spare |
Engine compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | - | Spare |
| 2 | 40A | Radiator Fan #1 – (Non 6.2L Supercharged) |
| 3 | 50A | Electric Power Steering #1 – If Equipped |
| 4 | 30A | Starter |
| 5 | 40A | Anti Lock Brake |
| 6 | 30A | Anti Lock Brake |
| 7 | 20A | Police Ignition Run / ACC #1 |
| 9 | 20A | All-Wheel Drive Module – If Equipped |
| 10 | 10A | Intrusion MOD (300) – If Equipped / Under Hood Lamp – Police |
| 11 | 20A | Horns |
| 12 | 10A | Air Conditioning Clutch |
| 13 | - | Spare |
| 14 | - | Spare |
| 15 | 20A | Left HID – If Equipped |
| 16 | 20A | Right HID – If Equipped |
| 18 | 50A | Radiator Fan #2 (Non 6.2L Eng) |
| 19 | 50A | Electric Power Steering #2 – If Equipped |
| 20 | 30A | Wiper Motor |
| 21 |
30A 20A – Police |
Headlamp Washers – If Equipped Police Bat Feed #2 |
| 23 | 20A | Police Bat Feed # 1 |
| 28 | - | Spare |
| 29 | 15A | Auto Trans (Challenger / Charger Police) |
| 30 | - | Spare |
| 31 | 25A | Engine Module |
| 32 | - | Spare |
| 33 | - | Spare |
| 34 | 25A | ASD Feed #1 |
| 35 | 20A | ASD Feed #2 |
| 36 | 10A | Anti-Lock Brake Module / Steering Column Lock Module (300 if equipped) |
| 37 | 10A | Engine Controller |
| 38 | 10A | Airbag Module |
| 39 | 10A | AC Clutch/EPS – If Equipped/ Vacuum Pump – If Equipped |
| 48 | AWD Module/Front Axle Disconnect – If Equipped | |
| 49 | - | Spare |
| 50 | - | Spare |
| 51 | 20A | Vacuum Pump – If Equipped |
| 52 | 5A | Adaptive Cruise – If Equipped |
| 53 | - | Spare |
