Ram ProMaster 2017 Fuse Box Info
Fuse box location:
The fuse box is located on the driver's side under the instrument panel.
Engine compartment fuse box:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 12 | 10A | Right Low Beam |
| 13 | 10A | Left Low Beam |
| 31 | 5A | INT/A |
| 32 | 10A | SBMT |
| 34 | 7.5A | Clearance Lights |
| 36 | 15A | +30 (ACM – TPCU – RRM – DLC) |
| 37 | 5A | INT (BRAKE NO – IPC) |
| 38 | 15A | Central Locking |
| 42 | 5A | INT (BSM – SAS – BRAKE NC) |
| 43 | 20A | Bi-Directional Washer Pump |
| 47 | 20A | Driver Power Window |
| 48 | 20A | Passenger Power Window |
| 49 | 5A | INT (PAM – CCS – RRM – ECM) |
| 50 | 7.5A | INT (ORC) |
| 51 | 5A | INT (REAR CAMERA-AUX) |
| 53 | 5A | +30 (IPC) |
| 90 | 7.5A | Left High Beam |
| 91 | 7.5A | Right High Beam |
| 92 | 7.5A | Left Fog Lamp |
| 93 | 7.5A | Right Fog Lamp |
Right Central Pillar Fuses:
The right central pillar fuse panel is located on the interior side at the base of the passenger side B pillar.
| Fuse/Relay N° | Rating | Functions |
| 81 | 7.5A | Seat Heater |
| 83 | 20A | Rear Left Windows Heater |
| 84 | 20A | Rear Right Windows Heater |
| 86 | 20A | Auxiliary Switch (From Battery) – If Equipped |
| 87 | 20A | Auxiliary Switch (From Ignition) – If Equipped |
Engine compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 01 | 40A | Electronic Stability Control (ESC) Pump |
| 02 |
20A (3.6 Gasoline Engine) 50A (3.0 Diesel Engine) |
Starter Relay 3.6L (3.6 Gasoline Engine) Glow Plug Unit (3.0 Diesel Engine) |
| 04 |
50A (3.6 Gasoline Engine) 40A (3.0 Diesel Engine) |
Secondary Power Distribution Center (PDC) (Trans Power Relay, Vacuum Pump, KL30 for the Shifter Transmission Module [STM]) (3.6 Gasoline Engine) Fuel Filter Heater (3.0 Diesel Engine) |
| 05 | 30A | SELESPEED Pump RELE (3.0 Diesel Engine) - If Equipped |
| 06 |
40A (non A/C) 60A (A/C) |
Engine Cooling Fan - 2nd Speed |
| 07 |
50A (non A/C) 60A (A/C) |
Engine Cooling Fan - 1st Speed |
| 08 | 40A | Passenger Compartment Blower |
| 09 | 15A | Rear Power Outlet |
| 10 | 15A | Horn |
| 11 | 15A | Fuel Pressure Regulator (MPROP)-DRV (3.0 Diesel Engine) — If Equipped |
| 14 | 20A | Power Outlet |
| 15 | 7.5A | USB Charger |
| 16 |
7.5A 7.5A |
KL15 Shifter Transmission Module (STM) (3.6), KL15 Starter Relay Coil (3.6 Gasoline Engine) KL15 Manual Transmission Automated (MTA), KL15 Gear Selector Unit, KL15 Engine Control Module (ECM), KL15 Starter Relay Coil (3.0 Diesel Engine) |
| 17 |
20A 20A |
Engine Control Module (ECM), Injectors (3.6 Gasoline Engine) Secondary Loads, Engine Control Module (ECM) (3.0 Diesel Engine) |
| 18 |
7.5A 7.5A |
KL30 Engine Control Module (ECM), KL30 Main Relay Coil (3.6 Gasoline Engine) KL30 Manual Transmission Automated (MTA), KL30 Engine Control Module (ECM), KL30 Main Relay Coil (3.0 Diesel Engine) |
| 19 | 7.5A | A/C Compressor (If Equipped) |
| 20 | 30A | Windshield Wiper |
| 21 | 15A | Fuel Pump |
| 22 |
20A 20A |
Engine Control Module (ECM), Ignition Coils (3.6 Gasoline Engine) Engine Control Module (ECM), Primary Loads (3.0 Diesel Engine) |
| 23 | 20A | Electronic Stability Control (ESC) Valves |
| 24 | 7.5A | KL15 Vacuum pump relay coil (3.6 Gasoline Engine) — If Equipped |
| 30 | 15A | Heated Mirrors |
Front PDC Additional Fuses:
The additional fuse box is located inside the front PDC Box.
| Fuse/Relay N° | Rating | Functions |
| 61 | 20A | Vacuum Pump (3.6 Gasoline Engine) — If Equipped |
| 62 | 30A | Transmission Power RELE (3.6 Gasoline Engine) — If Equippe |
| 64 | 7.5A | Urea Pump (3.0 Diesel Engine) — If Equipped |
| 65 | 25A | Urea NOX Sensor 1–2 — PM Sensor (3.0 Diesel Engine) — If Equipped |
| 66 | 5A | Shifter Transmission Module (STM) (3.6 Gasoline Engine) — If Equipped |
