Ram ProMaster 2016 Fuse Box

Ram ProMaster 2016 Fuse Box Info



Fuse box location:

The fuse box is located on the driver's side under the instrument panel.



Engine compartment fuse box:





Fuse Box Diagram | Layout



Passenger compartment fuse box:

Fuse/Relay N° Rating Functions
12 10A Right Low Beam
13 10A Left Low Beam
31 5A INT/A
32 10A SBMT
34 7.5A Clearance Lights
36 15A +30 (ACM – TPCU – RRM – DLC)
37 5A INT (BRAKE NO – IPC)
38 15A Central Locking
42 5A INT (BSM – SAS – BRAKE NC)
43 20A Bi-Directional Washer Pump
47 20A Driver Power Window
48 20A Passenger Power Window
49 5A INT (PAM – CCS – RRM – ECM)
50 7.5A INT (ORC)
51 5A INT (REAR CAMERA-AUX)
53 5A +30 (IPC)
90 7.5A Left High Beam
91 7.5A Right High Beam
92 7.5A Left Fog Lamp
93 7.5A Right Fog Lamp





Right Central Pillar Fuses:

The right central pillar fuse panel is located on the interior side at the base of the passenger side B pillar.

Fuse/Relay N° Rating Functions
81 7.5A Seat Heater
83 20A Rear Left Windows Heater
84 20A Rear Right Windows Heater
86 20A Auxiliary Switch (From Battery) – If Equipped
87 20A Auxiliary Switch (From Ignition) – If Equipped





Engine compartment fuse box:

Fuse/Relay N° Rating Functions
01 40A Electronic Stability Control (ESC) Pump
02

20A (3.6 Gasoline Engine)

50A (3.0 Diesel Engine)

Starter Relay 3.6L (3.6 Gasoline Engine)

Glow Plug Unit (3.0 Diesel Engine)

04

50A  (3.6 Gasoline Engine)

40A (3.0 Diesel Engine)

Secondary Power Distribution Center (PDC) (Trans Power Relay, Vacuum Pump, KL30 for the Shifter Transmission Module [STM]) (3.6 Gasoline Engine)

Fuel Filter Heater (3.0 Diesel Engine)

05 30A SELESPEED Pump RELE (3.0 Diesel Engine) - If Equipped
06

40A (non A/C)

60A (A/C)

Engine Cooling Fan - 2nd Speed
07

50A (non A/C)

60A (A/C)

Engine Cooling Fan - 1st Speed
08 40A Passenger Compartment Blower
09 15A Rear Power Outlet
10 15A Horn
11 15A Fuel Pressure Regulator (MPROP)-DRV (3.0 Diesel Engine) — If Equipped
14 20A Power Outlet
15 7.5A USB Charger
16

7.5A

7.5A

KL15 Shifter Transmission Module (STM) (3.6), KL15 Starter Relay Coil (3.6 Gasoline Engine)

KL15 Manual Transmission Automated (MTA), KL15 Gear Selector Unit, KL15 Engine Control Module (ECM), KL15 Starter Relay Coil (3.0 Diesel Engine)

17

20A

20A

Engine Control Module (ECM), Injectors (3.6 Gasoline Engine)

Secondary Loads, Engine Control Module (ECM) (3.0 Diesel Engine)

18

7.5A

7.5A

KL30 Engine Control Module (ECM), KL30 Main Relay Coil (3.6 Gasoline Engine)

KL30 Manual Transmission Automated (MTA), KL30 Engine Control Module (ECM), KL30 Main Relay Coil (3.0 Diesel Engine)

19 7.5A A/C Compressor (If Equipped)
20 30A Windshield Wiper
21 15A Fuel Pump
22

20A

20A

Engine Control Module (ECM), Ignition Coils (3.6 Gasoline Engine)

Engine Control Module (ECM), Primary Loads (3.0 Diesel Engine)

23 20A Electronic Stability Control (ESC) Valves
24 7.5A KL15 Vacuum pump relay coil (3.6 Gasoline Engine) — If Equipped
30 15A Heated Mirrors



Front PDC Additional Fuses:

The additional fuse box is located inside the front PDC Box.

Fuse/Relay N° Rating Functions
61 20A Vacuum Pump (3.6 Gasoline Engine) — If Equipped
62 30A Transmission Power RELE (3.6 Gasoline Engine) — If Equippe
64 7.5A Urea Pump (3.0 Diesel Engine) — If Equipped
65 25A Urea NOX Sensor 1–2 — PM Sensor (3.0 Diesel Engine) — If Equipped
66 5A Shifter Transmission Module (STM) (3.6 Gasoline Engine) — If Equipped
