Chevrolet Venture 2001 Fuse Box Info
Passenger compartment fuse box location:
The instrument panel fuse box is located on the passenger side edge of the instrument panel.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
Fuse/Relay | Functions |
1 | Daytime Running Lamps (DRL) Control Module, Headlamp and Instrument Panel Dimmer Switch |
2 | Power Sliding Door |
3 | Front Power Windows |
4 | 6-Way Power Seat and Rear Side Door Actuator Motor |
5 | Blower Motor Hi Speed Relay Module |
6 | Steering Wheel Radio Control Switches (Illumination) |
7 | Instrument Cluster to PRNDL Indicators |
8 | Power Remote Control Mirror Switch |
9 | Cruise Control Module, Switch and Release Switch |
10 | Not Used |
11 | Power Control Module (PCM), Ignition Crank |
12 | PASS-Key III System |
13 | Body Control Module (BCM) |
14 | Heated Mirrors |
15 | Not Used |
16 | Not Used |
17 | Cigarette Lighter, DIC, Front Auxiliary Power Outlets |
18 | Turn Signal Switch |
19 | Interior Lamp and Multifunction Switch (Power Vent Switch) |
20 | Windshield Wiper/Washer Motor and Switch |
21 | Turn Signal Switch |
22 | Rear Electric Accessory Plug Housing |
23 | DRL Control Module |
24 | Not Used |
25 | Rear Window Defogger Relay, Heated Mirrors |
26 | OnStar |
27 | Inflatable Restraint Control Module |
28 | Heater-A/C Control |
29 | Instrument Cluster, BCM, Electronic Level Control (ELC) Sensor and Relay |
30 | Stoplamp Switch |
31 | Module/Electronic Brake Control Module/Electronic Brake Traction Control Module (EBCM/EBTCM) |
32 | Evaporative Emissions (EVAP) Canister Vent Solenoid Valve |
33 | Not Used |
34 | ELC Air Compressor and ELC Relay, Trailer Harness |
35 | Courtesy Lamp |
36 | BCM, Electronic Brake Control Indicator Lamp Driver Module, Instrument Panel Cluster, Rear Side Door Actuator Control Module, Rear Windows |
37 | Rear HVAC-A/C Control |
38 | Rear Window Wiper Motor, Rear Window Wiper/Washer and Multifunction Switch (Rear Window Wiper/Washer Switch) |
39 | Not Used |
40 | Not Used |
41 | Not Used |
42 | Not Used |
43 | Not Used |
44 | Retained Accessory Power (RAP) Relay |
45 | Not Used |
46 | Air Inlet Actuator, DIC Display, DRL Control Module, Heater-A/C Control, Temperature Door Actuator (Front) and Rear Window Defogger Relay |
47 | BCM Programming |
48 | Not Used |
49 | Not Used |
50 | IGN MAIN Relay and PCM, Electronic Break Control Module |
Engine compartment fuse box:
Fuse/Relay | Functions |
1. COOL FAN 2 | Coolant Fans |
2. | Not Used |
3. HEADLAMPS | Circuit Breakers: FRT HVAC HI BLWR, and HEADLAMP Fuses (Instrument Panel): HAZARD and STOPLAMP |
4. BATT MAIN 2 | Circuit Breaker: PWR SEAT/PSD. Fuses (Instrument Panel): ELC and RR DEFOG |
5. IGN MAIN 1 | Ignition Switch to Fuses (Instrument Panel): ABS/TCS IGN, CRUISE, DRL, ELEC PRNDL, IGN 1, PSD, SIR, T/SIG and PCM [IGN MAIN Relay (Underhood Electrical Center Fuses: A/C CLU, ELEK IGN, IGN 1-U/H, INJ, TCC)] |
6. COOL FAN 1 | Coolant Fans |
7. BATT MAIN 1 | Fuses (Instrument Panel): ABS MOD BATT, CIGAR/DLC, CTSY LAMP, FRT PWR SCKT, PWR LOCK, PWR MIRROR and RR PWR SCKT |
8. IGN MAIN 2 | Ignition Switch to Fuses (I/P): BCM PRGRM, FRT HVAC LOW/MED BLWR, FRT WPR/WSHR, HVAC/DRL, MALL/RADIO/DIC, PWR QRT VENT, RR HVAC, RR WPR/WSHR, SWC ACCY and PWR WDO Circuit Breaker |
9. COOL FAN | RH FAN 1, LH FAN 2 |
10. COOL FAN 2 | LH FAN 2 |
11. IGN MAIN | FUSES: A/C CLU, IGN 1-U/H, INS, ELEK IGN, TCC |
12. COOL FAN 1 | RH FAN 1, LH FAN 2 |
13. A/C CLU | A/C Clutch |
14. FUEL PUMP | Fuel Pump |
15. | Not Used |
16. HORN | Horn |
17. FOG LAMP | LH Fog Lamp, RH Fog Lamp, Fog Lamp Indicator |
18. INJ | Fuel Injectors 1-6 |
19. SPARE | Not Used |
20. SPARE | Not Used |
21. IGN1-UH | Evaporative Emissions (EVAP) Canister Purge Valve, Heated Oxygen Sensors 1 and 2, Mass Air Flow (MAF) Sensor |
22. SPARE | Not Used |
23. SPARE | Not Used |
24. SPARE | Not Used |
25. ELEK IGN | Ignition Control Module (ICM) |
26. SPARE | Not Used |
27. B/U LAMP | Transaxle Range Switch to Back-up Lamps |
28. A/C CLU | A/C CLU Relay to A/C Compressor Clutch Oil |
29. RADIO | Driver Information Display, Heater A/C Control, Radio, Rear Side Door Actuator Control Motor, Remote Control Door Lock Receiver (RCDLR), Security Indicator Lamp and Theft-Deterrent Shock Sensor |
30. ALT SENSE | Generator |
31. TCC | Automatic Transaxle (Torque Converter Clutch Solenoids) Stoplamp Switch to PCM |
32. FUEL PUMP | Fuel Pump Relay |
33. ECM SENSE | Powertrain Control Module (PCM) |
34. | Not Used |
35. FOG LP | Fog Lamp Relay |
36. HORN | Horn Relay |
37. PARK LP | Daytime Running Lamps (DRL) Control Module, Headlamps and Instrument Panel Dimmer Switch Theft-Deterrent Relay to Headlamps |
38. | Not Used |
39. SPARE | Not Used |
40. | Mini Fuse Puller |
A/C CLU DIODE |
Air Conditioning Clutch Diode |
