Chevrolet Spark 2013 Fuse Box Info
Passenger compartment fuse box location:
The instrument panel fuse box is on the underside of the driver side instrument panel.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° | Functions |
| 1 | Not Used |
| 2 | Not Used |
| 3 | Heater, Ventilation, and Air Conditioning Switch |
| 4 | Heated Seat |
| 5 | Not Used |
| 6 | Blower |
| 7 | Body Control Module 4 |
| 8 | Body Control Module 5 |
| 9 | Body Control Module 7 |
| 10 | Instrument Cluster |
| 11 | Not Used |
| 12 | Air Bag Power |
| 13 | Radio |
| 14 | Not Used |
| 15 | Rear Parking Assist |
| 16 | Body Control Module 1 |
| 17 | Body Control Module 2 |
| 18 | Body Control Module 3 |
| 19 | Body Control Module 6 |
| 20 | Body Control Module 8 |
| 21 | Heater, Ventilation, and Air Conditioning |
| 22 | Data Link Connector |
| 23 | Discrete Logic Ignition Sensor |
| 24 | Outside Rearview Mirror |
| 25 | Spare Fuse |
| 26 | Not Used |
| 27 | Not Used |
| 28 | Instrument Cluster |
| 29 | Air Bag Ignition |
| 30 | Rear Window |
| 31 | Front Window |
| 32 | Lighter/Auxiliary Power Outlet |
| 33 | Not Used |
| 34 | Run Relay |
| 35 | Logic Mode Relay |
| 36 | Accessory/ Retained Accessory Power Relay |
| 37 | Not Used |
| 38 | Radio |
| 39 | Heater, Ventilation, and Air Conditioning |
| 40 | OnStar |
| 41 | Spare Fuse |
| 42 | Spare Fuse |
| 43 | Spare Fuse |
| 44 | Spare Fuse |
| 45 | Spare Fuse |
| 46 | Spare Fuse |
Engine compartment fuse box:
| Fuse/Relay N° | Functions |
| 1 | Windshield Washer |
| 2 | Rear Window Washer Relay |
| 3 | Windshield Washer Relay |
| 4 | Horn Relay |
| 5 | Fan High Relay |
| 6 | Fan Low Relay |
| 7 | Antilock Brake System 1 |
| 8 | Horn |
| 9 | Not Used |
| 10 | Not Used |
| 11 | Spare Fuse |
| 12 | Fan High |
| 13 | Front Fog |
| 14 | Headlamp High Left |
| 15 | Headlamp High Right |
| 16 | Fan Low |
| 17 | Antilock Brake System 2 |
| 18 | Not Used |
| 19 | Spare Fuse |
| 20 | Front Fog Relay |
| 21 | Headlamp High Relay |
| 22 | Fuel Pump Relay |
| 23 | Not Used |
| 24 | Spare Fuse |
| 25 | Antilock Brake System 3 |
| 26 | EMIS 2 |
| 27 | Canister |
| 28 | Fuel Pump |
| 29 | Front Wiper |
| 30 | Front Wiper Control Relay |
| 31 | Spare Fuse |
| 32 | Starter |
| 33 | Ignition |
| 34 | EMIS 1 |
| 35 | Not Used |
| 36 | Not Used |
| 37 | Front Wiper Speed Relay |
| 38 | Not Used |
| 39 | Start Relay |
| 40 | Engine Relay |
| 41 | RUN/CRANK Relay |
| 42 | Interior Electrical Center |
| 43 | Not Used |
| 44 | Air Conditioning Relay |
| 45 | Air Conditioning |
| 46 | ECM/TCM 1 |
| 47 | ECM/TCM 2 |
| 48 | Low Vacuum Switch |
| 49 | Automatic Occupant Sensing |
| 50 | Mirror Heater |
| 51 | Rear Defog |
| 52 | Fuse Puller |
| 53 | Not Used |
| 54 | Voltage Sensing |
| 55 | Rear Wiper |
| 56 | Rear Wiper |
| 57 | Rear Defog Relay |
Auxiliary fuse box:
| Fuse/Relay Name | Functions |
| EVP RELAY | EVP Relay |
| EVP MTR | EVP Motor |
