Chevrolet Spark 2022 Fuse Box Info
Passenger compartment fuse box location:
The instrument panel fuse box is on the underside of the driver side instrument panel.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
Fuse/Relay Name | Functions |
ONSTAR | OnStar |
HVAC CNTR/ECC | HVAC Control Module/ Electronic Climate Control |
IPC | Instrument cluster |
TCM | Transmission control module |
RDO | Radio |
BCM1 (AT S&S) |
Body control module 1 (CVT stop and start) |
SBSA/RPA | Side Blind Spot Alert/ Rear Park Assist |
DLC | Data link connector |
ESCL | Electric steering column lock |
SDM | Sensing and diagnostic module |
TRANSD | DC-DC converter |
AQI | Virtual key pass system module |
ETCS | Electronic toll collection system |
LPM | Linear power module |
PEPS | Passive entry/ Passive start |
DLIS (Non AT S&S) | Discrete logic ignition switch (non-CVT stop and start) |
FCA | Forward Collision Alert |
IPC | Instrument cluster |
RLAD | Reflected LED alert display |
HLLD SW | Headlamp leveling switch |
FRT PWR WNDW |
Front power window |
REAR PWR WNDW |
Rear power window |
- | - |
MTA | Automated manual transmission module |
APO | Auxiliary power outlet |
S/ROOF | Sunroof |
CGM | Central gate module |
- | - |
BCM8 | Body control module 8 |
BCM7 | Body control module 7 |
BCM6 | Body control module 6 |
BCM5 | Body control module 5 |
BCM4 | Body control module 4 |
BCM3 | Body control module 3 |
BCM2 (Non AT S&S) |
Body control module 2 (non-CVT stop and start) |
BCM1 (Non AT S&S) |
Body control module 1 (non-CVT stop and start) |
DLIS (AT S&S) |
Discrete logic ignition switch (CVT stop and start) |
SWC BKLT | Steering wheel controls backlighting |
- | - |
TRANS (200/ 400W)/ LOGISTICS |
DC DC converter/ Logistics |
EXP PWR WNDW |
Driver express power window |
BLWR | Blower motor |
HTD/SEAT | Front heated seats |
HVAC CNTR | HVAC module |
HTD/STR | Heated steering wheel |
BCM2 (AT S&S) |
Body control module 2 (CVT stop and start) |
RLY1 | Logistics relay |
RLY2 | Accessory/ Retained accessory power relay |
RLY3 | Interruptible retained accessory power relay |
RLY4 | Run relay |
Engine compartment fuse box:
Fuse/Relay N° | Functions |
1 | Liftgate latch |
2 | Transmission output speed sensor |
3 | Rear defogger |
4 | Outside mirror heater |
5 | Sunroof |
6 | Continuously variable transmission control module |
7 | Mass air flow sensor |
8 | - |
9 | ABS valve |
10 | Regulated voltage control |
11 | Rear vision camera |
12 | - |
13 | - |
14 | Engine control module/ Transmission control module |
15 | Fuel injection control module/ Starter motor |
16 | Fuel pump motor |
17 | Engine control module 1 |
18 | Engine control module 2 |
19 | Injector/Ignition |
20 | A/C system |
21 | Intelligent battery sensor |
22 | Electric steering column lock |
23 | Cooling fan – low |
24 | Virtual key pass system sensor |
25 | Outside mirror motor control |
26 | Engine control module/ Transmission control module battery |
27 | Canister vent solenoid |
28 | - |
29 | Automatic occupant sensing |
30 | Headlamp leveling motor |
31 | Horn |
32 | Front fog lamps |
33 | Left high-beam headlamp |
34 | Right high-beam headlamp |
35 | Air quality ionizer |
36 | Rear wiper |
37 | Left cornering lamp |
38 | Washer motor |
39 | Right cornering lamp |
40 | - |
41 | Virtual key pass system sensor |
42 | Starter 2 |
43 | In-panel bussed electrical center |
44 | Automated manual transmission |
45 | Starter 1 |
46 | ABS pump |
47 | Cooling fan – high |
48 | Front wiper motor |
49 | Accessory/ Retained accessory power |
RLY1 | Rear defogger |
RLY2 | Transmission control module |
RLY3 | Fuel pump motor |
RLY4 | Starter 2 |
RLY5 | A/C system |
RLY6 | - |
RLY7 | Cooling fan – low |
RLY8 | Run/Crank |
RLY9 | Powertrain |
RLY10 | Starter 1 |
RLY11 | Cooling fan – high |
RLY12 | Front fog lamps |
